BIOLOGY 11

1
BIOLOGY 11

• Plant Reproduction
• and Development

2
Introduction

• We saw in earlier units the problems that plants
  faced in evolving to land.
• One major problem was reproduction.
• In the angiosperms, the gametophyte generations
  are very reduced the male is only the pollen
  grain, the female is reduced to embryo sacs
  within the ovule.

3
Introduction

• Angiosperms reproduce primarily sexually but have
  a variety of mechanisms for asexual reproduction.
• A. Sexual Reproduction
• The Flower
• The flower is an organ specialized for sexual
  reproduction on land.

4
The Flower
2. Incomplete Flowers These lack one or more of
the four flower organs of sepals, petals, stamen,
or carpels Ex. Grass flowers lack petals

• 1. Complete flowers
• Have sepals, petals, stamen, and carpels

5
The Flower

• 3. Perfect Flowers
• Contains both sexes
• 4. Imperfect Flowers
• Contain only one sex

6
The Flower

• 1. Sepals often photosynthetic, may be brightly
  colored, may protect flower or act as secondary
  petals.
• 2. Petals visual attractant for vector, may have
  specific shape for particular vector.

7
The Flower

• 3. The Stamen the male portion of the flower
• Produces the pollen.
• Elevated upon filament for distribution of
  pollen.
• 4. The Carpel (often called the Pistil)
• Female portion produces the egg and eventually,
  the seed and fruit.

8
(No Transcript)
9
(No Transcript)
10
IDENTIFY THESE FLOWERS AS MONOCOT OR DICOT
11
Fertilization

• Pollination
• The pollen grain contains three nuclei two
  haploid sperm nuclei, and one diploid tube
  nucleus (directs pollen tube growth).
• Pollen lands on stigma and germinates to grow a
  pollen tube down the style.
• This is pollination (not fertilization).

12
Fertilization

• Fertilization occurs when the pollen tube fuses
  with an opening in the ovule called the
  Micropyle.
• The two sperm nuclei enter the ovule.
• One sperm nucleus joins with the egg - this will
  ultimately form the embryo and new plant.
• It also restores the diploid number.

13
Fertilization

• The second sperm nucleus joins with two haploid
  polar nuclei (left over from the meiosis that
  formed the egg) to form a Triploid nucleus (3N)
  in a large cell.
• This will divide rapidly to form the endosperm
  which grows rapidly as the embryo grows storing
  food around it.
• This whole process is called Double
  Fertilization.

14
Double Fertilization
15
Development of the Seed

• Once fertilization is complete events rapidly
  accelerate.
• 1. The zygote rapidly undergoes mitosis to form
  an embryo. It only develops so far then stops.
• 2. The ovule the rapidly growing endosperm fills
  in all the space between the embryo and the ovule
  wall - this will become the seed.

16
Development of the Fruit

• 3. The fruit develops from the tissues of the
  ovary which rapidly divide.
• The fruit at first protects the developing seeds
  (thus the name Angiosperm).
• When the seeds are ready for distribution, the
  fruit matures in some fashion to facilitate seed
  dispersal.

17
Seed Structure

• Seeds contain three basic structures
• 1. The seed coat formed from the wall of the
  ovule - protection.
• 2. Cotyledon(s) These are food storage sacs
  formed by transfer of food from the endosperm
  (endosperm may be present also).

18
Seed Structure

• 3. The embryo made of four parts
• i. The plumule embryonic leaves
• ii. The Epicotyl embryonic stem portion from
  above cotyledon attachment site
• iii. The Hypocotyl stem below the cotyledons
• iv. The Radicle embryonic root

19
Seed Structure

• Once the seed is developed, it goes dormant for a
  period of time.
• This is a survival mechanism to withstand winters
  on land (or dry seasons etc).
• Monocot seeds have only one cotyledon (seed
  half) dicots have two.

20
Germination

• Dormancy allows a plant to survive seasonal
  hardships.
• This allows plants to significantly extend their
  range and is why the angiosperms are the dominant
  land plants.
• Dormancy can last for years or even much longer
  if the conditions are right.

21
Germination

• Dormancy is broken when the dry seed begins to
  absorb water
• (called imbibition).
• This causes the seed to swell and the seed coat
  to burst.
• Imbibition also causes metabolic changes that
  result in the embryo resuming growth.
• This growth is fueled by food stored in the
  cotyledons or endosperm.

22
Germination

• In dicots, the first part of the embryo to emerge
  is the radicle (root).
• Next the hypocotyle emerges and pulls the plumule
  (embryonic leaves) to the surface.
• Once the seedling begins photosynthesis, the
  cotyledons shrivel and fall off.
• In monocots, the coleoptile breaks the ground
  first providing a protective sheath for the shoot
  inside.

23
(No Transcript)
24
Asexual Reproduction

• Most angiosperms are also capable of a form of
  asexual reproduction called Vegetative
  Reproduction which is actually a form of natural
  cloning.

25
Bulbs Modified Stem
Tulip bulbs
Gladiolis bulbs
Onion bulbs
26
Rhizomes Modified Stem
Bamboo Rhizomes
Iris Rhizomes
27
Tubers Modified Stems
28
Corms Modified Stems
Crocus corms
Garlic corms
29
Monocot vs. Dicot

• You have now seen many differences between these
  two main groups of angiosperms.
• The following slides summarize these differences.

30
MONOCOTS OR DICOTS?
