Mineralogy

1
Mineralogy
Minerals and crystals
2
Worlds largest crystals A cave in the Naica
Lead Zinc mine, Mexico
3
Miners in Cueva de los Crystals the mineral
gypsum
Crystals of a variety of gypsum (CaSO4.2H2O)
precipitated from hot water at 60 degrees celsius
in a limestone cave in the Naica mine
4
Minerals
Tourmaline on Feldspar
Beryl (Be3Al2(SiO3)6
Emerald
5
Crystal Shapes
Quartz (SiO2)
Diamond (C)
Halite (NaCl)
Calcite (CaCO3)
Stibnite (Sb2S3)
Garnet (Fe3Al2Si3O12)
6
Pyrite (FeS2) crystals
7
Feldspars two of the most important
rock-forming minerals
Plagioclase
Albite NaAlSi3O8
Anorthite CaAl2Si2O8
K-feldspar
Sanidine
Orthoclase
Microcline
KAlSi3O8
8
Colours and forms of quartz
Citrine
Amethyst
Milky quartz
Rose quartz
9
Quartz crystals displaying prism and pyramid faces
10
Quartz Crystal
Pyramid
Faces display consistent angular relationships
Angles measured with a goniometer
Prism
11
Crystals have ordered arrangements of atoms
Order
Disorder
12
X-ray diffraction
X-ray beam splits into numerous smaller beams.
Interference of waves of different beams produces
a diffraction pattern on a screen or film. The
pattern indicates the spacing and arrangement of
atoms.
13
Atomic structure of galena (PbS)
Surface of galena (PbS) imaged With an atomic
force microscope
Sulphur
Lead
14
The atomic structure of halite (NaCl)
Ionic bonding
15
Ionic bonding transfer of electrons
Anion -
Cation
16
Relative sizes of ions
Ion co-ordination
17
The atomic structure of diamond
Covalent bonding
18
The source of Diamonds
The Big Hole at Kimberly, South Africa
Kimberlite containing diamond
19
Cutting diamonds
20
Covalent bonding sharing of electrons
21
Atomic structure of graphite
Covalent bonding within sheet
Van der Waals bonding between sheets
22
Ice Crystals
Hydrogen bonding
23
The silicon tetrahedron
24
Silicate Structures
Inosilicate
Inosilicate
Nesosilicate
(Single chain)
(Double chain)
SiO44 -
Si4O116 -
SiO32-
Sheet silicate
Framework silicate
Si4O104 -
SiO2
25
Nesosilicate
(Fe,Mg)2SiO4
Olivine
26
Inosilicate (Single Chain)
Diopside
Pyroxene
CaMgSi2O6
Hypersthene
(Fe,Mg)SiO3
27
Inosilicate (Double Chain)
Amphibole
Tremolite Ca2Mg5Si8O22(OH)2
Riebeckite Na2Fe5Si8O22(OH)2
Tigers Eye
28
Asbestos
Chrysotile (Mg3Si2O5(OH)4
Uses and risks
(Insulation, heat, fire resistance)
Serpentine (Mg3Si2O5(OH)4
29
Sheet Silicate
Biotite KAl(Fe,Mg)3Si3O10(OH)2
Muscovite KAl3Si3O10(OH)2
30
Framework Silicate
Quartz SiO2
Albite NaAlSi3O8
Plagioclase
Anorthite CaAl2Si2O8
Amethyst SiO2
K-feldspar KAlSi3O8
31
Relationship of Quartz structure to Feldspar
Structure
Imagine four SiO2 molecules 4 x SiO2 Si4O8
Substitute Al3 for Si4 in one of these molecules
Add Na or K to supply missing charge
NaAlSi3O8 or KAlSi3O8
Albite K-Feldspar
Add Ca2 to supply missing charge CaAl2Si2O8
Anorthite
