TEQUILA Toward Evidence-based QUeueing Inference
for Latency Analysis
Charles Sutton, RAD Lab Jan 7, 2009
1

• Charles Sutton
• RAD Lab
• Jan 7, 2009

2
Transient Diagnostic ?s

• Performance models represent What if?
• This talk They can also answer
• What happened?
• Ex What fraction of response time caused by load?

Ex What caused temporary performance degradation
1 hr ago? Ex What are bottlenecks of the 1
slowest requests?
3
Measurement

• Many questions can be answered by measurement.
• Measurements include
• Response time
• Workload

4
Types of Measurement
5
Talk Road Map

• Interpret queueing network as a probabilistic
  model.
• Observe subset of arrivals, departures from
  running system.
• Reconstruct unobserved measurements
• Compute posterior distribution
• Answer diagnostic questions from reconstructed
  data

6
Generative Probabilistic Models
HIDDEN
OBSERVATIONS

• Define probability distribution
• p(Burglary, Earthquake, Alarm, JohnCalls,
  MaryCalls)
• Compute posterior distribution
• p(Plague Buboes, No Runny Nose)

7
Graphical Models

• Idea Represent how hidden variables generate
  the input

p(Burglary) p(EQ)
p(Alarm Burglary, EQ)
p(JohnCalls Alarm) p(MaryCalls Alarm)
8
Inference

• Problem Compute marginal probabilities given
  evidence

p(Burglary John, not Mary) S p(EQ, Alarm,
John, not Mary)
This is a posterior distribution.
9
Queueing Networks

• Model each component as a queue

Processor
M/M/1 queue

• For each task k
• Arrival time
• Departure time
• Service time
• Waiting time

10
Queueing Networks

• Model distributed system as network of queues
• Example two-tier web application

Web Server
DB
Web Server
Network
DB
Web Server
11
Queueing Networks
Finite state machine describes a tasks path
through the system.
Web Server
DB
Web Server
Network
DB
Web Server
12
Probabilistic Modeling

• Now we have a probability distribution over
• arrivals, departures, service times, and waiting
  times.

¹
Web Server
DB
Web Server
Network
DB
Web Server
13
Probabilistic Modeling

• Arrival and departure times can be instrumented.
• Question Can we reconstruct missing arrivals?
• Answer Use posterior distribution
• p( hidden arrivals arrivals I observed)

¹
Web Server
DB
Web Server
Network
DB
Web Server
14
Progress from Last Retreat

• Last retreat
• All queues single processor
• FIFO
• Service times exponential
• This retreat
• Arbitrarily many processors
• FIFO and random
• Arbitrary service distributions

15
Programmers Perspective

• Programmer supplies
• 1. Structure of queueing network

Rails 1
DB
Rails 2
Rails 3
DB 5 processor, FIFO, log normal service
distribution
16
Programmers Perspective

• Programmer supplies
• 2. Arrivals and departures measured in production

17
Reconstruction Accuracy
Service
Waiting
Exponential
Log Normal
18
Example Cloudstone

• Cloudstone running on EC2
• 5 VMs, Load up to 20 req/s
• Model Each thread (thin) a single-processor
  queue
• Data For each request, log
• Time spent in Rails
• Time spent in database

19
Example Cloudstone

• Cloudstone running on EC2
• 5 VMs, Load up to 20 req/s
• Workload

20
1. Visualization

• Performance bottlenecks over time

21
2. Hidden Resources

• Common performance bug
• Blocking on a resource you shouldnt
• Approach Model selection

MODEL 2 (PERFORMANCE BUG)
Rails
Rails
VM1
DB
Rails
Rails
VM2
22
2. Hidden Resources
MODEL 2 (PERFORMANCE BUG)
Rails
DB
Rails
VM
23
2. Hidden Resources
MODEL 1 (NORMAL)
Rails
DB
Rails
MODEL 2 (PERFORMANCE BUG)
Rails
DB
Rails
VM1
24
Summary

• Model-based diagnosis
• WHY A model lets you reason about aspects of the
  system state that you cant measure.
• HOW Do that reasoning using algorithms from
  machine learning
• Accurate reconstruction from 10 of possible log
  data

25
What Next?

• Modeling different applications
• Distributed file systems (e.g., Hadoop DFS)
• Network traffic
• SCADS?
• Feedback between queues
• Online, distributed inference
• Converting code ? performance model
