Modelling genomes

1
Modelling genomes

• Gil McVean
• Department of Statistics, Oxford

2
Why would we want to model a genome?

• To identify genes
• Protein-coding
• RNA
• Small RNAs
• To identify regulatory elements
• Transcription factor binding sites
• Enhancers
• To classify genome content
• Repeat DNA
• Unique sequence
• To understand the processes that shape genomes
• Mutation
• Recombination
• Duplication
• Rearrangement
• Natural selection

3
A rather simple model for a protein-coding gene
STATES
EMISSIONS
4
A genome model is like any other statistical
model
5
Hidden Markov Models in bioinformatics

• The model of a gene just described can be thought
  of as a hidden Markov model (HMM)
• The underlying states evolve in a Markov fashion,
  but we observe features (the DNA sequence)
  emitted by those states
• You will remember that there are lots of nice
  computational properties of hidden Markov models
  that we can use for inference
• Finding a most likely sequence of states
• Calculating posterior probabilities of a given
  state at a given position
• There are also various algorithms we can use to
  estimate parameters of HMMs (e.g. ML estimation
  by EM)
• How would you use the model of a gene to find new
  genes?
• How well do you think it would do?

6
Making useful HMMs in bioinformatics

• To be useful, HMMs for genes have to incorporate
  many features
• Regulatory sequences
• Intron-splicing features
• Correlations and biases in amino acid and base
  composition
• A REALLY important feature to capture is their
  evolution
• Important parts of genes and genomes evolve
  slower due to constraint

7
Searching for homology

• If we compare human and chimpanzee sequences they
  are approximately 98.8 identical at the DNA
  level. It is easy to identify which parts of
  the genome in humans correspond to which parts in
  chimps
• If we compare human with, say mouse, we can see
  some parts that are similar, and other parts
  where there is only vague or even no obvious
  similarity.
• When measuring evolution, we need to identify
  regions that are homologous
• Homology means similarity by descent
• Traditionally, the problem of identifying
  homology has been intrinsically linked to the
  problem of alignment

8
Alignment of PFEMP1 proteins from P. falciparum
9
The simplest problem aligning two sequences

• Suppose we have just two protein sequences that
  we want to align
• In evolution, three types of event can happen
• Mutation to new amino acids
• Insertion of new amino acids
• Deletion of amino acids
• We want to work out which amino acids in the two
  sequences are homologous i.e. related to each
  other through shared ancestry

WAKIS WEEKS
WAKIS WEEK-S
What do the -s really mean?
10
How can we construct an alignment algorithm?

• What we want to do is to look at every possible
  alignment and choose the one that is best
• What we have to do is to find an efficient
  algorithm that can search every possible
  alignment and that has an objective measure as to
  what best means
• A natural approach is to make a model of
  alignments, parameterise it and find the
  alignment that maximises the likelihood
• Although the problem sounds hard we can solve it
  using a hidden Markov model structure

11
How does is work?

• Suppose residues Xi and Yj are aligned to each
  other
• Three things could happen next
• The next two residues in each sequence could also
  align (A)
• A gap could be introduced in sequence X (B)
• A gap could be introduced in sequence Y (C)
• We can parameterise the probabilities of each
  event

Xi
Yj
XiXi1
Xi-
XiXi1
(B)
(C)
(A)
YjYj1
YjYj1
Yj-
12
The full algorithm

• We need to consider similar transitions for the
  cases when residue Xi is aligned to a gap after
  residue Yj, and when Yj is aligned to a gap after
  Xi
• We need to specify various probabilities
• The probability of inserting a gap
• The probability of extending a gap
• The probability of finishing the alignment
• The probability of observing an aligned pair of
  residues (20x20)
• The probability of observing a residue aligned to
  a gap (20)
• Once specified we can use the Viterbi and
  Forward/Backward algorithms to identify ML
  alignments, sample from the posterior or
  calculate posterior probabilities

Xi-aXi
Xi -
Yj -
Yj-aYj
13
The forward algorithm
Xi1
Emission probabilities ek(Xi1 )
H
H
D
Transition probabilities qij
In alignment the state space is two-dimensional
(residue i aligned to residue j)
14
The Viterbi algorithm
Xi1
Xi
Xi-1
H
H
H
D
D
D
A traceback matrix is used to keep track of the
best partial alignments
15
An example

• Suppose the gap opening and extension parameters
  are 0.2 and 0.5 respectively. There is a 80
  chance of observing a match, a 20/19 chance of
  observing any given mismatch and a 5 chance of
  observing each unaligned amino acid (We can
  ignore termination for the moment)
• The BEST alignments are given below, each of
  which has log likelihood of -16.84, or 31 of the
  total likelihood (lnlk -15.67).
• In many real situations, the best alignment
  represents only a fraction of the total likelihood

WAKIS WEEK-S
WA-KIS WEEK-S
16
Posterior decoding

• Using the forward-backward algorithm we can
  calculate the posterior probability that any
  residue is aligned to any other, or that a given
  residue is in a gap state

X1
X2
X3
X4
X5
X1
X2
X3
X4
X5
Y1
Y1
Y2
Y2
Y3
Y3
Y4
Y4
Y5
Y5
Conditional on X2-Y3
17
Extending the method

• Originally, alignment algorithms (Needleman and
  Wunsch, 1970 Smith and Waterman, 1981 Gotoh
  1982) were not explicitly defined as hidden
  Markov models
• Finite-state automata (FSA)
• There have been many extensions to the original
  idea
• Local alignment
• Repeat alignment
• Protein family identification
• Gene finding
• Multiple alignment
• The alignment algorithm is very much a workhorse
  of bioinformatics, as an alignment is needed or
  almost all subsequent analyses (e.g. phylogenetic
  tree reconstruction, population genetic
  inference)
• However, relying on a single alignment is not
  always a great idea

18
Doing away with alignment

• For most problems, the alignment is not of
  primary interest
• The natural thing to do is to integrate over
  alignments (as in the FB algorithm) to estimate
  parameters of interest
• The key problem is that there is no
  computationally efficient algorithm for
  statistical multiple alignment. All widely-used
  methods use heuristic approaches

19
Gene conversion and var gene diversity in P.
falciparum

• Multiple alignment methods typically assume the
  sequences are related to each through an
  evolutionary tree
• For the case of multi-gene families, this may not
  be the case, because gene conversion between
  copies can lead to mosaic structures
• If we wish to learn about the processes of
  conversion, a natural approach is to model the
  mosaicism
• In the case of var genes, the sequences are so
  diverged that we also need to consider the
  problem of alignment

20
Mosaic alignment

• We could model the n1th sequence as a mosaic of
  the previous n
• We can calculate the likelihood of observing a
  given sequence by summing over all possible
  mosaic structures and their alignment
• We can also identify the most likely mosaic
  structure and calculate the expected number of
  recombination events
• Repeating the procedure for all sequences
  provides a way of assessing the importance of
  mosaicism within the family

21
Extensive mosaicism within the var family
