Title: Building User Defined Functions (UDF)


1
Building User Defined Functions (UDF)
Speaker Jo Belyea-Doerrman jobdoer_at_teratech.c
om TeraTech Consultant
2
Speaker Information
  • Who am I?
  • ColdFusion Developer
  • ColdFusion Developer since 1997
  • Teach one-on-one and custom classes for TeraTech

3
This Session
  • This session I will
  • introduce you to the brave new world of
    user-defined functions (UDFs)
  • demonstrate two ways to create your own
    functions
  • show you where to get UDFs others have written.

4
Extend CFML
  • One of the advantages of CF is that it is
    extensible.
  • CFML can be easily extended beyond the tags and
    functions that are built-in.

5
4 ways to extend Cold Fusion
  • User-Defined Functions
  • Custom Tags
  • ColdFusion Components (CFCs)
  • CFX Tags
  • This session focuses on UDFs.

6
What are UDFs?
Simply put, UDFs are functions that you create
and/or share. If you feel that some function is
missing from CF make it yourself!
7
User-Defined Functions (UDFs)
  • Think of them as little engines on an assembly
    line
  • Accepts input runs it through the function and
    creates some kind of corresponding output
  • Now can be built with CFFUNCTION, CFARGUMENT
    CFRETURN tags.

Ucase()function
8
Why use UDFs instead of Custom Tags?
  • Only UDFs provide the convenience of return
    values.
  • Custom tags can create values (as
    Caller.VariableName) that are accessible to the
    calling template after their execution, but with
    UDFs the return value is the primary goal of the
    function.

9
Why use UDFs? Cont.
  • Performance may be worth some consideration when
    deciding to use UDFs or custom tags.
  • If a function is to be performed multiple times
    within one template, a UDF would most likely
    out-perform the custom tag. This is due to the
    fact that processing does not have to leave the
    template every time a UDF is executed. With the
    custom tag, it goes out to the tag itself each
    time processing of the task is required.

10
Whats new?
  • Completely overhauled in CFMX.
  • Can be written with Cold Fusion tags or using
    CFSCRIPT
  • No longer have to write UDFs with CFSCRIPT
    strongly recommend using ltCFFUNCTIONgt rather than
    this method
  • Note If you are writing UDFs in CF5 you must
    still write them in CFSCRIPT

11
Basic steps to a UDF with tags
  • To create a user-defined function you will need
    to four basic steps that use the following tags
  • CFFUNCTION
  • CFARGUMENT
  • CFRETURN

12
Step 1
  • Start with a pair of ltCFFUNCTIONgt tags. All the
    code you need to make the function do its work
    goes in between these tags.

13
Step 2
  • ltCFARGUMENTgt Add each argument your function
    will be using for input. Can make required or
    optional.

14
Step 3
  • Add any CFML code that is needed to make your
    function work. Can use whatever tags and
    functions you want.

15
Step 4
  1. The last step uses the ltCFRETURNgt tag. It
    specifies what your functions output should be.

16
Building Your First UDF
  • You may find yourself wanting a function that
    pulls an employees e-mail address from the db.
  • You could use this
  • ltCFOUTPUTgtgetEmployeeEmail(8)
  • lt/CFOUTPUTgt
  • You could create it using the old ltCFQUERYgt
    taghowever, you can also turn this into a
    function very easily!

17
Lets look at some code!
  • Well call the UDF GetEmployeeEmail()

18
GetEmployeeEmail()
  • ltCFFUNCTION nameGetEmployeeEmailgt
  • ltCFARGUMENT NAMEEmployeeID TYPENumeric
    REQUIREDYesgt
  • lt!---Get the Employees email---gt
  • ltCFQUERY NamegetEmployee DATASOURCEdatasourc
    e
  • CACHEDWITHINCreateTimespan(0,1,0,0)gt
  • SELECT EmployeeEmail FROM Employees
  • WHERE ARGUMENTS.EmployeeID
  • lt/CFQUERYgt
  • lt!--- Return the employees email ---gt
  • ltCFRETURN getEmployee.EmployeeEmailgt
  • lt/CFFUNCTIONgt

19
Using the Function
  • Once written, this can be used like any other
    function.
  • When CF sees the function -- It runs the code
    between the corresponding ltCFFUNCTIONgt tags.
  • Arguments can be
  • Static
  • ltCFOUTPUTgtGetEmployeeEmail(8)lt/CFOUTPUTgt
  • Dynamic
  • ltCFOUTPUTgtGetEmployeeEmail(FORM.ShowEmployeeID)
  • lt/CFOUTPUTgt
  • Used within ltCFSETgt
  • ltCFSET myEmployeeLowerCase Lcase(GetEmployeeEma
    il(FORM.ShowEmployeeID))gt

20
How do the tags work?
21
ltCFFUNCTIONgt
  • NAME You will call the function using the name
    provided here. Must be a valid CFML identifier.
  • RETURNTYPE Optional. Type of info the function
    will return. String, numeric, date and so on.
    Use to make functions more self-documenting.

22
ltCFARGUMENTgt
  • NAME The name of the argument.
  • TYPE Optional. The data type that should be
    supplied to the argument. If you supply a TYPE,
    CF will display an error if someone tries to use
    the function with the wrong kind of input.
  • REQUIRED Optional. Default is No.
  • DEFAULT Optional. For optional arguments
    (REQUIRED No), the value of the argument when
    the value is not passed in.

23
Required Arguments
  • ltCFARGUMENT
  • REQUIRED Yesgt
  • Argument must be provided the function is
    actually used.
  • If the argument is not provided at runtime, CF
    will display an error message.

24
Optional Arguments
  • If REQUIREDno and a default has been specified
    then the function can be called either with or
    without the argument at runtime.
  • If the value IS provided, the value will be what
    is presented in the ARGUMENTS scope.
  • If not, the DEFAULT value will be used
  • If REQUIREDno and a default has NOT been
    specified then the function still optional. You
    can use the IsDefined() function to determine
    whether the argument is provided at runtime.

25
ltCFRETURNgt
  • Return value can be any expression
  • Has no attributes per se. Instead, you determine
    whatever string, number, date, variable or
    expression you want directly returned within the
    ltCFRETURN gt tag.
  • Examples
  • ltCFRETURN agt
  • ltCFRETURN TimeFormat(Now())gt
  • ltCFRETURN The current time is
    TimeFormat(Now())gt

26
Dont show variables
  • Most times you dont want variables to be visible
    to pages that use the function
  • You need to tell CF that a particular variable
    should only be visible within the context of the
    ltCFFUNCTIONgt block.
  • Dont want function to have side effects.
  • Should not have to worry about its overwriting
    any variables already defined
  • Called a Local Variable

27
Using Local Variables
  • ltCFSET var myLocalVariable Hellogt
  • The var keyword tells CF that the variable should
    cease to exist when ltCFFUNCTIONgt block ends.

28
Local Variable Rules
  • Can declare as many as you want. Use separate
    ltCFSETgt for each, using the var keyword each
    time.
  • ltCFSETgt must be at the very top of ltCFFUNCTIONgt
    block right after the ltCFARGUMENTgt tags.

29
Local Variable Rules cont.
  • Can not declare without a value. There must be
    an sign with an initial value. Can change
    later in the functions code.

30
Where to Save Your UDFs
  • You can Create and Use UDF in the same file
  • or
  • Save UDFs in Separate Files for easy reuse
  • Reusing code saves time and effort
  • ltCFINCLUDEgt function code
  • If you want function available at the application
    level, ltCFINCLUDEgt function code in
    Application.cfm

31
Creating Libraries of Related UDFs
  • No specific rules what kinds of UDFs can be
    collected into a library.
  • Makes sense to group your UDFs into different
    files according to some kind of common concept
  • UDFs can call other UDFs in the same file.
  • They can even call functions in other files as
    long as the ltCFINCLUDEgt tag has been used to
    include the other files

32
Uses for UDFs
  • Adding Tags to CFSCRIPT

33
Adding Tags to CFSCRIPT
  • Another good use is when wanting to do something
    only supported by tags within a CFSCRIPT block
  • For instance, may want to do a CFDUMP in a script
  • Cant use that tag in CFSCRIPT
  • But can create UDF to do it and call that from
    script

34
CFFUNCTION_dumpudf code
  • lt!--- cffunction_dumpudf.cfm ---gt
  • ltcffunction name"dump"gt ltcfargument
    name"var"gt ltcfargument name"label"
    required"no" default""gt ltcfoutputgtarguments.la
    bellt/cfoutputgt ltcfdump var"arguments.var"gt lt
    brgtlt/cffunctiongt

35
Adding Tags to CFSCRIPT
  • You can now call it just like any other UDF
  • In this example, calling inside CFSCRIPT
  • Not a requirement. Can call outside CFSCRIPT too

36
Calling
  • lt!--- other\call_dumpudf.cfm ---gt
  • ltcfinclude template"cffunction_dumpudf.cfm"gt
  • ltcfscriptgt
  • // while creating code in CFSCRIPT you often
    want to dump something
  • // server scope is something we can now dump in
    CFMX
  • dump(var"server")
  • // or simply
  • dump(server)
  • lt/cfscriptgt

37
Benefits Over CFSCRIPT UDFs
  • Besides ability to use tags within UDF
  • More important point may be ability to use
    CFARGUMENT, and ReturnType on CFFUNCTION
  • These give greater control over data types over
    data coming into and going out of UDF
  • and required/optional support for arguments
    coming in

38
Benefits Over CFSCRIPT UDFs
  • Also, can use the ROLES attribute on CFFUNCTION
    to limit use by authorized users (see
    CFLOGINUSER)
  • Also, in script, there is no equivalent to
    CFTHROW
  • Still, the choice will more often be one of
    programming style
  • Each approach has its place

39
UDF written with CFSCRIPT
  • function TempConvert(ATemp, ItsScale)
  • if (not IsNumeric(ATemp)) return "NAN"
  • if (UCase(ItsScale) eq "F")
  • // temp given in Fahrenheit. Convert to Celsius
    degs (ATemp - 32.0) ( /9.0)
  • else if
  • (UCase(ItsScale) eq "C")
  • // temp given in Celsius. Convert to Fahrenheit
    degs (ATemp 9.0/5.0) 32
  • else
  • degs "Not a valid scale"
  • return degs 50 degrees Fahrenheit is
    TempConvert("50","F") degrees Celsius.

40
Calling the UDF
  • Call the UDF by using the following
  • 50 degrees Fahrenheit is TempConvert("50","F")
    degrees Celsius.

41
What does it do?
  • Prints "50 degrees Fahrenheit is 10 degrees
    Celsius."

42
How does it work?
  • Two arguments are passed to the function a
    temperature and the scale that it is in.
  • The temperature is checked to make sure it's a
    number (the value "NAN" is returned and
    processing ends if it is not).
  • Then the calculation is processed based on the
    scale being "F" or "C."
  • If the scale given is neither "F" nor "C," the
    message "Not a valid scale" is returned.

43
Rules for function definitions
  • The following rules apply to functions that you
    define using CFScript or the CFFunction tag
  • The function name must be unique. It must be
    different from any existing variable, UDF, or
    built-in function name.
  • The function name must not start with the letters
    cf in any form. (For example, CF_MyFunction
    cfmyFunction, and cfxMyFunction are not valid UDF
    names.)

44
Rules cont.
  • You cannot redefine or overload a function. If a
    function definition is active, ColdFusion
    generates an error if you define a second
    function with the same name.
  • You cannot nest function definitions that is,
    you cannot define one function inside another
    function definition.

45
Rules cont.
  • The function can be recursive, that is, the
    function definition body can call the function.
  • The function does not have to return a value

46
Define a function in the following places
  • On the page where it is called.
  • You can even define it below the place on the
    page where it is called, but this poor coding
    practice can result in confusing code.

47
Define a function in the following places
  • On any page that puts the function name in a
    scope common with the page on which you call the
    function.

48
Define a function in the following places
  • On a page that you include using a cfinclude tag.
  • The cfinclude tag must be executed before the
    function gets called. For example, you can define
    all your application's functions on a single page
    and place a cfinclude tag at the top of pages
    that use the functions.

49
Define a function in the following places
  • Application.cfm page.
  • Consider the following techniques for making your
    functions available to your ColdFusion pages on
    the following pages.

50
Using Application.cfm and function include files
  • If you consistently call a small number of UDFs,
    consider putting their definitions on the
    Application.cfm page.

51
Using Application.cfm and function include files
cont.
  • If you call UDFs in only a few of your
    application pages, do not include their
    definitions in Application.cfm.

52
Using Application.cfm and function include files
cont.
  • If you use many UDFs, put their definitions on
    one or more ColdFusion pages that contain only
    UDFs. You can include the UDF definition page in
    any page that calls the UDFs.

53
Specifying the scope of a function
  • User-defined function names are essentially
    ColdFusion variables. ColdFusion variables are
    names for data. Function names are names
    (references) for segments of CFML code.
    Therefore, like variables, functions belong to
    scopes.

54
Do not use the following as names of CFCs or UDFs
equals getClass getMetadata getPagePath getSuperScope invoke hashCode notify notifyAll setSuperScope toString wait
55
Where can I find UDFs?
  • www.cflib.com
  • www.macromedia.com

56
Ideas from the audience
  • Any thoughts on how you could use UDFs in your
    programming?
  • Share your thoughts

57
Where can I find out more information?
  • http//livedocs.macromedia.com/coldfusion/6.1/html
    docs/udfs.htm
  • http//www.macromedia.com/devnet/server_archive/ar
    ticles/user_defined_functions.html
  • http//www.macromedia.com/devnet/mx/coldfusion/art
    icles/ud_functions.html
  • http//www.cflib.org/resources.cfm
  • Macromedia Coldfusion MX Web Application
    Construction Kit Fifth Edition Chapter 19

58
Conclusion
  • UDFs are easy to write.
  • Now go out and write your own UDFs!
Write a Comment
User Comments (0)
About PowerShow.com
