Introduction to Oracle Spatial Using Public Data

1
Introduction to Oracle Spatial Using Public Data

• Richard L. Flores
• Isinglass, Inc.
• pleides100_at_yahoo.com

2
(No Transcript)
3
About Me

• Schooling in Geology and Business.
• 16 years working with Geographical Information
  Systems and Computer Mapping in the Oil Gas
  Industry.
• 15 years working with Oracle, mostly as DBA.
• Sporadic experience with Oracle Spatial since
  late Oracle 7.

4
Reading Material

• Clearly written with wonderful, downloadable
  examples for you to work through.
• Covers most features of Oracle Spatial.

5
Reading Material

• Wide ranging topics on the FREE acquisition of
  data and tools for the processing of geographic
  data.
• Great tips and insight on the field of Electronic
  Cartography.

6
Agenda

• Geographic Data Processing
• Cartography 101
• Oracle Spatial Products
• Oracle Spatial Basics by Example

7
Geographic Data ProcessingThe Processing Steps

• Data Acquisition
• Preliminary Data Processing
• Data Storage and Retrieval
• Graphical Display (Visualization), Analysis, and
  Interaction.

8
Geogaphic Data ProcessingData Acquisition

• Sources
• Global Positioning Systems (GPS)
• Published and Unpublished
• Free and Commercial
• Formats
• Vector shapefiles, DLG, DXF, NTF, etc.
• Raster TIFF, GIF, etc.

9
Geogaphic Data ProcessingPreliminary Data
Processing

• May Involve
• Digitization of paper maps
• Vectorization of raster images
• Transformation of Mapping Coordinates
• Geocoding calculation of geographic coordinates
  from street addresses.

10
Geogaphic Data ProcessingData Storage and
Retrieval

• For Oracle
• Storage
• Use of Oracles Geographic Data Model
• Database design for the integration of spatial
  and non-spatial data
• SQL and SQLLoader for loading data in Oracle.
• Oracles shapefile to SDO utility.
• Retrieval
• It all comes down to SQL using Oracle Spatial
  stored procedures.

11
Geogaphic Data ProcessingDisplay, Analysis, and
Interaction.

• Not many free programs that work with Oracle
  Spatial directly, unfortunately.
• Many commercial programs for displaying and
  interactively querying and editing Oracle Spatial
  data such as those from ESRI, Intergraph,
  MapInfo, Autodesk, eSpatial, and Acquis.

12
Cartography 101The Shape of the Earth Some Facts

• To accurately place a point on the earth, the
  general shape of the earth must be known. These
  shape models are called, datums.
• The earth is not flat.1
• The earth is not a perfect sphere.
• The earths general shape is best described by a
  theoretical surface called a geoid.
• For mapping, geoids are approximated by reference
  ellipsoids.

1
Assertions of the Flat Earth Society
notwithstanding.
13
Cartography 101 The Shape of the Earth North
American Datum

• Older maps used NAD27
• Newer maps use the more accurate NAD83 made using
  satellites and sophisticated electronic
  equipment.
• Worldwide GPS use a datum compatible to NAD83
  called WGS84
• The coordinates for a point on the earth can vary
  significantly depending on the datum used.

14
Cartography 101 Spatial Reference Systems

• SRS are coordinate-based systems used to locate
  geographical entities.
• Oracle Geographic SRS Types
• Geodetic Latitude Longitude
• Projected Coordinate Systems X Y where globe
  is mathematically projected onto a flat map.

15
Cartography 101Why are SRS important?

• During analysis, if all spatial data is not in
  the same Spatial Reference System, the geographic
  layers will not overlay and the analysis will be
  in error.

16
Cartography 101Why are SRS important?
17
Cartography 101Why are SRS important?

• During analysis, if an inappropriate Spatial
  Reference System is chosen, you may introduce
  unacceptable distortion into your maps.

18
Cartography 101Why are SRS important?

• If you were interested in using a map to measure
  land areas, you would probably not use this
  Spatial Reference System.

19
Cartography 101Geodetic Coordinate System

• Latitude/Longitude expressed in
  Degrees/Minutes/Seconds or Decimal Degrees
• Parallels Lines of latitude North () South
  (-) of Equator (-90 to 90)
• Meridians Lines of longitude East () West (-)
  of the Prime Meridian (-180 to 180)
• Oracle Uses Decimal Degrees in the odd order,
  Longitude/Latitude

20
Cartography 101Geodetic Coordinate System
21
Cartography 101 Projected Coordinate Systems
22
Cartography 101 State Plane Coordinate Systems

• Each state has defined SPCS zones which are
  popular for local- and state-sized areas because
  of their accuracy.
• Tall States, such as TX and CA use the Lambert
  Conformal Conic Projection.
• Wide States, such as NY use Transverse Mercator
  Projection.

California Zone III, 0403
Texas South Central Zone, 4204
23
Cartography 101 Projected Coordinate Systems

• Select map projection for display based on
• How you intend to use the data
• The size and location of the area of interest
• The metric property of the map you wish to
  preserve
• Shape
• Area
• Distance
• Direction
• Scale
• See erg.usgs.gov/isb/pubs/MapProjections/projectio
  ns.html

24
Oracle ProductsOracle Locator

• Includes
• Geographic Data Model
• Query and Analysis using the Index Engine
• Some advanced geometric functions
• Free with the Standard or Enterprise Edition

25
Oracle ProductsOracle Spatial Option

• Includes
• All Oracle Locator features
• More advanced spatial functions
• Location enabling geocoder
• Advanced features such as routing, network
  analysis, and georaster.
• Added-cost option with the Enterprise Edition

26
Oracle SpatialGeneral

• An integrated set of functions and procedures
  that enables spatial data to be stored, accessed,
  and analyzed quickly and efficiently in an Oracle
  database.
• A schema (MDSYS) that prescribes the storage,
  syntax, and semantics of supported geometric data
  types.
• A spatial indexing mechanism
• A set of operators and functions for performing
  area-of-interest queries, spatial join queries,
  and other spatial analyis operations.
• Administrative utilities.

27
Oracle SpatialSome Definitions

• The are other, more complex elements, including
  collections of one or more elements called
  Geometries.
• A Layer is collection of Geometries having
  similar attributes such a state boundaries,
  roads, or rivers.

28
Oracle SpatialMore on Geometries and Layers
Table, STATES LAYER
A GEOMETRY (outline) of a state is in a single
column of each row.
A GEOMETRY may contain more than one element.
29
Oracle Spatial by ExampleScenario

• You wish to open an upscale beauty salon in
  central Contra Costa county, California, catering
  to wealthier, older women.
• You would like to be close to a major
  thoroughfare for ease of access.
• You dont want to be too close to any competitors.

30
Oracle Spatial by ExampleIdentify Types and
Sources of Data Needed to Support Decision

• Competitors Internet Search Engine
• Demographic (Age, Gender, Income) U.S. Census
  Bureau
• Roads U.S. Geological Survey

31
Oracle Spatial by ExampleCompetitor Data Table
CREATE TABLE beauty (id
NUMBER(38), name
VARCHAR2(100), full_address
VARCHAR2(100), city_state
VARCHAR2(50),
street_number VARCHAR2(10),
street_name VARCHAR2(20),
street_type VARCHAR2(15),
street_prefix VARCHAR2(10),
street_suffix VARCHAR2(10),
city VARCHAR2(40),
state VARCHAR2(2),
postal_code VARCHAR2(16),
location MDSYS.SDO_GEOMETRY)
32
Oracle Spatial by ExampleCompetitor Data
Spatial Metadata
INSERT INTO user_sdo_geom_metadata VALUES
('BEAUTY', -- Geometry
Table 'LOCATION', --
Geometry Column SDO_DIM_ARRY (
SDO_DIM_ELEMENT ('LONGITUDE', -- Longitude
Text -180, --
Lower Boundary 180,
-- Upper Boundary
0.5), -- Tolerance
SDO_DIM_ELEMENT ('LATITUDE', -- Latitude
Text -90, --
Lower Boundary 90,
-- Upper Boundary
0.5) -- Tolerance ),
8307 -- (SRID)
DatumWGS84 )
33
Oracle Spatial by ExampleCompetitor Data
Spatial Index
CREATE INDEX beauty_spatial_idx ON beauty
(location) INDEXTYPE IS MDSYS.SPATIAL_INDEX

• R-Tree Index
• These are unlike regular Oracle indexes and
  special steps must be taken with their
  administration.

34
Oracle Spatial by ExampleCompetitor Data Source
Name ---------------- ID NAME FULL_ADDRESS
CITY_STATE STREET_NUMBER STREET_NAME
STREET_TYPE STREET_PREFIX STREET_SUFFIX CITY
STATE POSTAL_CODE LOCATION
Extract list of competitors and their addresses
from Search Engine.
While very useful, it doesnt provide any
directly mappable data.
35
Oracle Spatial by ExampleCompetitor Data
Geocoding

• The Geocoder will
• Standardize Address Name and,
• Using a database with the coordinates and street
  addresses of each intersection,
• Interpolate the location of the given address.
• Oracle Spatial Option geocoder added-cost
• Third party sells spatial database used to
  calculate the coordinates

36
Oracle Spatial by ExampleCompetitor Data
Geocoding
Solution Use Perl Program against internet
geocoding website.
!/usr/local/bin/perl simplest_xmlrpc.pl use
XMLRPCLite use DataDumper use strict use
warnings my where shift _at_ARGV or die
"Usage 0 \"1 Main St, Anytown, KS\"\n" my
result XMLRPCLite -gt proxy(
'http//rpc.geocoder.us/service/xmlrpc' ) -gt
geocode (where) -gt result print Dumper
result
From Mapping Hacks, Tips Tools for Electronic
Mapping
37
Oracle Spatial by ExampleCompetitor Data
Geocoding
simplest_xmlrpc.pl 1355 N. Main, Walnut Creek,
CA" VAR1 'number' gt '1355',
'street' gt 'Main', 'lat' gt
'37.898365', 'state' gt 'CA',
'city' gt 'Walnut Creek', 'zip' gt
'94596', 'suffix' gt '', 'long' gt
'-122.060445', 'type' gt 'St',
'prefix' gt 'N'
Name ---------------- ID NAME FULL_ADDRESS
CITY_STATE STREET_NUMBER STREET_NAME
STREET_TYPE STREET_PREFIX STREET_SUFFIX CITY
STATE POSTAL_CODE LOCATION
38
Oracle Spatial by ExampleCompetitor Data
SDO_GEOMETRY Object-Relational Type
UPDATE beauty SET location
SDO_GEOMETRY (2001, -- Geometry
Type 2-D Point 8307, --
SRID, Datum WGS84 SDO_POINT_TYPE
(-122.060445, -- Longitude
37.898365, -- Latitude NULL),
NULL, NULL )
WHERE id 430
39
Oracle Spatial by ExampleCompetitor Data Data
Display

• eSpatial iSmart Explorer free on OTN
• OEM Spatial Index Advisor
• Oracle Mapviewer
• For serious users, many commercial products.

40
Oracle Spatial by ExampleNon-Spatial Demographic
Data Table
CREATE TABLE census_data ( CENSUS_TRACT
VARCHAR2(10)NOT NULL, MED_HOUSE_INCOME
NUMBER(38), GENDER_TOTAL NUMBER(38),
FEMALE_GE_40 NUMBER(38))
41
Oracle Spatial by ExampleNon-Spatial Demographic
Data Source
42
Oracle Spatial by ExampleSpatial Census Tract
Data Source

• www.census.gov/geo/www/cob/tr_metadata.html
• Has geographic boundaries of Census Tracts which
  can be loaded into Oracle Spatial.
• Choose state and ARCVIEW Shapefile format to
  download file for California. These files are
  sometimes called ESRI Shapefiles.

43
Oracle Spatial by ExampleSpatial Census Tract
Data Pre-processing

• shp2sdo utility downloadable from Oracle will
  create SQL and SQLLoader data and control files
  for creating Spatial objects and loading
  shapefile data into Oracle Spatial.

Creates census_tracts.sql, census_tracts.ctl,
census_tracts.dat
44
Oracle Spatial by ExampleSpatial Census Tract
Data Loading census_tract.sql
DROP TABLE CENSUS_TRACTS CREATE TABLE
CENSUS_TRACTS ( AREA NUMBER,
PERIMETER NUMBER, TR06_D00_ NUMBER,
TR06_D00_I NUMBER, STATE
VARCHAR2(2), COUNTY VARCHAR2(3), TRACT
VARCHAR2(6), NAME
VARCHAR2(90), LSAD VARCHAR2(2),
LSAD_TRANS VARCHAR2(50), GEOM
MDSYS.SDO_GEOMETRY)
45
Oracle Spatial by ExampleSpatial Census Tract
Data Loading

• In SQLPlus
• connect spatial/spatial
• _at_census_tracts.sql
• Run SQLLoader
• sqlldr spatial/spatial census_tracts
• In SQLPlus
• connect spatial/spatial
• EXECUTE SDO_MIGRATE.TO_CURRENT(CENSUS_TRACTS,GE
  OM)

46
Oracle Spatial by ExampleSpatial Census Tract
Data Display

• Census tract outlines.
• You can CREATE TABLE SELECT AS on state06
  and county013 to get just Contra Costa county.

47
Oracle Spatial by ExampleRoad Data Source

• seamless.usgs.gov
• Bureau of Transportation Statistics from U.S.
  Geological Survey.
• shapefiles

48
Oracle Spatial by ExampleRoad Data Display
49
Oracle Spatial by ExampleAnalysis Criteria
Definition

• Within 2 miles of census tracts in which
• The Median Household Annual Income is greater
  then 100K and
• Over 30 of the people are women 40 years or
  older
• Within ½ mile of a major thoroughfare
• Not within ½ mile of a competitor

50
Oracle Spatial by ExampleAnalysis Oracle
Spatial Buffers
Original Geometry Buffered Geometry
Point
Line String
Polygon
51
Oracle Spatial by ExampleAnalysis Target Census
Tract Buffer
CREATE TABLE target_tract_buffer AS SELECT
SDO_AGGR_UNION(SDOAGGRTYPE(
SDOAGGRTYPE( SDO_GEOM.SDO_BUFFER(
a.geom, -- geometry column
2.00, -- Distance
0.5, 'arc_tolerance0.005 unitmile'),
-- Units 0.5)) geom FROM
census_tracts a, census_data b WHERE
b.census_tract a.name AND
b.med_house_income gt100000 AND
b.female_ge_40/b.gender_total gt 0.30 AND
a.state '06' AND
a.county '013'
52
Oracle Spatial by ExampleAnalysis Target Census
Tract Buffer
53
Oracle Spatial by ExampleAnalysis Target Census
Tract Buffer
54
Oracle Spatial by ExampleAnalysis Major Road
Buffer
CREATE TABLE road_buffer AS SELECT prefix, name,
type, suffix, SDO_AGGR_UNION(
SDOAGGRTYPE( SDO_GEOM.SDO_BUFFER(
a.geom, -- geometry
column 0.50, --
Distance 0.5,
'arc_tolerance0.005 unitmile'), -- Units
0.5)) geom FROM roads a WHERE (name
'ACALANES' AND type 'AVE') OR (name
'ACALANES' AND type 'RD')
OR (name 'YGNACIO VALLEY' AND
type 'RD')
55
Oracle Spatial by ExampleAnalysis Major Road
Buffer
56
Oracle Spatial by ExampleAnalysis Competitor
Buffer
57
Oracle Spatial by ExampleAnalysis Spatial
Operations
58
Oracle Spatial by ExampleAnalysis Spatial
Operations
CREATE TABLE target_site_wocomp AS SELECT
SDO_AGGR_UNION(SDOAGGRTYPE(c.geom,0.5)) geom
FROM (SELECT SDO_GEOM.SDO_INTERSECTION(
a.geom, b.geom, 0.5) geom FROM
target_tract_buffer a,road_buffer b)
c)
59
Oracle Spatial by ExampleAnalysis Spatial
Operations
CREATE TABLE target_site AS SELECT
SDO_AGGR_UNIION(SDOAGGRTYPE(a.geom,0.5)) geom
FROM (SELECT SDO_GEOM.SDO_DIFFERENCE(
b.geom, c.geom, 0.5) geom FROM
target_site_wocomp b,competitor_buffer
c) a -- Create spatial metadata and index for
target_site -- and target_site_wocomp after
creation.
60
Oracle Spatial by ExampleAnalysis Final Display
61
Introduction to Oracle Spatial Using Public Data
Any Questions?
