Camera Based Document Image Analysis

1
Camera Based Document Image Analysis

• David Doermann
• University of Maryland, College Park

2
What defines the problem?

• Traditional Document Analysis
• Deals primarily with paper representations
• Acquired with flatbed or sheetfed scanners
• Camera Based Analysis
• Clearly defined by the acquisition device, its
  properties, the impacts of it use, etc. but
• The devices open up a wide range of new and
  interesting applications (and problems) and
  extends what we may consider document analysis.

3
Scanner Acquisition

• Advantages
• Reasonable quality
• Controlled lighting, high resolution, fixed
  imaging plane
• Rapid Acquisition
• Relatively cheap
• Disadvantages
• Specialized Device
• Fixed Documents must come to device
• Requires handing of documents or documents in a
  sheet form for feeders

4
Book Camera/Scanner Acquisition

• One step removed from traditional scanners
• Controlled environment lighting, image plane,
  orientation
• Changes the nature of the content
• Easier to image atypical documents
• R are, Historic, fragile
• Often very expensive
• Can be relatively slow
• sheet scanners are hundreds of pages per minute
• although robotic cameras can image 10s of pages
  a minute.

5
Industrial Cameras

• Removes the constraints on configuration
• Often still in a controlled environment
• Custom (and expensive) solutions are common
• Processing power bounded only by cost
• Usage
• Postal applications, document inspection
  (newspapers, etc), industrial applications

6
(Portable) Digital Cameras

• Provide a much greater flexibility then scanners
• Multiple uses
• Devices goes to documents
• Potentially removes the bottleneck of acquisition
  for simple tasks
• fewer constraints (Lighting, image plane,
  focus,)
• increases complexity of resulting image and
  image processing
• yet allows a wider variation of applications
• A significant tradeoff

7
A broader view of a document?

• Conceptually
• The realization of a visual language for
  communicating information, typically meant for
  human consumption
• Practically
• Text, graphics, drawings, symbologies,
• Properties
• Exists over both space and time
• Relatively easy to produce
• Intended by the author to be read.

8
Roadmap

• Discussion of some key related research and
  applications of non-scanner DIA
• Influences of mobile devices on applications
• Issues with processing traditional documents vs
  processing text
• Future of camera based capture.
• Open issues
• New opportunities

9
What has been done?

• Applications primarily centered on Image Text
• Text in Video Graphics
• Text from WWW pages
• Text in Scenes
• Some work on key challenges
• Imaging of text in controlled environments such
  as parking lots, meeting rooms, assembly lines,
  etc
• Limited work on actually processing traditional
  documents.

10
Video Text Recognition

• Indexing content from graphic or scene text in
  videos used to supplement speech, closed
  captions,
• Countless papers published
• Challenges are well known
• Low Resolution, Complex background, Different
  font style and size, Lighting, Camera motion,
  Text/Object motion, Occlusion/distortion, all
  magnified for scene text
• Benefits of multiple frames, repeated content

11
WWW Text Image Analysis

• Applications
• Identifying graphic text for indexing and
  retrieval
• Identification of SPAM email in attachments
• Uncovering hidden information.
• Issues
• Text style variations (font, font style,
  orientation).
• Text Quality (Color, Size, Anti-aliasing)
• Image resolution

12
Visual Input

• Applications
• General input for computer systems
• Passive verification of signatures from cameras
  mounted over the writing surface
• Has general implications for mobile devices that
  dont have traditional keyboard input
• Challenges
• Pen tip tracking
• Identifying the temporal relations
• Online recognition

13
Whiteboard Reading

• Reading handwritten and printed material for
  meeting scenarios
• Challenges
• Must deal with unconstrained handwriting
• Distinguish text from graphics and sketches
• Parse and Interpret graphics (electronic ink)
• Content can appear and disappear dynamically
  produced

14
Meeting and Lecture Processing

• Meetings
• Reading name plates and tags
• Identifying and linking references to documents
• Processing whiteboards
• Lectures
• Reading text on projected presentations
• Detection, normalization and matching of text
  with source content (PowerPoint)
• Challenges
• Variable content
• Animations

15
License Plate Reading

• Applications
• Parking lot tracking
• Red-light and Speed Camera
• Vehicle Surveillance
• Challenges
• Moving Vehicles
• Complex plates
• Night and all weather imaging
• Limited use of context

16
Road Sign Recognition

• Applications
• Driver Assisted Systems, Automated Mapping, Sign
  guideline enforcement (location, quality)
• Challenges
• Low resolution, motion blur
• Real-time systems
• Detecting signs under a variety of conditions

17
Sign Recognition and Translation

• Application Integrated identification,
  recognition and translation text found on
  foreign signs, maps, menus, transportation
  schedules, etc
• Extremely useful for other character sets
• Primarily PDA or Mobile Phone Based Hardware
• Networked or Standalone solutions have are being
  marketed
• Ultimately software solutions are desirable.

18
Systems for the Visually Impaired

• Allows legally blind consumers access to a
  variety of information sources
• Transportation, shopping,
• System builds end to end application of
  detection, enhancement, recognition and speech
  transcription

A. Zandifar, A. Chahine, R. Duraiswami and L.S.
Davis, A Video-based interface to textual
information for the visually
impaired , IEEE Computer Society ICMI 2002, pp
325-330.
19
Commonalities

• Most of these systems can be/have been engineered
  and with the right constraints more are
  technically feasible but perhaps not cost
  effective.
• But what is the catalyst that will promote more
  general applications?
• Mobile devices and wireless networking are
  providing a platform which no longer requires
  special hardware

20
Mobile Devices

• Examples PDAs, Digital Cameras, Cellular Phones
• Devices are becoming common and pervasive
• They are becoming increasingly powerful
  (processor, memory, power, resolution)
• G3 networks promise multimedia support
• They are easy to use
• Devices go to the documents
• Rapid and Flexible Acquisition
• Acquisition becomes just another application of
  the device

21
How do they compare? (subjectively)

• Scanner Camera
• Resolution Adequate(?) Improving
• 150-600dpi
• Distortion Minimal Lens/Perspective
• Lighting Controlled Sensor and
• Environment
• Background Domain Often Complex
• Dependent
• Zoom/Focus N/A Variable
• Blur N/A Motion, focus
• Noise Minimal Sensor

22
Are Digital Cameras being used for text?

• Yes.
• Active capture of information sources Paris 03
• Note taking during presentations ICDAR 03
• Japan Signs prohibit the use of digital cameras
  in bookstores! They are being used as portable
  photocopiers.
• How about hardcopy documents?
• Falcon MT system currently testing high
  resolution cameras for input to standard OCR
  systems
• What are the challenges of imaging traditional
  documents?

23
Resolution and Large Documents

• Related Work
• Super-resolution
• Irani (1991), Patti (1997), Capel (2000), Fekri
  (2000)
• Mosaicing
• Taylor (1997, 1999), Mirmehdi (2001),
• State of the Art
• Digital Cameras gt 6 megapixels (can provide
  effective 300dpi)
• PDAs gt 1.3 megapixels
• Mobile Phones 1 megapixel
• But better cameras are on the way.
• (4 megapixels phones by 2005)

24
Blur from Focus/Depth of Field

• The imaging plane may not be parallel documents
  resulting in increased blur
• Frequency domain strategy
• Tsai (1984), Tom (1994), Kim (1990, 1993),
• Iterative solution
• Stark (1989), Tekalp (1992), Irani (1991),
• Bayesian methods
• Schultz (1994, 1995),

25
Lighting

• Natural lighting can be uneven
• Providing lighting can be challenging
• Lighting correction
• Global brightness / contrast
• Uneven brightness
• Adaptive thresholding
• Too many to list

26
Motion Blur

• Controlled with adequate lighting and shutter
  speed

27
Warping and Perspective Distortion

• Completely arbitrary viewing angles may not be
  realistic however.
• Remove perspective distortion of plane document
  pages
• Clark (2000, 2001),
• Unwarp curl pages using 3D shape
• Brown (2001), Pilu (2001),

28

• imaging plane is not guaranteed to be smooth
• But we simply enhance results and use existing
  tools?

29
For controlled imaging.
From scanner 300 dpi
From camera 200 dpi
30
Commercial OCR

• OCR is almost identical.

From scanner
From camera
31
More Typical Example
32
OCR Result
33
Simple Rectification
Original
Rectified
34
Better OCR Results
Original
Rectified
35
Simple Unwarping

• Text line straightening
• Unwarping book-spine type deformation

36
Curved Surface
37
OCR Result
t(,_.t catcgo'r'jZ(tN071 Cap("rinI,ClLt c'. et
,io-r1. "i,,tO 1 fl classes A hdd 10 zr
for n.tc goriz r (l f n(,-l'(Lll fSet '
illi111t of t11-'1epo7't 011, OUT
eaPc?'i,rn.ets ), 'J1r n ij11111/iii'
c(ItPy..i,(Lt-io?L of optically jfl address
the 1111119 l1fs' . the of feCts OCR errors
ifl(Ly )LL v(" Olt 11Et1t qI.d-at197,,Sionahi,
ty red ction. (Lnd c,teynr.izfL_ iTII1i d t, 1
eprt on 'uvaqs that cateyvri.zatiorf, Iff l.
f o recti,orL and rctrie11al cf
fectVCflF,ss. f11f1, help f,foJ _iiiCtion
38
Rough Text Extraction
Original
Edge Areas
Text Areas
Threshold Surface
39
Local Direction Detection
40
Cylindrical Model
41
Text Line Tracing
42
Straightened Text Lines
43
OCR Result

• 4 successful text categorizataon, capcri'raent
  divides
• tcrtual collection into pre-defined clu,.sses. A
  true
• ,lirrgtsentatzve for eachh class is generally
  obtained
• tiiryttg training of the ca.tcgorzzer.
• jri this paper, Yale report on oa.r
  caperiro.erats o-n,
• t,pivtrtg and categorization of optically
  recognized
• (pr tartaerrts. In partzctalar. ure in'll address
  the is-
• ,ie,s regarding the of fcct.s OCR, cr-ror.s m ay
  have on
• 10itaing. dirraensionality reduction, gnd
  categoriza_
• tip. lire further report on ways that,
  categorization
• pla,Uhelp error correctlor( and retrieval
  effectiveness.

44
Line Extraction

• Using Extrapolation with overlapping direction
  estimates

45
Improved OCR Result

• A successful text categorization experiment
  divides
• textual collection into pre-defined. classes. A
  true
• presentative for each class is generally
  obtained
• ing training of the categorizer.
• In this paper, we report on our experiments on
• joining and categorization of optically
  recognized
• pcuments. In particular, we will address the is-
• oes regarding the effects OCR errors may have on
• joining, dimensionality reduction, and
  categoriza-
• hon. We further- report on ways that
  categorization
• moy help error correction and retrieval
  effectiveness.

46
Open Questions

• Are existing tools good enough?
• Can we simply enhance the images
• or do we need to develop new tools.
• or new constraints?
• Can we make use of degradation knowledge?
• apply constraints from clear parts of the
  document to recognize similar text blurred by
  perspective?

47

• Will such devices replace scanners? No
• Will they open up the market to new applications?

• They already have
• Integrated Information Services
• Map locations
• Tourist information
• Promise of DIA on text captured with digital
  camera (business cards, nametags, pages of notes,
  )
• Grand Challenges
• Image Quality
• Immediate feedback for processability
• Moving processing to the device
• Killer Applications

48
MyLifeLog

• Record and Index anything and everything
• Text from everywhere you have been
• Identification of every document you have ever
  looked at (not necessarily read)
• Recall of everything you have ever written
• Is it possible?

49
IJDAR Special Issue

• Special Issue on Camera Based Text and Document
  Recognition
• Papers Due November 2003
• http//ijdar.cfar.umd.edu/special_issues/TD-SI.htm
  l
