Exploring Solids

1
Section 12-1

• Exploring Solids

2
Polyhedron

• Three dimensional closed figure formed by joining
  three or more polygons at their side.
• Plural polyhedra

3
Parts of a Polyhedron
4

• Face Each polygon of the polyhedron
• Edge A line segment along which two faces meet
• Vertex A point where three or more edges meet

5
Regular polyhedron

• Has faces that are congruent regular polygons

Example
6
Convex Polyhedron

• If any two points on its surface can be connected
  by a segment that lies entirely inside or outside
  the polyhedron

7
Concave Polyhedron

• If the segment goes outside the polyhedron

8
Cross Section

• Intersection of a plane and a solid

9
A plane and a solids intersection forms
different shapes.
10
Examples of a Plane and a Cubes Cross Sections
Square
Trapezoid
Triangle
11
Example of a Plane and a Spheres Cross Section
Circle
12
Eulers Theorem

• The number of faces (F), vertices (V), and edges
  (E) of a polyhedron are related by the formula

13
Platonic Solids

• Five regular polyhedra

• Tetrahedron 4 faces
• Cube 6 faces
• Octahedron 8 faces
• Dodecahedron 12 faces
• Icosahedron 20 faces

14
Regular Tetrahedron
4
6
4
____ faces, ____ vertices, ____ edges
15
Cube
8
12
6
____ faces, ____ vertices, ____ edges
16
Regular Octahedron
6
12
8
____ faces, ____ vertices, ____ edges
17
Regular Dodecahedron
20
18
Regular Icosahedron
30
