Lab3: Network Traces Analysis

1
Lab3 Network Traces Analysis
2
Overview

• Network packets are logged for
• Network monitor
• Protocol debugging
• Troubleshooting
• Attackers often peer into the packets
• Many protocols are in clear-text (e.g., ftp,
  http)
• Easy to get packet traces (sniffing)
• Packet traces contain sensitive information
• Do offline analysis on given packet traces,
  extracting sensitive information

3
Task 1 Extract FTP Passwords

• FTP communication is not encrypted
• Goal recover all the username and password of
  ftp accounts from a network trace file
• Assumptions
• FTP server is using port 21
• No protocols other than FTP is running on port 21

4
Task 2 Extract HTTP URLs

• HTTP traffic is not encrypted
• Goal find out all the URLs the browser has
  visited in the network trace file
• Assumptions
• The HTTP sever is using port 80
• No protocol other than HTTP is running on port 80
• During the protocol, neither the server not the
  client gets disconnected

5
Task 3 Extract HTTP cookies

• Cookies are transmitted in clear-text
• May contain sensitive information
• Goal to extract all cookies contained in the
  network trace file
• Same assumptions as that for task 2
• Make it easier
• Only extract the cookies sent out by the browser
  dont extract the cookies sent by the server
• Dont worry about the domain and path
  attributes

6
Implementation

• All the functionalities will be implemented in a
  single executable
• The stub code and the make file are provided
• Read the instruction in the lab handout carefully
  about how to use the stub code

7
Testing Grading

• 6 out of 8 trace files used in grading are
  provided
• Some sample output are also provided
• Strictly follow the output format requirements
  given in the handout
• Make sure your outputs are exactly the same as
  the sample outputs
• See the readme file for information about the
  samples
• Note the program should only output to the
  standard output
• Do not print any debugging information

8
Hints

• Keywords
• FTP Password USER, PASS
• HTTP URLs GET, Host
• HTTP Cookies Host, Cookie
• Backup code often

9
Useful Tools

• The traces are generated using tcpdump
• You should use the tool tcpflow to filter and
  convert the trace file to ease the analysis and
  debugging
• See the summary function in the stub file as an
  example
• grep
• Find a match in the file
• See the man page for grep
• A function to invoke a command and get back the
  results is provided in the stub file

10
Readings

• FTP rfc959
• Section 4.1.1 ACCESS CONTROL COMMAND
• HTTP rfc2616
• Section 9.3 GET method
• Section 14.23 Host header field
• HTTP Cookies rfc2965
• Section 3.3.4 sending cookies
• A general understanding of the protocol will help

11
Turnin

• Only need to turnin the source code and the make
  file
• Turnin instruction will be sent to the
  mailing-list later

12

• Have fun!
• Questions?
