Huffman Encoding

1
Huffman Encoding
2
Entropy

• Entropy is a measure of information content the
  number of bits actually required to store data.
• Entropy is sometimes called a measure of surprise
• A highly predictable sequence contains little
  actual information
• Example 11011011011011011011011011 (whats
  next?)
• Example I didnt win the lottery this week
• A completely unpredictable sequence of n bits
  contains n bits of information
• Example 01000001110110011010010000 (whats
  next?)
• Example I just won 10 million in the
  lottery!!!!
• Note that nothing says the information has to
  have any meaning (whatever that is)

3
Actual information content

• A partially predictable sequence of n bits
  carries less than n bits of information
• Example 1 111110101111111100101111101100
• Blocks of 3 111110101111111100101111101100
• Example 2 101111011111110111111011111100
• Unequal probabilities p(1) 0.75, p(0) 0.25
• Example 3 "We, the people, in order to form
  a..."
• Unequal character probabilities e and t are
  common, j and q are uncommon
• Example 4 we, the, people, in, order, to,
  ...
• Unequal word probabilities the is very common

4
Fixed and variable bit widths

• To encode English text, we need 26 lower case
  letters, 26 upper case letters, and a handful of
  punctuation
• We can get by with 64 characters (6 bits) in all
• Each character is therefore 6 bits wide
• We can do better, provided
• Some characters are more frequent than others
• Characters may be different bit widths, so that
  for example, e use only one or two bits, while x
  uses several
• We have a way of decoding the bit stream
• Must tell where each character begins and ends

5
Example Huffman encoding

• A 0B 100C 1010D 1011R 11
• ABRACADABRA 01001101010010110100110
• This is eleven letters in 23 bits
• A fixed-width encoding would require 3 bits for
  five different letters, or 33 bits for 11 letters
• Notice that the encoded bit string can be decoded!

6
Why it works

• In this example, A was the most common letter
• In ABRACADABRA
• 5 As code for A is 1 bit long
• 2 Rs code for R is 2 bits long
• 2 Bs code for B is 3 bits long
• 1 C code for C is 4 bits long
• 1 D code for D is 4 bits long

7
Creating a Huffman encoding

• For each encoding unit (letter, in this example),
  associate a frequency (number of times it occurs)
• You can also use a percentage or a probability
• Create a binary tree whose children are the
  encoding units with the smallest frequencies
• The frequency of the root is the sum of the
  frequencies of the leaves
• Repeat this procedure until all the encoding
  units are in the binary tree

8
Example, step I

• Assume that relative frequencies are
• A 40
• B 20
• C 10
• D 10
• R 20
• (I chose simpler numbers than the real
  frequencies)
• Smallest number are 10 and 10 (C and D), so
  connect those

9
Example, step II

• C and D have already been used, and the new node
  above them (call it CD) has value 20
• The smallest values are B, CD, and R, all of
  which have value 20
• Connect any two of these

10
Example, step III

• The smallest values is R, while A and BCD all
  have value 40
• Connect R to either of the others

11
Example, step IV

• Connect the final two nodes

12
Example, step V

• Assign 0 to left branches, 1 to right branches
• Each encoding is a path from the root

• A 0B 100C 1010D 1011R 11
• Each path terminates at a leaf
• Do you see why encoded strings are decodable?

13
Unique prefix property

• A 0B 100C 1010D 1011R 11
• No bit string is a prefix of any other bit string
• For example, if we added E01, then A (0) would
  be a prefix of E
• Similarly, if we added F10, then it would be a
  prefix of three other encodings (B100, C1010,
  and D1011)
• The unique prefix property holds because, in a
  binary tree, a leaf is not on a path to any other
  node

14
Practical considerations

• It is not practical to create a Huffman encoding
  for a single short string, such as ABRACADABRA
• To decode it, you would need the code table
• If you include the code table in the entire
  message, the whole thing is bigger than just the
  ASCII message
• Huffman encoding is practical if
• The encoded string is large relative to the code
  table, OR
• We agree on the code table beforehand
• For example, its easy to find a table of letter
  frequencies for English (or any other
  alphabet-based language)

15
About the example

• My example gave a nice, good-looking binary tree,
  with no lines crossing other lines
• Thats because I chose my example and numbers
  carefully
• If you do this for real data, you can expect your
  drawing will be a lot messierthats OK

16
Data compression

• Huffman encoding is a simple example of data
  compression representing data in fewer bits than
  it would otherwise need
• A more sophisticated method is GIF (Graphics
  Interchange Format) compression, for .gif files
• Another is JPEG (Joint Photographic Experts
  Group), for .jpg files
• Unlike the others, JPEG is lossyit loses
  information
• Generally OK for photographs (if you dont
  compress them too much), because decompression
  adds fake data very similiar to the original

17
The End
