Title: Contracts and Invariants


1
Contracts and Invariants
  • Section 6.2 (JIAs)

2
Design by Contract --- DBC
  • Assignments are individual work
  • Each class interface defines a set of services
    via its public methods
  • The declaration of a method
  • what the user cares about in the API or javadoc
    documentation pages
  • defines only the type and not behavior
  • Behavior what happens when method is run
  • When can I call it? What happens if I do?
  • One should not write a class without a formal
    contract
  • lists the internal consistency conditions that
    the class will maintain (the invariant)
  • for each method
  • the correctness conditions that are the
    responsibility of the client (the precondition)
  • and those which the operation promises to
    establish in return (the postcondition)

3
Design by Contract --- DBC
  • Methods have preconditions and postconditions
    classes have invariants
  • A precondition is a Boolean expression that must
    hold when the method is invoked
  • i.e. a method may not be invoked when the
    preconditions is false
  • preconditions are guaranteed by the caller
  • When you call me, the following must be true
  • A postcondition is a Boolean expression that must
    hold when the method invocation returns
  • postconditions are guaranteed by the callee
  • If the preconditions are satisfied, I guarantee
    the following will be true when I return

4
Contract of a Method
  • Documented using special tags (most tags are not
    supported by JavaDoc)
  • /
  • JAVADOC Documentation
  • _at_pre precondition
  • _at_post postcondition
  • /
  • public someMethod()
  • Those tags may occur multiple times for any
    single method
  • in such case, the conjunction of all Boolean
    expression would serve as the pre and post
    conditions

5
Contract of a Method
  • The following special tags are used in pre- and
    post-conditions
  • _at_result a variable holding the return value of a
    method
  • _at_nochange a Boolean expression implying that the
    state of the object is not changed by the method
  • in postconditions
  • for accessors
  • Can also use the following operators
  • ? logical implication (a ? b is true iff a is
    false or both are true)
  • ? logical equivalence (a?b is true iff both are
    either true or false)

6
Example 1
  • /
  • Returns the number of elements in
  • the list
  • OTHER JAVADOC TAGS
  • _at_pre true
  • _at_post _at_nochange //no change for the state of the
    object (i.e. an accessor or a getter method)
  • /
  • public int size()

7
Example 2
  • /
  • Returns true iff the list is empty
  • OTHER JAVADOC TAGS
  • _at_pre true
  • _at_post _at_result ? size() gt 0
  • _at_post _at_nochange
  • /
  • public boolean isEmpty ()

8
Example 3
  • /
  • Returns the 1st element in the list
  • OTHER JAVADOC TAGS
  • _at_pre !isEmpty()
  • _at_post _at_result element(0) // this is a
    condition so that is why we use instead of
  • _at_post _at_nochange
  • /
  • public Object head()
  • Last()?

9
Example 4
  • /
  • Returns the last element in the list
  • OTHER JAVADOC TAGS
  • _at_pre !isEmpty()
  • _at_post _at_result element(size()-1)
  • _at_post _at_nochange //no change for the state of
    the object (i.e. an accessor or a getter method)
  • /
  • Public Object last()

10
Mutators
  • A mutator is a method that changes the state of
    the object (setter)
  • _at_post _at_nochange for accessors
  • Need to distinguish between the state of the
    object before and after the method invocation
  • values of expressions in the postcondition are
    evaluated w.r.t. the after state of the object
    (i.e. after method returns)
  • Add a new item at top and return it
  • _at_post _at_result element(size()-1)
  • To refer to object immediately before the method
    is invoked, we use the pre-state notation
  • expression_at_pre
  • Add a new item to list ? increase size
  • E.g. _at_post size() size()_at_pre 1

11
Collections
  • Contracts involving a collection of objects (i.e.
    list, vector, array, etc ) often require
    quantified expressions
  • Universal quantification
  • Holds on every object in the collection
  • _at_forall x Range_at_Expression
  • Existential quantification
  • Holds on at least one object in the collection
  • _at_exists x Range_at_Expression
  • x is a variable over Range
  • Range specifies the collection of objects
  • Expression is a Boolean expression

12
Specifying Ranges
  • m..n
  • Where m and n are integer expressions
  • _at_post _at_forall k0..size()-1)_at_SOME_COND
  • ClassName
  • Defines range of all instances of the class
  • _at_post _at_forall kCAR_at_SOME_COND
  • Expression
  • Evaluates to a collection like a set, bag, list,
    etc
  • _at_post _at_forall kRed,Green,Blue_at_SOME_COND

13
Example 5
  • /
  • Inserts a new element at the ith position
  • OTHER JAVADOC TAGS
  • _at_pre item !null igt 0 iltsize()
  • _at_post size() size()_at_pre 1
  • _at_post _at_forall k0..size()-1)_at_
  • (klti ? element(k) element(k)_at_pre)
  • (ki? item element(k))
  • (kgti? element(k) element(k-1)_at_pre)
  • /
  • public void insert(Object item, int i)
  • Try
  • public void insertHead(Object item)
  • public Object remove(int i)

14
Example 6
  • /
  • Inserts a new element at the head
  • OTHER JAVADOC TAGS
  • _at_pre item !null
  • _at_post size() size()_at_pre 1
  • _at_post item element(0)
  • _at_post _at_forall k 1..size()-1_at_
  • element(k) element(k-1)_at_pre)
  • /
  • public void insertHead(Object item)

15
Example 7
  • /
  • Inserts a new element at the tail
  • OTHER JAVADOC TAGS
  • _at_pre item !null
  • _at_post size() size()_at_pre 1
  • _at_post item element(size()-1)
  • _at_post _at_forall k 0..size()-2_at_
  • element(k) element(k)_at_pre )
  • /
  • public void insertTail(Object item)

16
Example 8
  • /
  • Remove and return the element at the ith
    position
  • OTHER JAVADOC TAGS
  • _at_pre size() gt 0 igt0 iltsize()
  • _at_post _at_result element(i)_at_pre
  • _at_post size() size()_at_pre-1
  • _at_post _at_forall k 0..size()-1 _at_
  • (klti ? element(k)_at_preelement(k))
  • (kgti? element(k1)_at_preelement(k)
  • /
  • public object remove(int i)

17
Example 9
  • /
  • Remove and return the Head item
  • OTHER JAVADOC TAGS
  • _at_pre size() gt 0
  • _at_post _at_result element(0)_at_pre
  • _at_post size() size()_at_pre-1
  • _at_post _at_forall k 1..size()-1 _at_
  • element(k1)_at_preelement(k
  • /)
  • public Object removeHead()

18
Example 10
  • /
  • Remove and return the Tail item
  • OTHER JAVADOC TAGS
  • _at_pre size() gt 0
  • _at_post _at_result element(size()-1)_at_pre
  • _at_post size() size()_at_pre-1
  • _at_post _at_forall k 0..size()-2 _at_
  • element(k)_at_preelement(k)
  • /
  • public Object removeTail()
