Naming Compounds and Writing Formulas

1
Naming Compounds and Writing Formulas

• Module 12

2
Ban DHMO?

• DHMO is dihydrogen monoxide.
• Evaluate the following link and decide if this
  potentially dangerous chemical should be
  prohibited.
• www.dhmo.org

3

• 5 types of chemical compounds
• Binary ionic - metal ion nonmetal ion
• Ternary ionic - at least one ion is a
  polyatomic ion
• Binary molecular - two nonmetals
• Binary acid - H nonmetal
• Ternary acid - H Polyatomic ion

4
Tips to keep in mind when naming and writing
formulas Always keep your Periodic Table handy
You should have it in front of you ALWAYS when
you are naming and writing formulas. Remember
that metals (except Hydrogen) are found to the
left of the stairstep on the Periodic
Table. Nonmetals are found on the right side of
the Periodic Table. Transition Metals are found
from Group 3 to the stairstep (except aluminum
which is a regular metal)
5
(No Transcript)
6

• How do you name binary ionic compounds? (composed
  of two elements a metal and a nonmetal)
• Name the first ion
• If the first ion is a transition element other
  than zinc, cadmium, or silver, you must use a
  Roman Numeral with the name well discuss this
  later.
• Name the second ion changing the suffix to ide.

7
Examples NaCl
What is the name of this compound HIJKLMNO? WATER
H to O You have to admit that was funny!
Name the metal ion
Sodium
Chloride
CaO
Name the nonmetal ion, changing the suffix to
ide.
Oxide
Calcium
Al2S3
Aluminum
Sulfide
MgI2
Magnesium
Iodide
This is two metals not a binary ionic compound
BaNa2
The name of this is Banana (JOKE haha)
You should recognize a problem with this one
8
What about the transition metals and using roman
numerals? How does that work? Lets see.
FeO
Notice metal and nonmetal.
Name the first ion. Since the first ion is a
transition element, you must use a Roman Numeral
to represent the charge.
Iron
II
Oxide
How do you know the charge? Deductive reasoning.
All compounds are neutral. Oxygen has a -2 charge
(group 16) Therefore .. Iron must have a 2
charge since there is one iron and one oxygen.
Iron gets a Roman Numeral II.
Isnt this easy and FUN!!!
9
Cu2S
Name the first ion. Since it is a transition
metal, you must use a Roman Numeral. Which Roman
Numeral? The Roman Numeral is the same as the
charge of the ion. How do you find the
charge? Deductive reasoning! All compounds are
neutral Sulfur has a -2 charge (group 16) There
are two coppers. Therefore each copper must have
a 1 charge for all ions to be neutral
Copper
I
Sulfide
10
Another Example MnO2
Name the first ion. Since it is a transition
metal, you must use a Roman Numeral. How do you
determine the Roman Numeral? It is the same as
the charge. What is the charge of Mn? All
compounds are neutral. Oxygen (group 16) has a -2
charge. There are two oxygens and one
Mn. Therefore Mn must have a 4 charge for this
compound to be neutral.
Manganese
IV
oxide
11
So why must we use Roman Numerals with transition
elements?
The metals in groups 1, 2, and 13 have single,
definite charges. Group 1 metals have a 1
charge. Group 2 metals have a 2 charge. Group 13
metals have a 3 charge. Transition metals may
have multiple charges usually two different
positive charges. For example, there are two
copper oxide compounds
Cu2O and CuO
Cu2O Copper I oxide Copper is 1
CuO Copper II oxide Copper is 2
We cant just say Copper oxide. Which one of
these is Copper oxide? We must distinguish these
by using a Roman Numeral
12
There are three transition elements which do not
require a Roman Numeral because they have single
definite charges. These are Zinc Zn2 Cadmium
Cd2 Silver Ag1
You need to remember the charges for these.
No Roman Numerals needed for these.
Ag2O
Name the first ion.
Name the second ion changing the suffix to ide.
oxide
Silver
ZnCl2
Name the first ion.
Name the second ion changing the suffix to ide.
Zinc
chloride
13
Sometimes you will see the transition elements
named using common names. Transition metals named
with Roman Numerals involves stock names. The
common names use the Latin derivative of the
elements name with a suffix of either ous or
ic. The ous suffix name corresponds with the
smaller charge. The ic suffix name corresponds
with the larger charge. Cuprous Copper I Cupric
Copper II
Ferrous Iron II Ferric Iron III
There are many more just be familiar with these
six common names.
Plumbous Lead II Plumbic Lead IV
14
In Summary
15

• How do you write formulas for binary ionic
  compounds given the name?
• Two simple steps
• Write the symbol and charge of each ion
• Balance the charges by providing subscripts

Magnesium chloride
Write the symbol and charge of each ion.
Mg2 Cl-1
Balance the charges by supplying subscripts.
Subscripts tell how many of each atom is present.
Cl-1
MgCl2
You need a second Cl-1 to balance the charges
16
More examples Iron III bromide
Write the symbol and charge of each ion. The
charge of the iron is provided by the Roman
Numeral.
Fe3 Br -1
Br -1
Br -1
FeBr3
Balance the charges by supplying subscripts. The
subscripts tell how many of each ion is needed to
balance the compound.
Youll need three bromine ions to balance the one
iron.
17
Aluminum Sulfide
Write the symbol and charge of each ion.
Al3 S-2
S-2
Al3
Balance the charges by supplying subscripts.
S-2
In this case the charges do not evenly divide
into each other. You must find the least common
multiple. SIX
Al2S3
How many aluminums are needed to arrive at a 6
charge?
2
How many sulfurs are needed to arrive at a -6
charge?
3
18
Second Category of compounds Ternary Ionic
Compounds. These compounds contain at least one
polyatomic ion. What is a polyatomic ion? Lets
look at the name to try to understands. It is an
ion that means it has a charge. It is
polyatomic that means it is made of more than
one atom. Simple as that!! Lets look at some
examples of polyatomic ions.
19
CO3-2
carbonate
This ion is composed of one carbon and three
oxygens and the entire group has a charge of -2.
Polyatomic ion Group of atoms that act as a
unit and carry a charge. More examples
PO4-3
Phosphate
C2H3O2-1
Acetate
SO4-2
Sulfate
OH-1
Hydroxide
SO3-2
Sulfite
NO3-1
Nitrate
ClO4-1
Perchlorate
NO2-1
Nitrite
ClO3-1
Chlorate
NH41
Ammonium (only positive PI)
ClO2-1
Chlorite
ClO-1
Hypochlorite
You need to learn these!!!
20

• How do you recognize Ternary Ionic Compounds?
• Composed of two ions in which at least one is a
  polyatomic ion.
• There is only one positive polyatomic ion (NH41)
• Three possible types of Ternary Ionic Compounds
• Ammonium negative ion (nonmetal)
• Metal (positive ion) negative polyatomic ion
• Ammonium negative polyatomic ion

s
Polyatomic Ion
21
How do you name Ternary Ionic Compounds? EASY!
PIECE OF CAKE! NO PROBLEM! Name the first
ion. Name the second ion. Isnt that
simple??!! Examples
When you look at this compound you should
recognize that this is NOT binary. There are
THREE elements present. When you see this,
immediately look for a polyatomic ion. Carbonate
is present here.
Na2CO3
Sodium
carbonate
Notice that you do NOT change the suffix just
name the polyatomic ion
Name the first ion.
Name the second ion.
22
A few more examples Fe(OH)3
Name the first ion.
Iron
Remember that iron requires a Roman Numeral since
it is a transition element. What Roman Numeral
should be used?
III
hydroxide
Since there are 3 OH groups, each with a -1
charge, the charge of the iron must be 3 for the
compound to be neutral

• The Roman Numeral comes from the charge of the
  ion. How do you find the charge of the iron?
• You know two things
• All compounds are neutral.
• You know the charge of OH (-1)

Name the polyatomic ion.
23
NH4Cl
Name the first ion.
Ammonium
Name the second ion.
chloride
Notice that since the second ion is a nonmetal
that, like binary ionic compounds, the suffix of
the nonmetal changes to ide.
Name the first ion.
(NH4)3PO4
Name the second ion.
Ammonium
phosphate
Looks like a monster, but its really a pussycat.
24
ONE more example Cu2SO4
Name the first ion.
You should realize that you need a Roman Numeral
since copper is a transition metal.
sulfate
Copper
I
The Roman Numeral is the same as the charge. What
is the charge? The charge of sulfate is -2. Since
there are two coppers, the charge of the copper
must be 1.
Name the second ion.
25

• How do you write formulas for Ternary Ionic
  Compounds?
• Very much like writing formulas for Binary Ionic
  Compounds.
• Two steps
• Write the formulas/symbols of each ion.
• Balance the charges by supplying subscripts.
• If a subscript is needed for a polyatomic ion, it
  must be put in parentheses with the subscript on
  the outside.
• Lets do some!!

26
Aluminum nitrate
First, you can tell from the name that there is a
polyatomic ion present (nitrate). All binary
ionic compounds have suffixes of ide.
Al3 NO3-1
Al(NO3)3
Write the formula/symbol and charge of each ion.
Balance the charges by supplying
subscripts. Since Al is 3 and NO3 is -1, you
need a total of 3NO3-1 to balance one Al3 Since
you will need a subscript of 3 for NO3-1, you
need to put this in parentheses with the 3
outside.
27
Lead (IV) acetate
Write the formula/symbol and charge of each ion.
Pb4 C2H3O2-1
Balance the charges by supplying subscripts.
Since Pb is 4 and C2H3O2 is -1, you will need 4
C2H3O2-1 to balance 1Pb4
Pb(C2H3O2)4
Write the formula/symbol and charge of each ion.
Calcium phosphate
Ca2 PO4-3
Balance the charges by supplying subscripts.
Since Ca is 2 and PO4 is -3, you will need 3
Ca2 to balance 2 PO4-3
Ca3(PO4)2
28
The Third Category of Compounds Binary
Molecular What are Binary Molecular
Compounds? These compounds contain two elements
(binary). The term molecular indicates that
these elements are joined by a covalent
bond. They must therefore be nonmetals. Bottom
line 2 elements both nonmetals To name and
write formulas for these, you must know some
numerical prefixes.
29

• Naming you must use prefixes.
• 1 mono 3 tri 5 penta 7 hepta
  9 nona
• 2 di 4 tetra 6 hexa 8 octa
  10 deca
• Steps
• The first nonmetal only gets a numeric prefix
  when there is more than one. No prefix if there
  is only one.
• The second element always gets a numeric prefix
  and always has a suffix of -ide

30
CO2 Carbon dioxide CO Carbon monoxide N2O4 Dinitro
gen tetraoxide H2O Dihydrogen monoxide CCl4 Carbon
tetrachloride
Name the first element. Since there is only one,
no prefix is needed. The second element always
gets a prefix and a suffix of ide.
Name the first element. Since there are two
present, the prefix di is needed. The second
element always gets a prefix and a suffix of ide.
Do you think it wise to BAN DHMO?
31
AlCl3
What do you think about this one??? Be careful.
This is a metal and nonmetal. Always keep your
Periodic Table in front of you for reference. You
may have been tempted to say aluminum
trichloride. This is INCORRECT! This is a binary
IONIC compound. No prefixes are used. Simply
aluminum chloride.
Given the names of binary molecular compounds,
how do you write the formulas? Very easy to do!!!
The prefixes tell you how to write the formulas.
DO NOT CONSIDER CHARGES. NONMETALS ARE ALL
NEGATIVE SO TO USE CHARGES DOES NOT WORK!
32
Silicon dioxide
Silicon and oxygen are both nonmetals. The lack
of a prefix on silicon means that there is only
ONE silicon. The prefix di in front of oxide
means that there are TWO oxygens.
SiO2
Diphosphorous pentachloride
P2Cl5
Phosphorous and chloride are both nonmetals. The
prefix di means that there are TWO
phosphorouses (Is that a word?) The prefix
penta before chlorine means that there are five
chlorines.
33
Nitrogen monoxide
Nitrogen and oxygen are both nonmetals. The lack
of a prefix on nitrogen means only ONE
nitrogen. The prefix mono on oxygen indicates
ONE oxygen.
NO
Is this not sooooooo easy!??
34
What are Binary Acids? Binary means two
elements Acid means it contains hydrogen The
second element is a nonmetal hydrogen
nonmetal Naming All binary acids follow the
pattern as shown below
35
Stem or root of nonmetal
Prefix
Suffix
Acid
-ic
Hydro-
lt NM gt
HCl is a binary acid hydrogen - nonmetal
HCl
Hydro
chlor
ic
Acid
Hydro
iod
ic
Acid
HI
Hydro
sulfur
ic
Acid
H2S
36
Given the name, how do you write formulas for
binary acids? The obvious pattern of the name
tells you that it is a binary acid. HydroltNMgtic
Acid. Therefore, you know that the acids begins
with hydrogen and contains a nonmetal which you
can identify between the Hydro and the ic To
arrive at the formula, you pretend that
hydrogen is 1 and using the normal charge of the
nonmetal, balance the formula by supplying
subscripts.
Hydrofluoric Acid
The name tells you that this is a binary acid.
H1 F-1
HF
37
Hydrophosphoric acid
The name tells you that it is definitely a binary
acid.
H1 P-3
H3P
Remember that the P has a -3 charge because it is
in group 15
38
Lets Practice Ca(OH)2 Calcium hydroxide SO2 Sulfu
r dioxide (NH4)3PO4 Ammonium phosphate Co2(CO3)3 C
obalt (III) carbonate HBr Hydrobromic acid
Ternary Ionic
Binary molecular
Ternary Ionic
Ternary Ionic
Binary acid
39
Potassium acetate KC2H3O2 Cadmium
nitrate Cd(NO3)2 Aluminum oxide Al2O3 Hydrosulfuri
c acid H2S Difluorine trioxide F2O3
Ternary Ionic
Ternary Ionic
Binary Ionic
Binary acid
Binary molecular
40
The fifth category of compounds is Ternary Acids.
These compounds begin with hydrogen since they
are acids. Attached to the hydrogen is a
polyatomic ion Hydrogen polyatomic ion
41
How are Ternary Acids named? There are two
categories of naming depending on the suffix of
the polyatomic ion. First Category If the
polyatomic ion has a suffix of ate or ide, use
the following pattern
suffix
-ic
acid
ltRoot of polyatomic iongt
Ternary Acid contains the polyatomic ion
chlorate (suffix ate)
Ternary Acid contains the polyatomic ion
nitrate (suffix ate).
Ternary Acid contains the polyatomic ion
sulfate (suffix ate).
Ternary Acid contains the polyatomic ion
cyanide (suffix ide).
HClO3
Chlor
ic
Acid
Nitr
ic
Acid
HNO3
Sulfur
ic
Acid
H2SO4
HCN
Cyan
ic
Acid
42
Second Category If the polyatomic ion has a
suffix of ite, use the following pattern
suffix
-ous
acid
ltRoot of polyatomic iongt
Ternary acid contains polyatomic ion, nitrite
(-ite suffix).
HNO2
acid
Nitr
ous
Chlor
ous
acid
Ternary acid contains polyatomic ion, chlorite
(-ite suffix).
HClO2
Ternary acid contains polyatomic ion, sulfite
(-ite suffix).
Sulfur
ous
acid
H2SO3
43
How are Ternary Acids named? First, a ternary
acid is easy to distinguish from a binary
acid. ALL binary acids have the prefix hydro-.
NO Ternary acids have the prefix hydro-.
Acetic acid
This is an acid, but NOT a binary acid. This is a
ternary acid. The -ic suffix in the acid name
tells you that the polyatomic ion must have a
-ate suffix acetate. To write the formula,
pretend that hydrogen is 1 and balance the
charges.
H1 C2H3O2-1
HC2H3O2
44
Hypochlorous acid
This is a Ternary acid (does not begin with
hydro-.
H1 ClO-1
The -ous suffix indicates that the polyatomic
ion in this acid has a suffix of -ite -
hypochlorite
HClO
Pretend that hydrogen is 1 and balance the
charges.
This is a Ternary acid (does not begin with
hydro-.
Phosphoric acid
H3PO4
The -ic suffix indicates that the polyatomic
ion in this acid has a suffix of -ate -
phosphate
Pretend that hydrogen is 1 and balance the
charges.
45
This concludes Module 13!
