Concurrency

1
Concurrency

• Operating Systems
• Fall 2002

2
Concurrency pros and cons

• Concurrency is good for users
• One of the reasons for multiprogramming
• Working on the same problem, simultaneous
  execution of programs, background execution
• Concurrency is a pain in the neck for the
  system
• Access to shared data structures
• Deadlock due to resource contention
• Enabling process interaction

3
Mutual Exclusion

• OS is an instance of concurrent programming
• Multiple activities may take place in the same
  time
• Concurrent execution of operations involving
  multiple steps is problematic
• Example updating linked list
• Concurrent access to a shared data structure must
  be mutually exclusive

4
new-gtnextcurrent.next
insert_after(current,new)
current.nextnew
new
current
new
current
5
remove_next(current)
tmpcurrent.next current.nextcurrent.next.next
free(tmp)
current
current
6
new
current
new
current
new
current
7
Atomic operations

• A generic solution is to execute an operation
  atomically
• All the steps are perceived as executed in a
  single point of time
• insert_after(current,new) remove_next(current),
  or
• remove_next(current) insert_after(current,new)

8
The Critical Section Model

• A code within a critical section must be executed
  exclusively by a single process

do
critical section
remainder section
while(1)
9
Linked list example
do
do
tmpcurrent.next current.nextcurrent.next.next
free(tmp)
new-gtnextcurrent.next
current.nextnew
remainder section
remainder section
while(1)
while(1)
10
The Critical Section Problem

• n processes P0,,Pn-1
• Processes are communicating through shared
  atomic read/write variables
• x is a shared variable, l is a local variable
• Read takes the current value
• Write assigns a provided value

11
Requirements

• Mutual Exclusion If process Pi is executing its
  C.S., then no other process is in its C.S.
• Progress If Pi is in its entry section and no
  process is in C.S., then some process eventually
  enters C.S.
• Fairness If no process remains in C.S. forever,
  then each process requesting entry to C.S. will
  be eventually let into C.S.

12
Solving the CS problem (n2)
13
Solving the CS problem (n2)
14
Solving the CS problem (n2)
15
Petersons algorithm for n2
16
Bakery algorithm of Lamport

• Critical section algorithm for any ngt1
• Each time a process is requesting an entry to CS,
  assign it a ticket which is
• Unique and monotonically increasing
• Let the process into CS in the order of their
  numbers

17
Choosing a ticket
18
Bakery algorithm for n processes
19
Correctness
Lemma
Mutual exclusion is immediate from this lemma It
is easy to show that Progress and Fairness
hold as well (Exercise 47 in the notes -)
20
Hardware primitives

• Elementary building blocks capable of performing
  certain steps atomically
• Should be universal to allow for solving
  versatile synchronization problems
• Several such primitives were identified
• Test-and-set
• Fetch-and-add
• Compare-and-swap

21
Test-and-Set

• test-and-set(lock)
• templock
• lock1
• return temp

• Shared int lock, initially 0
• do
• while(test-and-set(lock))
• critical section
• lock0
• reminder section
• while(1)

22
Higher level abstractions

• Atomic primitives bring convenience
• Using hardware primitives make programs
  non-portable
• Higher level software abstractions are
  represented by
• Semaphores
• Monitors

23
Semaphores

• Invented by Edsger Dijkstra in 1968
• Interface consists of two primitives
• P() and V()

24
Notes on the Language

• Dutch P Proberen, V Verhogen
• Hebrew P ????, V ????
• English P() wait(), V() signal()

25
Semaphores initial value

• Initial value of a semaphore indicates how many
  identical instances of the critical resource
  exist
• A semaphore initialized to 1 is called a mutex
  (mutual exclusion)
• P(mutex)
• critical section
• V(mutex)

26
Programming with semaphores

• Semaphores is a powerful programming abstraction
• Define a semaphore for each critical resource
• E.g., one for each linked list
• Granularity?
• Concurrent processes access appropriate
  semaphores when synch. is needed

27
Implementing semaphores

• All the CS solutions so far imply busy waiting
• Burning CPU cycles while being blocked
• Semaphore definition does not necessarily imply
  busy waiting!
• Semaphores can be implemented efficiently by the
  system
• P() is explicitly telling the system Hey, I
  cannot proceed, you can preempt me

28
Implementing Semaphores

• Hence, in fact, a semaphore is a record
  (structure)

type semaphore record count
integer queue list of
process end var S semaphore

• When a process must wait for a semaphore S, it is
  blocked and put on the semaphores queue
• The signal operation removes (acc. to a fair
  policy like FIFO) one process from the queue and
  puts it in the list of ready processes

29
Semaphores operations (atomic)
P(S) S.count-- if (S.countlt0)
place this process in S.queue block this
process
V(S) S.count if (S.count lt 0)
remove a process P from S.queue place this
process P on ready list
S.count must be initialized to a nonnegative
value (depending on application)
30
The producer/consumer problem

• A producer process produces information that is
  consumed by a consumer process
• We need a buffer to hold items that are produced
  and eventually consumed
• A common paradigm for cooperating processes

31
P/C unbounded buffer

• We assume first an unbounded buffer consisting
  of a linear array of elements
• in points to the next item to be produced
• out points to the next item to be consumed

32
P/C unbounded buffer (solution)

• We need a semaphore S to perform mutual exclusion
  on the buffer only 1 process at a time can
  access the buffer
• We need another semaphore N to synchronize
  producer and consumer on the number N ( in -
  out) of items in the buffer
• an item can be consumed only after it has been
  created

33
Solution of P/C unbounded buffer
Initialization S.count1 N.count0
inout0
append(v) binv in
Producer repeat produce v P(S)
append(v) V(S) V(N) forever
Consumer repeat P(N) P(S) wtake()
V(S) consume(w) forever
take() wbout out return w
34
P/C finite circular buffer of size k

• can consume only when number N of (consumable)
  items is at least 1 (now N!in-out)
• can produce only when number E of empty spaces is
  at least 1

35
P/C finite circular buffer of size k

• As before
• we need a semaphore S to have mutual exclusion on
  buffer access
• we need a semaphore N to synchronize producer and
  consumer on the number of consumable items
• In addition
• we need a semaphore E to synchronize producer and
  consumer on the number of empty spaces

36
Solution of P/C finite circular buffer of size k
Initialization S.count1 in0
N.count0 out0 E.countk
append(v) binv in(in1) mod k
Producer repeat produce v P(E) P(S)
append(v) V(S) V(N) forever
Consumer repeat P(N) P(S) wtake()
V(S) V(E) consume(w) forever
take() wbout out(out1) mod
k return w
critical sections
37
Monitors

• Only a single process at a time can be active
  within the monitor
• gt other processes calling Pi() are queued
• Conditional variables for finer grained
  synchronization
• x.wait() suspend the execution until another
  process calls x.signal()

monitor monitor-name shared variable
declarations procedure P1()
procedure Pn()
38
Monitor

• Awaiting processes are either in the entrance
  queue or in a condition queue
• A process puts itself into condition queue cn by
  issuing cwait(cn)
• csignal(cn) brings into the monitor 1 process in
  condition cn queue
• Hence csignal(cn) blocks the calling process and
  puts it in the urgent queue (unless csignal is
  the last operation of the monitor procedure)

39
Producer/Consumer problem

• Two types of processes
• producers
• consumers
• Synchronization is now confined within the
  monitor
• append(.) and take(.) are procedures within the
  monitor are the only means by which P/C can
  access the buffer
• If these procedures are correct, synchronization
  will be correct for all participating processes

ProducerI repeat produce v
Append(v) forever ConsumerI repeat Take(v)
consume v forever
40
Monitor for the bounded P/C problem

• Monitor needs to hold the buffer
• buffer array0..k-1 of items
• needs two condition variables
• notfull csignal(notfull) indicates that the
  buffer is not full
• notemty csignal(notempty) indicates that the
  buffer is not empty
• needs buffer pointers and counts
• nextin points to next item to be appended
• nextout points to next item to be taken
• count holds the number of items in buffer

41
Monitor for the bounded P/C problem
Monitor boundedbuffer buffer array0..k-1 of
items nextin0, nextout0, count0
integer notfull, notempty condition
Append(v) if (countk) cwait(notfull)
buffernextin v nextin nextin1 mod k
count csignal(notempty) Take(v)
if (count0) cwait(notempty) v
buffernextout nextout nextout1 mod k
count-- csignal(notfull)
