Computer Science Software Engineering
AspectAda Aspect-Oriented Programming for Ada95
WORLD CLASS through people, technology and
dedication
2
Agenda

• Separation of Concerns Crosscutting
• Aspect-Oriented Programming (AOP) Model
• Logging Example
• AspectAda Prototype Architecture
• Effect on SW Quality

3
Separation of Concerns (SoC)

• Separation of Concerns (SoC) (Parnas,
  Dijkstra)
• realization of problem domain concepts into
  separate units of software.
• Benefits of SoC
• Better analysis and understanding of systems
• Easy adaptability, maintainability and high
  degree of reusability.
• Low Coupling/High Cohesion
• SoC Fundamental to SW Development
• Ada95 SoC
• Packages, Subprograms,
• Tagged Types, Protected Types, Tasks

4
Crosscutting Concerns

• Certain properties cannot be localized in single
  modular units, but their implementation cuts
  across the decomposition hierarchy of the system.
• These properties are called crosscutting
  concerns, or aspects.
• Concern (Requirement)
• Functional
• Non-functional
• Design
• Crosscutting Concern
• A concern that is implemented in more than one
  location
• security, logging, synchronization, fault
  tolerance, design by contract

5
Initial Picture of Crosscutting
Constantinides
6
CORBA Servant Implementation
procedure Do_Some(Self in out Object Data in
Data_t) is begin ? Tracer.Enter(Self.TraceId,
Do_Some) ? Mutex.Lock(Self.Lock) ....
-- Do business-logic --(Also invoking methods
across CORBA) .... ?Fault_Tolerance.Log_State(
Make_Stream(Data)) ?Mutex.Unlock(Self.Lock)
?Tracer.Exit(Self.TraceId, Do_Some) exception
?when event others gt ? Mutex.Unlock(Self.Loc
k) ? Error_Logger.Log_Error(event, Unknown
Exception in Do_Some) end Do_Some
7
Crosscutting identification
procedure Do_Some(Self in out Object Data in
Data_t) is begin ? Tracer.Enter(Self.TraceId,
Do_Some) ? Mutex.Lock(Self.Lock) ....
-- Do business-logic --(Also invoking methods
across CORBA) .... ?Fault_Tolerance.Log_State(
Make_Stream(Data)) ?Mutex.Unlock(Self.Lock)
?Tracer.Exit(Self.TraceId, Do_Some) exception
?when event others gt ? Mutex.Unlock(Self.Loc
k) ? Error_Logger.Log_Error(event, Unknown
Exception in Do_Some) end Do_Some
8
Symptoms of Crosscutting

• Crosscutting imposes two symptoms on software
  development
• Code scattering implementation of some concerns
  not well modularized but cuts across the
  decomposition hierarchy of the system.
• Code tangling a module may contain
  implementation elements (code) for various
  concerns.
• Problems
• Low cohesion
• Strong coupling
• Low reusability, adaptability
• Difficult comprehensibility

9
AOP Version
procedure Do_Some(Self in out Object Data in
Data_t) is begin -- Do business-logic
--(Also invoking methods across CORBA) end
Do_Some

• Aspects
• Tracer
• Mutex
• FT State
• Exception handling
• Composition rules
• Rules for inserting aspect behavior to components

10

• AOP Programming Model

11
Aspect Oriented Programming

• AOP Complementary to OOP as OOP was to procedural
  programming
• Also applicable to procedural programming
• Aspect Languages extends traditional programming
  languages
• Abstractions for representing crosscutting
  concerns (Aspects)
• Composition of Aspects and traditional modules
  (Weaving)
• Improves modularity, adaptability, traceability
• AspectJ Dominant AOP language extension for
  Java
• AspectAda Our Proposal to extend Ada95
• Influenced by AspectJ

12
Joinpoint

• Well defined instant in the execution of a
  program
• Subprogram execution
• Finalization, Initialization, Adjust (Controlled
  Types)
• Variable access (Object declarations)
• Package body statement block
• Named block statements
• Named loop statements
• Rendezvous/Entry points

procedure Do_Some(Self in out M_Object Data
in Data_t) is ... begin ... end Do_Some
13
Pointcuts

• Set of joinpoints (object declaration)
• Pointcut expression (AspectJ Influenced)
• Primitive pointcuts
• Call
• Execution
• Get/Set of variables
• Wildcard matching (, ..)
• Composition using and, or, xor, not
• When a pointcut is matched, an advice can be
  executed

My_PC Pointcut execution Some_Pk.Do_
(in out M_Object ..) or execution
Some_Pk.Set_ (in out M_Object ..)
14
Advice

• Code module (as a subprogram) that attaches to a
  pointcut
• Injects behavior at all joinpoints selected by
  that pointcut
• Three types
• Before (code injected before the joinpoint)
• After (code injected after the joinpoint)
• Around (code injected around (in place of) code
  from joinpoint

advice Around(Mutex_A in out Mutex_Aspect)
is begin Mutex_A.Mutex.Lock Proceed
Mutex_A.Mutex.Unlock when others gt
Mutex_A.Mutex.Unlock raise end Around
15
Aspect

• A modular unit of crosscutting behavior
• Advice type (tagged)
• Simple (Performance)
• Detailed (Contextual information)
• Advice(s) bound to pointcut(s) (Advice clause)
• Like a package can have subprograms, types ...
• Parameterized to bind to one or more pointcut(s)

generic Mutex_P Pointcut aspect
Mutex_Aspects is type Mutex_Aspect is new
Simple_Aspect with record Mutex
Mutex_t end Mutex_Aspect advice
Around..... for AroundAdvice use Mutex_P end
Mutex_Aspects
16

• Logging Example

17
AOP Tracing Example Aspect Spec
with AspectAda generic Tracer_P
Pointcut aspect Tracer is type Tracer_Aspect
is new Aspect_Ada.Detailed_Aspect with null
record advice Before(Tracer in
Tracer_Aspect) for BeforePointcut use
Tracer_P advice After(Tracer in
Tracer_Aspect) for AfterPointcut use
Tracer_P end Tracer
18
AOP Tracing Example Aspect Body
with Ada.Text_IO use Ada.Text_IO with
Aspect_Ada use Aspect_Ada aspect body Tracer
is advice Before(Tracer in Tracer_Aspect)
is begin Put_Line(gt
Image(Get_Join_Point(Tracer).all)) end
Before advice After(Tracer in
Tracer_Aspect) is begin Put_Line(lt
Image(Get_Join_Point(Tracer).all)) end
After end Tracer
19
AOP Tracing Example Composition Rules
with Tracer use Tracer weaver CMS_Proto is
Gun_Control_All_PC Pointcut execution
Gun.(..) aspect Gun_Control_Logger is
new Tracer_Aspect(Tracer_P gt Gun_All_PC) end
CMS_Proto
20

• AspectAda Prototype Architecture

21
AspectAda Architecture Conceptual View
Hofmeister Notation
22
Weaver Prototype Modular View

• ASIS Based (Ada95)
• AdaGOOP (Aspects, Pointcuts)
• Ada.Containers
• Easy to adapt to Ada2005

23

• Effects on SW Quality

24
Effects on SW Quality

• Cohesion
• One concern in Ada95 module
• Crosscutting concerns modularized in aspects
• Coupling
• Minimal coupling modeled using pointcut
  expressions
• Reversed dependency direction
• Adaptability
• Code comprehensibility
• Tradeoff
• Traceability

25
Future Work

• Extended joinpoint model
• Call, Set/Get
• Named blocks, named loops
• Export of context at Joinpoints (objects,
  arguments)
• Extend GPS Plugin (GNAT Programming System)
• Joinpoint model and Ada generics
• Increased Aspect reusability
• Design by contract support
• Open for suggestions

26
Conclusion

• Crosscutting concerns
• Joinpoint model (joinpoints, pointcuts, advices,
  aspects)
• Tracing using AspectAda
• AspectAda Prototype Architecture
• Effects on SW Quality
• Future Work

27
End
www.cs.concordia.ca/cc/research knuthp_at_gmail.com
