AutoMed

1
AutoMed

• A Heterogeneous Data Integration System

2
Outline

• Both-As-View (BAV) approach
• GAV LAV approaches
• BAV approach
• Comparison of integration approaches
• BAV advantages
• The AutoMed system
• Architecture
• Current future work
• Testbeds

3
GAV LAV Approaches

• Global-As-View (GAV) approach describe GS
  constructs with view definitions over LSi
  constructs
• Local-As-View (LAV) approach describe LSi
  constructs with view definitions over GS
  constructs

4
Global-As-View Approach (GAV)

• student(id,name,left,degree) x,y,z,w
  ?x,y,z,w,_??ug ? ?x,_,_,_,_??phd ?
• ?x,y,z,w,_??phd ?
• w phd
• monitors(sno,id)
• x,y ?x,_,_,_,y??ug ?
  ?x,_,_,_,_??phd ?
• ?x,y??supervises
• staff(sno,sname,dept)
• x,y,z ?x,y,z,w,_??tutor ?
  ?x,_,_??supervisor ?
• ?x,y,z??supervisor

5
Local-As-View Approach (LAV)

• tutor(sno,sname)
• x,y ?x,y,_??staff ? ?x,z??monitors
  ?
• ?z,_,_,w??student ?
• w ? phd
• ug(id,name,left,degree,sno)
• x,y,z,w,v ?x,y,z,w??student ?
  ?v,x??monitors ?
• w ? phd

6
Both-As-View (BAV) (1/3)

• Schema transformation approach
• For each pair (LSi,GS) incrementally modify
  LSi/GS to match GS/LSi

7
Both-As-View (BAV) (2/3)

• Common Data Model Hypergraph Data Model (HDM)
• Constructs are nodes, edges constraints
• It avoids the semantic mismatches that may occur
  between constructs of higher-level modelling
  languages

8
Both-As-View (BAV) (3/3)

• Modify using primitive schema transformations
• add/delete
• rename
• extend/contract
• Supply transformations with queries
• add(??table,attrib3??, q), where
  qt,(a1a2)t,a1???table,attrib1??t,a2???
  table,attrib2??
• extend(??table,attrib3??, q1,q2)

9
Example (1/2)

• S1 ? Sg
• add(??monitors?? ,q1)
• add(??monitors,sno??,q2)
• add(??monitors,id??,q3)
• add(??tutor,dept??,q4)
• rename(??ug??,??student??)
• rename(??tutor,??staff??)
• delete(??student,sno??,q5)
• S2 ? Sg can be derived similarly

10
Example (2/2)

• Automatically derivable reverse transformations
• add(C,q)/extend(C,q1,q2) delete(C,q)/contract(C,
  q1,q2)
• delete/contract add/extend
• rename(C1,C2) rename(C2,C1)

11
BAV vs. LAV, GAV GLAV

• BAV approach subsumes other integration
  approaches
• Can be used to derive GAV LAV view definitions
  (ICDE03)
• Comparison with GAV, LAV GLAV in DBIS'04

12
Schema Evolution

• In GAV LAV view definitions have to be
  regenerated
• The BAV approach readily supports the evolution
  of both local and global schemas
• In particular (CAiSE02 ICDE03 papers)
• if the evolved schema is semantically equivalent
  to the original schema, schema evolution is
  automatic
• if the evolved schema is a contraction of the
  original schema, schema evolution is automatic
• if the evolved schema is an extension of the
  original schema, then domain knowledge may be
  required (but again the pathway can be evolved
  rather than regenerated)

13
Local Schema Evolution Example

• Define the evolution of the global or local
  schema as a schema transformation pathway from
  the old to the new schema

14
Types Of Integration

• Virtual integration
• Materialised integration
• Hybrid integration

15
Outline

• Both-As-View (BAV) approach
• GAV LAV approaches
• BAV approach
• Comparison with GAV, LAV GLAV
• BAV advantages
• The AutoMed system
• Architecture
• Current future work
• Testbeds

16
The AutoMed System

• The AutoMed toolkit implements the BAV data
  integration approach
• AutoMed repository
• Model Definitions Repository (MDR)
• Schema Transformation Repository (STR)
• AutoMed query language IQL
• Higher-level query languages are translated to
  IQL
• IQL is translated to the query languages of the
  datasources

17
Query Engine
18
Query Engine
Query
Reformulator
19
Wrappers

• Current
• Relational (Oracle, PostgreSQL, SQLServer)
• XML documents (DOM SAX)
• YATTA
• RDF
• Near future
• Object-oriented (ODMG 3.0 compliant)
• Native XML Databases (Xindice, Sedna)
• RDF Schema Specific DataBase (RSSDB)

20
Testbeds

• BioMap
• http//www.biochem.ucl.ac.uk/bsm/biomap
• Data warehouse containing diverse biological data
• AutoMed used for the creation and maintenance of
  the data warehouse
• ISPIDER
• http//www.ispider.man.ac.uk
• Develop a Grid architecture for sharing data from
  various biological data sources (such as BioMap)
• Extend AutoMed system with Grid services

21
Development/Research Areas

• Query engine
• Query processing optimisation
• Query language translation
• Tools
• Data Warehousing data lineage
• Automatic schema matching (data mining)
• Automatic integration of XML data sources
• Unstructured/semi-structured data
• Transformation pathway optimisation
• Visualisation tool
• Grid/P2P architecture

22
Project Information

• Homepage http//www.doc.ic.ac.uk/automed
• Technical details
• Papers
• Technical reports
• Software
• AutoMed releases
• Documentation

23
Project Members

• Birkbeck College
• Alexandra Poulovassilis (P.I.)
• Hao Fan
• Dean Williams
• Lucas Zamboulis
• Past members
• Tanvir Amed Faqueer
• Edgar Jasper
• Dimitri Theodoratos

• Imperial College
• Peter McBrien (P.I.)
• Mike Boyd
• Sasivimol Kittivoravitkul
• Nikolaos Rizopoulos
• Nerissa Tong
• Past members
• Siegfried Hodgson
• Charalambos Lazanitis

24
XML Data Transformation Integration

• Lucas Zamboulis, Alexandra Poulovassilislucas,ap
  _at_dcs.bbk.ac.uk

25
Overview

• Objective restructuring integration of XML
  files
• Motivation
• Interoperability
• Related work on relational databases
• Need for XML-specific solutions

26
Outline

• Semantic Heterogeneity
• Schema Matching
• Ontologies
• Structural Heterogeneity
• XML schema type in AutoMed
• Schema transformation
• Schema integration

27
Semantic Heterogeneity

• Problem definition
• Schema Matching
• Data mining
• Neural networks
• Machine learning (LSD)
• Ontologies (RDFS/OWL)

28
Schema Matching (1/2)

• Types
• 1-1, 1-n, n-1, n-m
• Subset, superset, equivalence
• Use schema matching output to create the
  intermediate schemas used by the schema
  restructuring / schema integration algorithms

29
Schema Matching (2/2)

• Necessary transformations
• add attributes day, month, year in S
• delete attribute dob from S
• The reverse transformation pathway describes a
  n-1 match

30
Structural Heterogeneity

• Problem Same information can be represented in
  many different ways
• Ancestor descendant ?? different branches
• Elements attributes not clearly distinguished
  in XML model
• Ordering policy

31
Aims

• XML-specific solution
• Insert-remove-rename operations on elements,
  attributes, edges
• Efficient move (node/subtree) operation
• Element-to-attribute, attribute-to-element
  transformations
• Avoid loss of data due to structural
  incompatibilities
• Automation

32
A Schema Type For XML

• DTD
• Advantage wide adoption
• Disadvantages
• Non-XML format
• Grammar
• XML Schema
• Advantage XML format
• Disadvantages
• Grammar
• Unnecessary complexity

33
XML DataSource Schema (1/3)

• Basic characteristics
• Structure-only representation
• XML format ? ease of traversal manipulation
• Automatically derived from an XML file
• XMLDSS from other schema types (DTD, XML Schema)

34
XML DataSource Schema (2/3)
35
XML DataSource Schema (3/3)

• XMLDSS is being extended
• Structural summary ? schema type (persistence,
  describe multiple documents)
• Constraints
• Primary/foreign keys
• Cardinality
• Ordering
• If present, translate DTD/XML Schema to XMLDSS

36
Schema Transformation (1/2)

• Target schema T given
• Source schema S is transformed to match the
  structure of T

37
Schema Transformation (2/2)

• Schema matching phase
• Schema transformation phase
• id phase
• Target schema materialisation

38
Algorithm

• Growing phase traverse the target schema and
  issue an add/extend transformation for every
  construct that does not exist in the source
  schema.
• Shrinking phase traverse the source schema and
  issue an delete/contract transformation for every
  construct that does not exist in the target
  schema.
• Completeness of algorithm

39
Transformation Types

• AutoMed primitive transformations
• add/extend
• delete/contract
• rename
• Schema level
• Insert, remove or rename schema constructs
• Move element/subtree
• Element ?? attribute

40
Example 1

• Insert element C
• ext(ltCgt,Void,Any)
• ext(ltA,Cgt, Void,Any)
• ext(ltC,Bgt, Void,Any)
• del(ltA,Bgt,q)
• Remove element C
• add(ltA,Bgt,q)
• con(ltCgt, Void,Any)
• con(ltC,Bgt, Void,Any)
• con(ltA,Cgt, Void,Any)

41
Example 2

• Insert/remove edge move operation

42
Example 3

• Move
• add(ltroot,Bgt,q3)
• add(ltB,Agt,
• b,aa,b?ltA,Bgt)
• delete(ltA,Bgt)
• a,bb,a?ltB,Agt)
• Complete
• add(ltBgt, ltBgtq1)
• add(ltA,Bgt, ltA,Bgtq2)
• delete(ltA,Bgt, ltA,Bgt)
• delete(ltBgt, ltBgt)
• rename(ltBgt, ltBgt)

Schemas
Data
43
Example 1 - revisited

• Actually, this can also be treated with an
  add/delete transformation

44
Example 4

• Element-to-attribute transformation
• insert(ltA,ABgt,q)
• remove(ltA,Bgt,q)
• remove(ltB,PCDATAgt,q)
• remove(ltBgt,q)
• Attribute-to-elementtransformation
• insert(ltBgt,q)
• insert(ltA,Bgt,q)
• insert(ltB,PCDATAgt,q)
• remove(ltA,ABgt,q)

45
Schema Integration Type I
46
Schema Integration Type II

• Type I integration performs two tasks at once
• schema integration
• schema improvement
• Type II
• Augment with missing constructs
• Remove redundant constructs

47
Schema Integration Type II

• Improve GS as a second step

48
Materialisation

• Strategy
• Materialise root and its attributes
• Consider all edges (ep,ec) in a depth-first way
• Materialise ec and its attributes

49
Conclusions

• XML specific solution
• element??attribute transformations
• move operation
• No loss of data by synthetically creating missing
  structure

50
Evaluation

• BIOMAP
• Integration of biological data sources
• Relational databases, XML documents, XML databases

51
Future Work

• Short-term
• Use ontologies for resolving semantic
  heterogeneity
• Extend XMLDSS
• Native XML Databases (Xindice, Sedna)
• XML-Enabled Databases (Oracle)
• Long-term
• Schema integration
• GS improvement (type II)
• Overlapping data identification
• Targeted rematerialisation of GS
• Schema evolution
