On NearUniform URL Sampling

1
On Near-Uniform URL Sampling

• Glenn M. Bernstein

2
Introduction

• First, the authors consider several sampling
  approaches, including natural approaches based on
  random walks. Intuitively, the problem with
  using a random walk in order to sample URLs from
  the web is that pages that are more highly
  connected tend to be chosen more often.

3
Introduction

• The authors suggest an improvement to the
  standard random walk technique that mitigates
  this effect, leading to a more uniform sample.

4
Introduction

• Second, the authors describe a test bed for
  validating their technique.
• In particular, the authors apply an sampling
  approach to a synthetic random graph whose
  connectivity was designed to resemble that of the
  web, and then analyze the distribution of these
  samples.

5
Introduction

• Finally, the authors apply their sampling
• technique to three sizable random walks
• of the actual web. They then use these
• samples to estimate the distribution of
• pages over internet domains, and to
• estimate the coverage of various search
• engine indexes.

6
Prior Work

• Definition The size of a search engine is the
  number of pages indexed by the search engine.
• Similarly, the size of the web corresponds to the
  number of publicly accessible static web pages.

7
Prior Work

• The question of understanding the size of the web
  and the relative sizes of search engines has been
  studied previously.
• The question of whether size is an appropriate
  gauge of search engine utility, however, remains
  a subject of debate.
• Another reason to study size is to learn about
  the growth of the web, so that
• Appropriate predictions can be made and future
  trends can be spotted early.

8
Prior Work

• Initial work The approach of sampling from NEC
  query logs leaves questions as to the statistical
  appropriateness of the sample, as well as the
  repeatability of the test by other researchers.
• Further work An approach based on random testing
  of IP addresses to determine characteristics of
  hosts and pages found on the web, as well as to
  estimate web size.

9
Prior Work

• This technique appears to be a usefule approach
  for determining characteristics of web hosts.
• Given the high variance in the number of
  pages/host, and the difficulties in accessing
  pages from hosts by this approach, it is not
  clear that this technique provides a general
  methodology to accurately determine the size of
  the web. In particular, the scalability of this
  approach is uncertain for future 128 bit IP-v6
  addresses.

10
Prior Work

• The weight of an index is a generalization of the
  notion of its size
• Each page can be assigned a weight, which
  corresponds to its importance
• The weight of a search engine index is then
  defined to be the sum of the weights of the pages
  it contains.

11
Prior Work

• Another natural weight measure is, for example,
  the PageRank measure.
• Random walks on the web graph and search-engine
  probing techniques can determine the weight of an
  index when the weight measure is given by the
  PageRank measure.

12
Prior Work-PageRank

• The PageRank is a measure of a page that is
  fundamental to this sampling approach.
• PageRank
• , where
• T is the total pages on the web
• 0 0.15
• Let pages p1,p2,,pn link to page p, and
• C(p) be the number of links out of p.

13
Mercator

• An extensible, multi-threaded web crawler written
  in Java
• Mercator configured to use 100 crawling threads,
  thus 100 random walks in parallel
• The crawl is seeded with 10K starting points
  chosen from a previous crawl

14
Mathematical Underpinnings

• First, approximate Pr(X is crawled)

15
Mathematical Underpinnings

• Consider a page well-connected if it can be
  reached by almost every other page through
  several short paths.
• A short walk means about steps, where n is
  the number of pages in the Web graph
• Short Walks
•
  (3)

16
Mathematical Underpinnings

• The main point of the approach is to obtain more
  nearly uniform samples from the history of random
  walks if we sample visited pages with a skewed
  probability distribution, namely by sampling
  inversely to each pages PageRank.

17
Mathematical Underpinnings

• The random walk provides us with two possible
  ways of estimating the PageRank
• 1. Estimate R(X), and call it the visit ratio

18
Mathematical Underpinnings

• Second, estimate the PageRank R(X) of a
• page by the sample PageRank R?(X)
• computed on this sample graph

19
Limitations

• Crawl-based approach finds pages that are
  accessible only through some sequence of links
  from our initial seed set
• Furthermore, avoid crawling dynamic content by
  stripping the query component from discovered
  URLs log only content text/html
• Technique biased against pages that are not
  well-connected

20
Limitations that stem from Mathematical framework

• Initial bias based on starting point, and
  mitigated by choosing a large, diverse set of
  initial starting points
• Dependence A dependence between pages in the
  random walk
• Short cycles A specific problem raised by the
  dependence problem. In particular, implies that
  approximation (3) is inaccurate for these pages

21
Limitations that stem from Mathematical framework

• Large PageRanks Approximation (3) is
  inappropriate for long walks and pages with very
  high PageRank. Approximation (4) will therefore
  overestimate the probability that a high PageRank
  page is crawled, since the right hand side can be
  larger than 1

22
Limitations

• Random Jumps The random walk approximates the
  behavior of a random web surfer by jumping to a
  random page visited previously, rather than a
  completely random page
• Approximation (4) doesnt guarantee uniform
  samples, since there are other possible sources
  of error in using the visit ratio to estimate the
  PageRank of a page

23
A Random Test Bed

• The graph represented by the web has a
  distinguishing structure. For example, the
  in-degrees and out-degrees of the nodes appear to
  have a power-law (or Zipf-like) distribution
• A random variable X is said to have a power-law
  distribution
• for some real number a and some range of k

24
A Random Test Bed

• The total in-degree and out-degree must match
• Random connections are then made from out links
  to in links via a random permutation
• The probability of having out-degree k was set to
  be proportional to 1/k2.38, for k in the range
  five to twenty
• The probability of having in-degree k was set to
  be proportional to 1/k2.1. The range of the
  in-degrees were therefore set to lie between five
  and eighteen

25
A Random Test Bed

• The final graph has 10,000,000 nodes and
  82,086,395 edges
• To crawl this graph, they wrote a program that
  reads a description of the graph and acts as a
  web server that returns synthetic pages whose
  links correspond to those of the graph
• Mercator to perform a random walk on this server

26
A Random Test Bed

• Three sets of two thousand samples each were
  chosen from the visited nodes, using three
  different sampling techniques
• A PR sample was obtained by sampling a crawled
  page X with probability inversely proportional to
  its apparent PageRank R'(X)

27
A Random Test Bed

• A VR sample was obtained by sampling a crawled
  page X with probability inversely proportional to
  its visit ratio VR(X)
• Finally, a random sample was obtained by simply
  choosing 2000 of the crawled pages independently
  and uniformly at random

28
A Random Test Bed

• Compare the proportions of the in-degrees,
  out-degrees, and PageRanks of our samples with
  their proportions in the original graph
• Consider first the out-degrees as shown in Figure
  1.
• The graph on the right normalizes these
  distributions against the percentages from the
  original graph

29
A Random Test Bed

• Figure 1 Out-degree distributions for the
  original graph and for nodes obtained by three
  different sampling techniques.

30
A Random Test Bed

• In both graphs, sample curves are closer to the
  graph curve are better. Although the
  distributions for the samples differ somewhat
  from that of the original graph, the differences
  are minor, and are due to the variation inherent
  in any probabilistic experiment.

31
A Random Test Bed

• In contrast, when they compare samples to the
  original graph in terms of the in-degree and
  PageRank, there does appear to be a systematic
  bias against pages with low in-degree and low
  PageRank.
• Figures 2 and 3 show the most biased results for
  in-degree and PageRank appear in the random
  samples.

32
A Random Test Bed

• Figure 2 In-degree distributions for the
  original graph and for nodes obtained by three
  different sampling techniques.

33
A Random Test Bed

• Figure 3 PageRank distributions for the original
  graph and for nodes obtained by three different
  sampling techniques.

34
A Random Test Bed

• Similar experiments with random graphs with
  broader ranges of in- and out-degrees, more
  similar to those found on the web were conducted
• Potential problem is that random graphs
  constructed with small in- and out- degrees might
  contain disjoint pieces that are never sampled,
  or long trails that are not well-connected.

35
A Random Test Bed

• In such graphs, again find that using the values
  VR(X) or R'(X) to re-scale sampling probabilities
  makes the resulting sample appear more uniform.

36
Sampling Random Walks of the Web

• Various attributes of the three random walks

37
Sampling Random Walks of the Web

• Note that Walk 3 downloaded pages at roughly
  twice the rate as the other two walks they
  attribute this to the variability inherent in
  network bandwith and DNS resolution

38
Sampling Random Walks of the Web

• Figure 4 Overlap of the URLs (in thousands)
  visited during the three walks.

39
Sampling Random Walks of the Web

• Figure 4 shows a Venn diagram. The regions
  enclosed by the blue, red and green lines
  represent the sets of URLs encountered by Walks
  1, 2 and 3, respectively.
• The main conclusion of Figure 4 is that 83.2 of
  all visited URLs were visited by only one walk.
  Hence, their walks seem to disperse well

40
Applications

• Measure properties of the web 2 groups
• 1. Determine characteristics of the URLs
  themselves. Examples include measuring
  distributions of the following URL properties
  length, number of arcs, port numbers, filename
  extensions, and top-level internet domains.

41
Applications

• 2. Determine characteristics of the documents
  referred to by the URLs. Examples include
  measuring distributions of the following document
  properties length, character set, language,
  number of out-links, and number of embedded
  images.

42
Estimating the Top-Level Domain Distribution

• Table 2 shows for each walk and each sampling
  method (using 10K URLs) the percentage of pages
  in the most popular internet domains.
• The results are consistent over the three walks
  that are sampled in the same way
• As the domain becomes smaller, the variance in
  percentages increases.

43
Estimating the Top-Level Domain Distribution

• Table 2 Percentage of sampled URLs in each
  top-level domain.

44
Estimating the Top-Level Domain Distribution

• Table 2 Percentage of sampled URLs in each
  top-level domain.

45
Estimating the Top-Level Domain Distribution

• Table 2 Percentage of sampled URLs in each
  top-level domain.

46
Search Engine Coverage

• To test whether a URL is indexed by a search
  engine.
• Used a list of words and approximate measure of
  their frequency
• Find the r rarest words
• Then query the search engine using a conjunction
  of these r rarest words and check for the
  appropriate URL.

47
Search Engine Coverage

• In practice, strong queries dont always uniquely
  identify a page.
• Sampled pages contain few rare words
• Mirror sites, duplicates or near-duplicates of
  the page or other spurious matches
• Northern Light can return pages that dont
  contain all of the words in the query.

48
Search Engine Coverage

• All URLs normalized by converting to lowercase,
  removing optional extensions such as index.htm
  and home.htm, inserting defaulted port numbers if
  necessary, and removing relative references of
  the form ...
• Figures 5, 6 and 7

49
Search Engine Coverage

• Figure 5 Exact matches for the three walks.

50
Search Engine Coverage

• Figure 6 Host matches for the three walks.

51
Search Engine Coverage

• Figure 7 Non-zero matches for the three walks.

52
Search Engine Coverage

• Google appears to perform better than one might
  expect from reported results on seach size
• First, Google sometimes returns pages that it has
  not indexed based on key words in the anchor text
  pointing to the page
• Second, Googles index may contain pages with
  higher PageRank than other search engines,

53
Search Engine Coverage

• and the biases of this approach in favor of
  such pages may be significant.

54
Conclusions

• Method for generating a near-uniform sample of
  URLs by sampling URLs discovered during a random
  walk of the web
• Known that random walks tend to over-sample URLs
  with higher connectivity, or PageRank.
• To ameliorate that effect, they described

55
Conclusion

• how additional information obtained by the walk
  can be used to skew the sampling probability
  against pages with high PageRank.
• They dont take advantage of additional knowledge
  about the web. However, such an approach might
  incur other problems for example, the changing
  nature of the web makes it unclear whether
  additional information used for sampling can be
  trusted to remain accurate over time.
