LowFrequency Pulsar Surveys and Supercomputing

1
Low-Frequency Pulsar Surveys and Supercomputing

• Matthew Bailes

2
Outline

• Baseband Instrumentation
• MultiBOB
• MWA survey vs PKSMB survey
• Data rates
• CPU times
• Low-Frequency Pulsar Monitoring
• The Future Supercomputers

3
Pulsar Dedispersion

• Incoherent

4
Coherent Dedispersion

• Unresolved on us timescales
• From young or millisecond pulsars
• Power-law distribution of energies

PSR J02184232
5
10221001 Pulsar Timing (Kramer et al.)
6
CPSR2 Timing (Hotan, Bailes Ord)
7
Swinburne Baseband Recorders etc

• 1998 Canadian S2 to computer (16 MHz x 2)
• 100K system video tapes
• 2000 CPSR
• 20 MHz x 2 DLT7000 drives x 4
• 2002 CPSR2
• 128 MHz x 2 real-time supercomputer (60 cores)
• 2006 DiFX (Deller, Tingay, Bailes West)
• Software Correlator (ATNF adopted)
• 2007 APSR
• 1024 MHz x 2 real-time supercomputer (160
  cores)
• 2008 MultiBOB
• 13 x 1024 ch x 64us fibre 1600-core
  supercomputer

8
dspsr software

• Mature
• Delivers lt 100 ns timing on selected pulsars
• Total power estimation every 8us with RFI
  excision
• Write a loader
• Can do
• Giant pulse work
• Pulsar searching (coherent filterbanks)
• Pulsar timing/polarimetry
• Interferometry with pulsar gating

9
PSRDADA (van Straten)

• psrdada.sourceforge.net
• Generic UDP data capture system (APSR/MultiBOB)
• Ring Buffer(s)
• Can attach threads to fold/dedisperse etc
• Hierachical buffers
• Shares available CPU resources/disk
• Web-based control/monitoring
• Free! hooks to dspsr psrchive.

10
APSR

• Takes 8 Gb/s voltages
• Forms
• 16 x 128 channels (with coherent dedispersion)
• 4 Stokes, umpteen pulsars
• Real-time fold to DM250 pc/cc.
• O(100) Ops/sample
• Sustaining gtgt100 Gflops
• 100K computers.

• June 2008
• 192 MHz working _at_ 4bits
• 768 MHz working _at_ 2bits

11
Coherent Dedispersion BW/time
1024
x
(100K)
BW
128
(300K)
x
16 20
x
x
1998 2000 2002 2004 2006 2008
year
12
Coherent Dedispersion

• Now trivial
• FFT ease B-2/?3

13
MultiBOB

• High Resolution Universe Survey (PALFA of the
  South)
• Werthimers iBOB boards
• 1024 channels, down to 10us sampling
• Two pols
• FPGA coding hard
• Use software gain equalizer/summer
• 5 MB/s beam
• 1 Gb/s Fibre to Swinburne (gt1000 km fibre)
• Real time searching!

14
New PKS MB Survey

• Bailes
• 13 beams
• 9 minutes/pointing
• 1024 channels
• 300 MHz BW
• 64 us sampling
• /- 15 deg

• Kramer
• 13 beams
• 70 minutes/pointing
• 1024 channels
• 300 MHz BW
• 64 us sampling
• /- 3.5 deg

• Johnston
• 13 beams
• 4.5 minutes/pointing
• 1024 channels
• 300 MHz BW
• 32 us sampling
• The rest

15
MWA

• Samples
• Takes (24x1.3MHz32 MHz) x 2 x 512
• Just 32 GB/s (64 Gsamples/s)
• FFTs it
• (5 N log2 ops/pt 2.2 Tflops)
• XMultiplies adds
• (512)256B4 16 TMACs

16
Sensitivity
(folded factor)
17
PKS vs MWA

• G 3-5 x better
• Tsys 14 x worse ?
• B1/2 3 x worse
• Flux 25 x better (1400 vs 200 MHz)
• t1/2 32 x better

Single Pulse work Comparable Coherent search
32x improvement!
But There is a limit to the time you can observe
a pulsar! 4m vs 144m -gt 5x deeper.
18
Scattering b0

• 1,10,100,1000ms

19
Scattering b5d

• 1,10,50,100ms

20
b30

• 0.5,1ms

21
Search instrumentation?
Volts
Spectra
Visibilities
FBanks
uv
32 MHz
Dedisp
F
X
Grid
2D FFT-1
36 GB/s
x 512
x 512 x 256
x 1922
x 512
36 GB/s
1024 GB/s 32 bits
600 GB/s
30 GB/s 5 bits
200 GB/s 32 bits
Fold
FFT
Spectra
Pulsars lt1 bit/s
22
Search Timings

• 36,000 coherent beams (768m/4m192)2
• 36 gigapixels/s
• Dedisperse/CPU core
• Gigapixel/120s
• 36 x 120 4320 cores 500 machines 250 kW
• NFFT 36,000 1024 (DMs)/8192 4608 FFTs/sec
• Seek (3s / 8192 x 1024 pt FFT)
• 14,000 cores 1800 machines MW. (M/yr)

23
Supercomputing _at_ Swinburne
The Green Machine

• installed May/June 2007
• 185 Dell PowerEdge1950 nodes
• 2 quad-core processors
• (Clovertown Intel Xeon 64-bit 2.33 GHz)
• 16GB RAM
• 1TB disk -gt 300 TB total
• 1640 cores/14 Tflops
• dual channel gigabit ethernet
• CentOS Linux OS
• job queue submission
• 20 Gb infiniband (Q1 2008)
• 83 kW .vs. 130 kW cooling

Machines 1.2M Fuel 100K/yr
24
Search Times

• Depend only upon
• Npixels x Nchans x Tsamp-1
• Requires
• No acceleration trials
• PSR J0437-4715
• In 8192s, small width from acceleration

25
Search Timings (32x32 tiles)

• 36000-gt1024 coherent beams
• 36-gt1 gigapixels/s
• Dedisperse/core
• Gigapixel/120s
• 120 120 cores 15 machines 7 kW
• NFFT 1024 1024 (DMs)/8192(s/FFT) 128
  FFTs/sec
• Seek (3s / (8192 x 1024) pt FFT)
• 378 cores 50 machines 25 kW.

26
RRATs

• Log N - Log S (helps with long pointings)
• 1000 x integration time.
• Maybe good RRAT finder.

27
Monitoring
Monitoring?
28
Monitoring
29
Build Your Own Telescope?

• May be cheaper to build dedicated PSR telescope
  than attempt to process everything from existing
  telescopes!
• 32x32 tile (2D FFT - 1D FFT - dedisperse - FFT)
• 2M telescopes
• 2M beamformer/receivers
• 1M correlator
• 1M Supercomputer
• 1M construction
• 7-8M

30
Next-Gen Supercomputers (IO or Tflops?)

• Infiniband 20 Gb (40Gb)
• 288 port switch
• 10 Tb/s IO Capacity (1-2K/node)
• Teraflop CPU capacities/node (140 Gflops now)
• Teraflop Server or Tflop GPU?
• 10 GB/s vs 76 GB/s
• Power (0.1W/)
• 2M 200 kW

31
Architecture (2011??)
288 Ports 40 Gb/s
288 Ports 40 Gb/s
144 Tflops
144 Tflops
FX
300K
1M
300K
1M
32
Summary

• Strong motivation for multiple (100) tied array
  beams
• PSRs/deg2
• Surveys only possible with compact configurations
• At present
• Future Supercomputers may allow search even with
  MWA-like telescopes
