SEATING ERGONOMICS

1
(No Transcript)
2
SEATING ERGONOMICS

• The Features of a Good Ergonomic Chair

3
What to Look for in a Good Ergonomic Chair

• A chair that will fit everyone comfortably by
  adjusting to support each person in their working
  position.

• A back that will not hinder movement and has
  some passive flex.

• Soft edges for comfort while moving at the
  workstation. Soft edges also protect the
  surrounding worksurfaces.


• General Features

4
What to Look for in a Good Ergonomic Chair

• Generous and supportive cushion to encourage
  movement and comfort.

• Supportive foam that wont bottom out causing
  pressure points. You should try the chair out for
  a 3-5 days (See Chair Review) for best idea of
  long term comfort.

• General Features

Bulldog Recline
Bulldog Forward Tilt
Lowest Pressure Highest Pressure
5
What to Look for in a Good Ergonomic Chair

• Adjustments that are easy to do from the seated
  position, for ADA accessibility.

• Adjustment knobs that are intuitive and easy to
  grip.

• Arms (fixed or adjustable) that are recessed to
  allow the user to get close to the work surface
  and removable to adapt the chair to different
  user preferences.
• Radiused or soft armpads that do not to constrict
  blood flow in the wrist.

• General Features

6
What to Look for in a Good Ergonomic Chair

• Waterfall front seat edge that does not constrict
  blood flow to the legs.

• Synchronized tilt or knee tilt that mimics the
  bodys movement with tilt lock for resistance.
  Good ergonomic tilts do not cause the front edge
  of the chair to rise (which could obstruct
  circulation to the legs.)

• General Features

7
What to Look for in a Good Ergonomic Chair

• Tilt tension should be adjusted to the users
  preferred amount.

• Pneumatic Height Adjustment for quick ease of
  adjustment. Cylinder options for different size
  people - 15 to 22

• Adjustable Features

8
What to Look for in a Good Ergonomic Chair

• Adjustable Features

• The back height adjustment should adjusts 4
  inches to cover the full lumbar range of most
  users. The lumbar support maintains the users
  natural back curvature.

• Seat depth adjustment changes the seat depth to
  accommodate different height users. The seat
  depth adjustment in conjunction with a soft
  waterfall edge protects the sensitive area under
  the users knee. Proper positioning with a slight
  distance between the seat cushion and the user
  enhances circulation.

9
What to Look for in a Good Ergonomic Chair

• Forward Tilt creates a forward incline of the
  entire seat and back and allows for recline and
  lock.

• This feature should bring the back of the chair
  forward while in the incline mode to support the
  users back in the perched position.

• The forward tilt feature decreases pressure on
  the back and pelvis.

• Adjustable Features

10
What to Look for in a Good Ergonomic Chair

• 3-way adjustment - Height, arm support width and
  rotation (fixed rotation is preferable)

• 4-way adjustment - Height, arm support width for
  added clearance on the chair, fixed rotation and
  pad slide

• Soft Armpads are preferable to avoid excessive
  pressure on the wrists.

• Retrofittability enables an easy upgrade.

• Adjustable Features

11
What to Look for in a Good Ergonomic Chair
A good ergonomic chair should fit users
comfortably and support different working
positions

• Generous cushions and waterfall edge that
  encourage movement and circulation

• Synchronized tilt that mimics the bodys movement
  without straining the back. Good ergonomic tilts
  do not cause the front edge of the chair to rise
  during recline, ensuring proper circulation to
  the legs.
• Tilt tension that adjusts the recline resistance
  to the users preferred amount.

• Supportive foam that prevents bottoming out and
  pressure points.

• Soft edges on cushions that promote comfort in
  different seated positions. They also protect
  surrounding worksurfaces.

• The chair back that does not hinder arm movement
  while seated

• Tilt lock that supports the back in the upright
  position and variable position stop tailors the
  recline range.

• Adjustment knobs that are intuitive and easy to
  grip

• Simple, east-to-reach adjustments (for ADA
  accessibility.)

• Back height adjustment that controls the height
  of the entire back for lumbar and upper back
  support. (about 3-4 covers the full lumbar
  range.)

• Forward tilt that creates a forward incline of
  the seat and back with the ability to recline and
  lock in this mode. Forward tilt allows the chair
  to support the body in the position most people
  assume when typing.

• Arms that are recessed to allow the user to get
  close to the worksurface. Four-way adjustable
  arms include height, arm support width, fixed
  rotation and pad slide.
• Removable/retrofittable arms that adapt the chair
  to the users preferences and enable easy
  upgrades.


• Seat depth adjustment that changes the seat depth
  to accommodate different height users.

• Pneumatic seat height adjustment that includes
  optional cylinder sizes to accommodate different
  users.

• Five star base and casters that provide stability
  and mobility.

12
Adjustability Is Not a Valuable
InvestmentUnless the User Knows How to Operate
the Chair!

• Information onHow to Operate Your Knoll Office
  Chair can be found in the following places

• Instructional hangtags that ship on every chair.
• Knoll Office Seating Operating Instructions are
  available on the Knoll Web Site
  (http//www.Knoll.com.)

• Knoll Sellers can also provide after-sale
  personal product instruction.
