Title: JFFS:


1
  • JFFS
  • The Journaling Flash File System
  • Ioannis Papadopoulos
  • ipapadop_at_cse.tamu.edu

2
Motivation for JFFS
  • Typical approach for using flash memory
  • Implement a block-device emulation layer
  • Makes the flash memory look like a magnetic disk
    drive
  • Then use a regular filesystem
  • Problems
  • Suboptimal writing
  • A block in flash memory is 128KiB (NOR) or 8KiB
    (NAND)
  • A block device has 512byte sectors thus a
    filesystem for the latter is optimized for these
    sectors
  • Potential data loss
  • Keeping data in memory while writing the block
  • Wear-leveling is either inexistant or requires a
    Translation Layer
  • Have the same amount or erasures for every block
  • Flash Translation Layer (FLT) and NAND FLT (NFLT)
  • Covered by patents (M-Systems)

3
JFFS
  • Log-structured filesystem
  • Data/metadata are written sequentially to the log
  • It is a continuous stream of data
  • The log is the filesystem
  • Inode
  • Data structure in Unix filesystems that keeps
    information for a file, directory or other object
  • Unique and non-reusable 32bit identifier
  • An inode has many nodes
  • Node
  • Metadata
  • uid, gid, mtime, atime etc.
  • Variable amount of data
  • Total ordering between nodes in inode
  • Unique and non-reusable 32bit identifier called
    version
  • Running out of identifiers not an issue
  • Limited lifetime of flash memory

4
Log details
  • Obsolete nodes are nodes that are not used
  • Called Dirty Space
  • A deleted inode has only obsolete nodes
  • Nodes whose range is covered by later nodes
  • Later nodes have higher version number
  • Head of log first non-obsolete node
  • Tail of log last non-obsolete node
  • At mount time, all the nodes are scanned
  • Rebuild directory structure
  • Do the inode-to-node mapping
  • Mapping and directory structure kept in memory
  • Changes in metadata or file writes
  • Writes new node at the end of the log
  • So nodes of the same range become obsolete!

5
Garbage Collection (GC)
  • Write needs to be done but no space for a new
    node
  • Reclaim dirty space
  • Head is moved after the tail of the log
  • The head becomes obsolete
  • New head is the next non-obsolete node
  • May merge many nodes to improve storage
    efficiency
  • Nodes move happens until a full block has been
    erased
  • It becomes available for use by the tail of the
    log
  • At least 4 blocks are needed at the tail to do GC
  • Empirically proven
  • Maximum node size half flash block
  • JFSS is a circular log

6
JFFS Limitations
  • No hard links allowed
  • Suboptimal GC
  • Provides perfect wear leveling
  • But moving data unnecessarily
  • On every pass of the GC, it was moving static
    data
  • No compression support

7
JFFS2
  • Three node types
  • No more circular log
  • Each erase block is treated individually
  • Nodes do not span over different blocks
  • Some information only about inodes cached at
    memory
  • New mounting procedure
  • Four stages
  • Scan all nodes and check them, from inode-to-node
    mapping
  • Find obsolete nodes
  • Find deleted inodes
  • Flush inode information cache

8
JFFS2 Nodes
  • Common header
  • Full node length, node type, CRC
  • Support for well-defined behavior if kernel does
    not support the node type
  • Backwards compatibility
  • JFFS-like node of inode
  • Support for compression
  • Dirent node
  • Directory entry of link-to-inode
  • Clean node
  • Indicates an erased node
  • Solves problem of partially erased nodes in block
    appearing as used in JFFS

9
JFFS2 Compression Support
  • Major feature since JFFS
  • That's why JFFS2 was created
  • Zlib, rubin, rtime compression algorithms
  • For data in nodes
  • Special compression mode signals empty node
  • Truncation leads to holes in files
  • Old GC didn't care about holes in files
  • Linear so later nodes took care of holes
  • New GC has problems
  • Mark nodes that are holes with compression
    special header

10
JFFS2 GC
  • Instead of head-tail a free_list of nodes
  • Heurestic starts GC
  • Obtains full inode information
  • Tries to compress some of the non-obsolete nodes
    of the inode
  • Writes it in a new block
  • Erases the old one and puts it in the free_list
  • Formal proof of correctness of GC crucial
  • But compression complicates things
  • Single byte changes entropy
  • Solution allow partial ordering of nodes
  • Same version number if same data
  • Formal proof pending

11
Future
  • Improved Fault Tolerance
  • Error Detection Yes (CRC)
  • Error Correction NO!!!
  • Currently mark bad blocks and check them upon
    remounting
  • Essential for NAND
  • Higher error rates
  • Garbage Collection Space Requirements
  • 5 full erase blocks needed currently before any
    write happens
  • Can probably be reduced to
  • 1 block for NOR flash
  • 3 blocks for NAND flash
  • Formal upper bound for number of erase blocks
  • No provable upper bound for JFFS1, possibly
    exists for JFFS2
  • Transaction Support
  • Expose transactions to user-space
  • Not as another layer, but in the filesystem
    itself
  • Take advantage of the journalling capabilities

12
Conclusion
  • XIP (eXecute-In-Place)
  • Don't move program to RAM for execution
  • Execute it in the flash
  • Can't work with compression
  • Developers do not consider implementing it
  • Or maybe support a read-only XIP-capable JFFS2
  • JFFS and JFFS2 are stable
  • No major bugs, small number of new ones
  • Used in Familiar, a GNU/Linux distribution and
    by RedHat's contract customers
  • In Linux Kernel versions 2.4 and up
  • Available under GNU/GPL and eCoS MPL licences
