Chapter 7 Large and Fast: Exploiting Memory Hierarchy

1
Chapter 7Large and Fast Exploiting Memory
Hierarchy

• Bo Cheng

2
Principle of locality

• programs access a relatively small portion of
  their address space at a given time.
• Temporal locality (locality in time) if an item
  is referenced, it will tend to be referenced
  again soon.
• Spatial locality (locality in space) if an item
  is referenced, items whose addresses are close
  will tend to be referenced soon.

3
Basic Structure
4
The Principal

• By combining two concepts (locality and
  hierarchy)
• Temporal Locality gt Keep most recently accessed
  data items closer to the processor
• Spatial Locality gt Move blocks consisting of
  multiple contiguous words to upper levels of the
  hierarchy

5
Memory Hierarchy (I)
6
Memory hierarchy (II)

• Data is copied between adjacent levels
• Minimum unit of information copied is a block
• If the requested data appears in some block in
  the upper level, this is called a hit, otherwise
  a miss and a block containing the requested data
  is copied from a lower level.
• The hit rate or hit ratio, is the fraction of
  memory accesses found in the upper level. The
  miss rate (1.0 - hit rate) is the fraction not
  found at the upper level.
• Hit time the time to access the upper level
  including the time to determine if the access is
  a hit or a miss.
• Miss penalty the time to replace a block in the
  upper level.

7
Memory Hierarchy (II)
8
The Moores Law
9
Cache

• A safe place for hiding or storing things
• The level of memory hierarchy between processor
  and main memory
• Refer to any storage managed to take advantage pf
  locality of access
• Motivation
• high processor cycle speed
• low memory cycle speed
• fast access to recently used portions of a
  program's code and data

10
The Basic Cache Concept
1. The CPU is requesting data item Xn 2. The
request results in a miss 3. The word Xn is
brought from memory into cache
11
Direct Mapped Cache

• Each memory location is mapped to exactly one
  location in the cache.
• address of the block modulo number of blocks in
  the cache.
• Answer two crucial questions
• How do we know if a data item is in the cache?
• If it is, how do we find it?

12
The Example of Direct-Mapped Cache
13
(No Transcript)
14
Cache Contents
m
n

• Tag
• Identify whether a word in the cache corresponds
  to the requested word.
• Valid bit
• indicates whether an entry contains a valid
  address
• Data

Tag size 32 n 2 32 10 - 2
Size 2index x ( valid tag data)
2n x ( 1 m 48)
15
Direct-Mapped Example
How many total bits are required for
direct-mapped?

• A Cache
• 16 KB of data
• 4-word blocks
• 32 bits address

4-word
n m 4 32 . (1) 16KB 4K words 210
block ? n 10 m 18 The total bits 210 x (1
18 448) 147 Kbits
16 KB
4 x 4 x 8 128 bits
16
Mapping an address to a cache block
Source http//www.faculty.uaf.edu/ffdr/EE443/
17
Block Size vs. Miss Rate
18
Handling Cache Misses

• Stall the entire pipeline fetch the requested
  word
• Steps to handle an instruction cache miss
• Send the original PC value (PC-4) to the memory.
• Instruct main memory to perform a read and wait
  for the memory to complete its access.
• Write the cache entry, putting the data from
  memory in the data portion of the entry, writing
  the upper bits of the address (from the ALU) into
  the tag field, and turning the valid bit on.
• Restart the instruction execution at the first
  step, which will refresh the instruction, this
  time finding it in the cache.

19
Write-Through

• A scheme in which writes always update both the
  cache and the memory, ensuring that data is
  always consistent between the two.
• Write buffer
• A queue that holds data while the data are
  waiting to be written to memory.

20
Write-Back

• A scheme that handles writes by updating values
  only to the block in the cache, then writing the
  modified block to the lower level of the
  hierarchy when the block is replaced.
• Pro Improve performance, especially when writes
  are frequent (and couldnt be handled by write
  buffer)
• Con More complex to implement

21
Cache Performance

• CPU time (CPU execution clock cycles
  Memory-stall clock cycles) x Clock cycle time
• Memory-stall clock cycles Read-stall cycles
  Write-stall cycles
• Read-stall cycles (Reads/Program) x Read miss
  rate x Read miss penalty
• Write-stall cycles ((Writes/Program) x Write
  miss rate x Write miss penalty) Write buffer
  stalls
• Memory-stall clock cycles (MemoryAccess/Program)
  x Miss Rate x Miss Penalty
• Memory-stall clock cycles (Instructions/Program)
  x Misses/Instructions) x Miss Penalty

22
The Example
Source http//www.faculty.uaf.edu/ffdr/EE443/
(1.38 2)
23
What if .

• What if the processor is made faster, but the
  memory system stays the same?
• Speed up the machine by improving the CPI from 2
  to 1 without increasing the clock
• The system with a perfect cache would be 2.38 / 1
  2.38 times faster
• The amount of time spent on memory stalls rises
  from 1.38/3.38 41 to 1.38/2.38 58

24
What if .
25
Our Observations

• Relative cache penalties increases as a processor
  becomes faster
• The lower the CPI, the more pronounced the impact
  of stall cycles
• If the main memory system is the same, a higher
  CPU clock rate leads to a larger miss penalty

26
Decreasing miss ratio with associative cache

• direct-mapped cache A cache structure in which
  each memory location is mapped to exactly one
  location in the cache.
• set-associative cache A cache that has a fixed
  number of locations (at least two) where each
  block can be placed.
• fully associative cache A cache structure in
  which a block can be placed in any location in
  the cache.

27
The Example
(12 mod 8) 4
(12 mod 4) 0
Can appear in any of the eight cache block
28
One More Example Direct Mapped
5 Misses
29
Two-Way Set Associative Cache
which block to replace commonly used is LRU
scheme
Least recently used (LRU) A replacement scheme in
which the block replaced is the one that has been
unused for the longest time.
4 Misses
30
The Implementation of 4-Way Set Associative Cache
31
Fully Associative Cache
3 Misses
Increasing degree of associativity ? decrease in
miss rate
32
Performance of Multilevel Cache
11/4 2.8
33
Designing the Memory System to Support Caches (I)

• Consider hypothetical memory system parameters
• 1 memory bus clock cycle to send address
• 15 memory bus clock cycles to initiate DRAM
  access
• 1 memory bus clock cycle to transfer a word of
  data
• a cache block is a 4-word blocks
• 1-word-wide bank of DRAMs
• The miss penalty is 1 4 15 4 1 65
  clock cycles
• Number of bytes transferred per clock cycle per
  miss
• (44) / 65 0.25

34
Designing the Memory System to Support Caches (II)
35
Virtual Memory

• The technique in which main memory acts as a
  "cache" for the secondary storage
• automatically manages main memory and secondary
  storage
• Motivation
• allow efficient sharing of memory among multiple
  programs
• remove the programming burdens of a small,
  limited amount of main memory

36
Basic Concepts of Virtual Memory
Source http//www.faculty.uaf.edu/ffdr/EE443/

• Virtual memory allows each program to exceed the
  size of primary memory
• It automatically manages two levels of memory
  hierarchy
• Main memory (physical memory)
• Secondary storage
• Same concepts as in caches, different terminology
• A virtual memory block a page
• A virtual memory miss a page fault
• CPU produces a virtual address (which is
  translated to a physical address, used to access
  main memory). This process (accomplished by a
  combination o HW and SW) is called memory mapping
  or address translation.

37
Mapping from a Virtual to Physical Address
232 4 GB
230 1 GB
38
High Cost of a Miss

• Page fault takes millions of cycles to process
• E.g., main memory is 100,000 times faster than
  disk
• This time is dominated by the time it takes to
  get the first word for typical page size
• Key decisions
• Page size large enough to amortize the high
  access time
• Pick organization that reduces page fault rate
  (e.g., fully associative placement of pages)
• Handle page faults in software (overhead is small
  compared to disk access times) and use clever
  algorithms for page placement
• Use write-back

39
Page Table

• Containing the virtual to physical address
  translations in a virtual memory system.
• Resides in memory
• Indexed with the page number form the virtual
  address
• Contains corresponding physical page number
• Each program has its own page table
• Hardware includes a register pointing to the
  start of the page table (page table register)

40
Page Table Size

• For Example
• Consider 32-bit virtual addresses,
• 4-KB page size,
• 4B per page table entry
• Number of page table entries
• 230/212 220
• Size of page table
• 220 x 4 4 MB

41
Page Faults

• Occurs when a valid bit (V) is found to be 0
• Transfer the control to the operating system
  (using the exception mechanism)
• The operating system must find the appropriate
  page in the next level of hierarchy
• Decide where to place it in the main memory
• Where is the page on this disk?
• The information can be found either in the same
  page table, or in a separate structure
• The OS creates the space on disk for all the
  pages of the process
• at the time it creates the process
• At the same time, a data structure that records
  the location of each
• page is also created.

42
The Translation-Lookaside Buffer (TLB)

• Each memory access by a program requires two
  memory accesses
• Obtain the physical address (reference the page
  table)
• Get the data
• Because of the spatial and temporal locality
  within each page, a translation for a virtual
  page will likely be needed in the near future.
• To speed this process up include a special cache
  that keeps track of recently used translations

43
The Translation-Lookaside Buffer (TLB)
44
Processing read/write requests
45
Where Can a Block Be Placed?
1. Increase in the degree of associativity
usually decreases the miss rate. 2. The
improvement in miss rate comes from reduced
competition for the same location.
46
How Is a Block Found?
47
What block is replaced on a miss?

• Which block is a candidate for replacement
• In a fully associative cache all blocks are
  candidates
• In a set-associative cache all the blocks in
  the set
• In a direct-mapped cache there is only one
  candidate
• In set-associative and fully associative caches,
  use one of two strategies
• 1. Random. (use hardware assistance to make it
  fast)
• 2. LRU (Least recently used). usually two
  complicated even for fourway associativity.

48
How Are Write Handled?

• There are two basic options
• Write-through The information is written to
  both the block in the cache and to the block in
  the lower level of the memory hierarchy
• Write-back The modified block is written to the
  lower level only when it is replaced
• ADVANTAGES of WRITE-THROUGH
• Misses are cheaper and simpler
• Easier to implement (although it usually requires
  a write buffer)
• ADVANTAGES of WRITE-BACK
• CPU can write at the rate that the cache can
  accept
• Combined writes
• Effective use of bandwidth (writing the entire
  block)
• Virtual memory is a special case only a
  write-back is practical

49
The Big Picture

• Where to place a block?
• One place (direct-mapped)
• A few places (set-associative)
• Any place (fully-associative)
• How to find a block?
• Indexing (direct-mapped)
• Limited search (set-associative)
• Full search (fully associative)
• Separate lookup table (page table)
• 3. Which block should be replaced on a cache
  miss?
• Random
• LRU
• 4. What happens on a write?
• Write-through
• Write-back

50
The 3Cs

• Compulsory misses caused by the first access to
  a block that has never been in the cache
  (cold-start misses)
• INCREASE THE BLOCK SIZE (increase in miss
  penalty)
• Capacity misses caused when the cache cannot
  contain all the blocks needed by the program.
  Blocks are being replaced and later retrieved
  again.
• INCREASE THE SIZE (access time increases as well)
• Conflict misses occur when multiple blocks
  compete for the same set (collision misses)
• INCREASE ASSOCIATIVITY (may slow down access time)

51
The Design Challenges
