Presented by Doug Rothauser

1
Favor Composition Over Inheritance

• Presented by Doug Rothauser
• FCCI Insurance Group

2
Inheritance Drawbacks

• Inheritance imposes a tight coupling between
  parent class and its subclasses.
• The parent class / child class relationship is
  brittle. A change in the parent class could break
  its child classes even though there are no
  changes in the child classes.
• Inheritance exposes implementation details thus
  violating encapsulation.
• This presentation assumes implementation
  inheritance, not interface inheritance.

3
Inheritance Guidelines

• The decision to use inheritance should not be
  made lightly. The decision to use inheritance
  should be make on sound OO principles

• IS A Is the subclass indeed a type of parent
  class?
• In many cases IS A criteria isnt good enough
  to make this determination.

• Will the type hierarchy violate the Liskov
  Substitution Principle?

• Per Design by Contract
• Are the preconditions of an overridden method the
  same or weaker than that of the parent type?
• Are the postconditions the same or stronger?

• Is the base type designed and documented for
  inheritance?

• How volatile is the base type?

4
Liskov Substitution Principle

• If for each object o1 of type S there is an
  object o2 of type T such that for all programs P
  defined in terms of T, the behavior of P is
  unchanged when o1 is substituted for o2 then S is
  a subtype of T.
• o1 is an instance of a Subtype
• o2 is an instance of a Type
• P is the Type that defines the behavior the
  object it realizes.
• P should behave the same regardless of whether it
  realizes a Type (o2) or a Subtype (o1 ).
• Programmatically, a function or method using
  object of a base class should behave the same
  when it is made to use object of a class derived
  from the base class.
• LSP is an OOD guideline stressing the importance
  of behavior over data.
• Method overriding in derived classes is probably
  the biggest cause of LSP violations. Method
  overriding should be done with great impunity to
  avoid these violations.
• Overriding an implemented method violates the
  Dependency Inversion Principle (depend on
  abstractions, not implementations).

5
Design By Contract

• To help with designing classes that conform to
  the Liskov Substitution Principle, Design by
  Contract (DbC) concepts can be employed to help
  facilitate proper class inheritance.
• Preconditions define the minimum requirements
  that must be met before a method can execute.
• Postconditions define what conditions the method
  is obligated to satisfy.
• When applying Design By Contract to subclasses,
  DbC saysWhen redefining a routine in a
  derivative, you may only replace its
  precondition by a weaker one, and its
  postcondition by a stronger one.

6
Design By Contract

• When using an object (derived or base) through
  its base class interface
• The client must not require stronger
  preconditions on a method than the base class
  (i.e. there cannot be more preconditions than
  that required by the base class).
• A method of a derived class must satisfy at least
  the same post conditions as the base class (i.e.
  the derived class cannot support less
  postconditions than the base).

7
Favor Composition Over Inheritance

• Composition is often the better choice for
  extending and adding functionality to a
  structure.
• The Open Closed Principle can arguably be more
  effectively applied through composition than
  through inheritance.
• Open Closed Principle - A class should be open
  for extension, but closed for modification.
• Ideally, code should never have to be changed.
  New functionality can be added through
• Inheritance or in many cases
• Composition and Delegation!

8
Favor Composition over Inheritance

• Composition is the act of composing an object
  from other objects.
• Composition is expressed as a has-a or
  knows-a relationship.
• Types of composition
• Association One object uses another to perform
  some type of service (e.g. utility class).
• Aggregation Represents a whole/part relation.
  Aggregation implies that a complex object is
  composed of other objects (e.g. Account is
  composed of one or more policies).
• Notice that you could get composability by
  replacing inheritance with aggregation.

9
Aggregation
Aggregation is a form of association representing
a whole/part relationship between two classes.
Aggregation implies that the whole is at a
conceptually higher level than the part, whereas
an association implies both classes are at the
same conceptual level. An instance variable in
the whole holds a reference to the part(s). The
difference between association and aggregation is
entirely conceptual and is focused strictly on
semantics.
In an aggregation relationship, the part class
instance (tire) can outlive the whole class
(car). The relationship is represented with a
hollow diamond attached at the whole and an
arrow pointingto the part.
10
Composition
Composition is a special form of aggregation,
which implies the whole is responsible for the
lifecycle of the part. Composition is also
non-shared. So while the part doesn't necessarily
need to be destroyed when the whole is destroyed,
the whole is responsible for either keeping alive
or destroying the part. The part cannot be shared
with other wholes. The whole, however, can
transfer ownership to another object, which then
assumes lifetime responsibility.
The above trivial example shows that water is
composed of hydrogen and oxygen. The composition
relationship is represented with a solid diamond
attached at the whole and an arrow pointingto
the part.
11
Favor Composition over Inheritance Decorator
Pattern

• The Decorator pattern provides a common
  alternative to inheritance. Wrapper classes use
  the Decorator pattern.
• Decorator classes mirror the type of components
  they decorate.
• They are the same type as the components they
  decorate either through inheritance or
  implementation.
• The decorator holds an instance of the component
  it decorates. In other words, the decorator is
  composed of the object it decorates.
• Decorators are prevalent in many core Java
  packages e.g.
• Java.io.FilterInputStream (wraps InputStream)
• HttpServletResponseWrapper (wraps ServletResponse)

12
Favor Composition over Inheritance Decorator
Pattern

• Decorator classes mirror the type of components
  they decorate.
• They are the same type as the components they
  decorate either through inheritance or
  implementation.
• Decorators are transparent to the client
• The decorator holds an instance of the component
  it decorates. In other words, the decorator is
  composed of the object it decorates.

13
Favor Composition over Inheritance Decorator
Pattern

• Decorator Class Diagram

14
Favor Composition over Inheritance Decorator
Pattern

• A decorator can be used to add behavior to a
  stable class.
• For example, consider a Ftp utility class - the
  behavior of the file upload operation can be
  altered to encrypt the file before uploading.
• The decorator will hold an instance of the Ftp
  class and encryption behavior will be added to
  the upload method.

15
Decorator Pattern Example

• Decorator Class Diagram
• Applied to Ftp Filter Chain

16
Decorator Pattern Example
17
Decorator Chained Filter Construction
18
Decorator Chained Filter File Upload
19
Favor Composition over Inheritance

• Inheritance
• Pros
• Code sharing
• Cons
• Brittle
• Tight coupling between parent/child classes

• Composition
• Pros
• Evaluated at runtime (dynamic binding)
• Lightweight
• Flexible
• Cons
• Increased system complexity

Composition increases system flexibility. If we
use composition, we can extend an objects
behavior dynamically, at runtime, adding new
responsibilities to objects that we may not have
thought about during design time. Another benefit
of this technique is that we do not need to
change existing code, and so the chances of
introducing new bugs or unwanted effects are
reduced.
20
Thank You!
21
Object Oriented Design Principles

• Encapsulate what varies
• Favor composition over inheritance
• Program to interfaces, not implementations
• Strive for loosely coupled designs between
  objects that interact
• Classes should be open for extension but closed
  for modification
• The open/closed principle is the single most
  important guide for an object oriented designer.
  Designing modules whose behavior can be modified
  without making source code modifications to that
  module is what yields the benefits of OOD.
• Abstractions should not depend on details.
  Details should depend on abstractions (Dependency
  Inversion Principle)

22
Encapsulate What Varies

• Take what varies and encapsulate it so it wont
  affect the rest of your code.
• In other words, identify the aspects that vary
  and separate them from what stays the same.
• Results in fewer unintended consequences from
  code changes.
• Decouples components that change frequently from
  those that are relatively stable.
• Changes become much less limited in scope and
  arent as invasive.
• Engenders modularity and flexibility.

23
Encapsulate What VariesData Encapsulation

• Typical Example The JavaBean
• Define private members
• Encapsulate access to private members by creating
  accessors and mutators (getters and setters) .
• Eclipse provide a refactoring function to easily
  encapsulate class fields.

24
Encapsulate What VariesProcedural Encapsulation

• Identify what varies and hide it behind an
  interface Implementations of the interface can
  vary without violating the contract of the
  interface.
• This is the essence of the OO concept -
  Abstraction. Abstraction focuses on the
  outside view of an object and separates an
  objects behavior from its implementation.
• Dependency Inversion Principle - Abstractions
  should not depend on details. Details should
  depend on Abstractions.

25
Encapsulate What Varies

• The Encapsulate What Varies principle forms the
  basis for most design patterns. For example
• Factory - Code that creates objects is generally
  subject to frequent change. Use the Factory
  pattern to encapsulate object creation.
• State - The State pattern allows an object to
  vary its behavior when its internal state
  changes. Each state is generally encapsulated in
  its own class.
• Strategy - Encapsulates each algorithm in a
  family of algorithms so that they can vary for
  each client that uses them.

26
Questions?
