Spatially Distributed 3D Circuit Models

1
Spatially Distributed3D Circuit Models

• Michael Beattie Electronic Design Automation
• Hui Zheng Austin Research Lab
• Anirudh Devgan Austin Research Lab
• Byron Krauter Electronic Design Automation
• IBM Corporation Austin, Texas

2
Background

3
Conventional BEM Extraction

• Starts with dense potential matrices with spatial
  information
• Vector potential integrals for inductance
  extraction
• Scalar potentials for capacitance extraction
• Solves for net behavior (net capacitance loop
  inductance) while strictly obeying Kirchhoffs
  laws static behavior
• Produces small dense models
• Loses spatial information

Capacitance Extraction
Inductance Extraction
0 V
4
Inverse Inductance Extraction

• Differs from conventional BEM extractionby
  generating segment, not net properties
• Starts with dense partial inductance matrices
• Inverts truncates matrices irrespective of net
  KCL
• Equivalent to applying loop potentials across
  segment lengths
• Easily truncated as L-1 drops off fast due to
  shielding effects
• Produces large, sparse models with spatial
  information

0 V
Inverse Inductance Extraction Loop Potentials
for Single Segment Extraction
1 V
0 V
0 V
0 V
0 V
0 V
0 V
5
Distributed BEM Capacitance Extraction

6
Distributed BEM Capacitance Extraction

• Similar to inverse inductance extraction
• Derives segment, not net couplings
• Violates static conditions by considering
  discontinuous surface potentials
• Windowed extraction
• Highly parallelizable
• Produces spatially distributed coupling models
• segment-to-segment couplings
• no distribution heuristics

7
Distributed Extraction not likeRegular BEM
Capacitance Extraction

• Discontinuous surface potentials(ground all but
  one segment)
• Locally solve for each segment
• Coarse panels are sufficient for remote segments
• Yields spatially distributed C model with self
  coupling terms
• Segment length depends on time step / accuracy

8
Spatially Distributed 3D Circuit Models

9
Spatially Distributed 3D Circuit Models

• Two step discretization process
• Segment lengthsbased on circuit speeds
• Segment panel / filament sizesbased on
  extraction accuracy
• Power planes require separate Lx , Ly C
  segments
• Extract for all segments
• Inverse inductances
• Distributed segment capacitance
• Combine netlists simulate
• Skin effect can be modeled with RL-1 Foster
  filters

10
Simulation Efficiency

• Sparse L-1 matrix densities is less thanfor
  comparable sparse partial inductance modelsfor
  similar simulation accuracy
• Linear circuits can be solved via nodal analysis
  when using only L-1 models and current sources
• Nodal analysis circuit equations are symmetric
  positive definite
• These equations can be solvedvia more efficient
  Cholesky factorization

11
L-1 based Transient Simulation

• Inner-loop Linear System (BE)
• Clock tree/mesh with 1.8 million elements(no
  couplings)

12
Adaptive Gridding

• Extract coupling from specific central segmentto
  all segments within a given distance (window)
• Discretize surfaces of segments finer, the closer
  they are to the central segment (adaptive
  gridding)
• Small impact on accuracy due to shielding
• Faster extraction compared to uniform gridding

13
How L-1 Differs from Capacitance

• Conductors split into segments for simulation
  accuracy
• Segments in turn split into panels for extraction
  accuracy
• BEM capacitance extraction coalesces
  charges(non-directionally)
• C AT(P) -1 A
• Capacitance matrix is diagonally dominantwith
  negative off-diagonals
• Proof based on all surface potentials being 1 or
  0 Volts,Gauss Law harmonic functions being
  extreme at their boundaries

14
Serial and Parallel Filaments

• Inductance filaments have a direction circuit
  topology
• L-1 coalescing differentiates between parallel
  (admittance) and serial (impedance) filaments
• L-1 (AsT(ApT(L) -1 Ap)-1As)-1
• L-1 not always diagonally dominantand can have
  positive off-diagonals
• Diagonal dominance proof used for C breaks down
  because vector potentials on surface are not 1 or
  0,but length integrals of vector potential are 1
  or 0

15
High-Frequency L-1 Models

• Use Foster RL-1 filters to modelimpedance
  frequency dependence
• Model skin effect in individual segments

16
Signal Integrity Analysis

17
Chip / Board Approximation

• Common all power supplies add chip board
  planes to allegro extract file
• Initial Shapes Processing
• merge eliminate overlapping shapes
• discretize lines planes
• create node numbers
• prune out smallest shapes

18
Signal Integrity Flow
pin-to-node correlation data
layout data
shape process
shapes data
technology data
shape-to-node correlation data
sparse L-1 C matrices
block process
full package extract neighbor list build
blocks for parallel extraction
neighborlist
19
Signal Integrity Flow (contd)
neighbor list
sparse L-1 C matrices
channel shapes processing
netlist build
linear simulation
signal integrity channels for parallel simulation
results
chip, board, analysis reporting instructions
20
Boundary Conditions

• - Linear analysis with 50 W Norton driver models
• - All chip supplies shorted all board supplies
  shorted
• - Near and far end termination with Zo50 W
• - Single point ground model -gt local
  differential measurements
• Apply
• Saturated ramp to find far end and saturated near
  end noise
• Triangular pulse to create time domain scattering
  models

21
Sample Signal Integrity Analysis

• Allegro Layout (Victim Net Highlighted)

22
Layers Above / Below
Layer Above
Layer Below
23
Discretized Ground Planes
Shapes All Levels Displayed
24
Near / Far End Noise
25
TDR Measurement / Simulation
1 Volt ramps with 40 ps rise time
In simulation, transmission lines are modeledas
equivalent L-1 C networks.
26
Measured Differential TDR
From this data the Differential transmission
line characteristic impedance is from 92 Ohms to
108 Ohms.
27
Simulated Differential TDR
28
Calibration to 2D Analysis
PATS Layout
EIP Cross Section
29
Comparison with EIP

• EIP PATS Units
• C11 1.3770 1.3887 pF/cm
• C12 0.2313 0.2217 pF/cm
• L11 2.910 3.262 nH/cm
• L12 0.488 0.548 nH/cm
• Z0 46.0 48.5 Ohms
• td 63.3 66.1 ps/cm

30
Near / Far End Responses
31
Summary

• Inverse Inductance allows for very efficient
  modeling and simulation of complex 3d
  interconnect
• Segment-to-segment capacitance captures spatial
  distribution more accurately than net-by-net
  models
• L-1 and C similar, but fundamental
  differencesdue to KCL and directionality of
  magnetic field
• Segment-based capacitance and inverse inductance
  interconnect models allow for windowed extraction
  and huge speed-ups through extract
  parallelization
• Signal integrity analysis parallelizablethrough
  channel modeling
