Concurrency: Mutual Exclusion and Synchronization

1
Concurrency Mutual Exclusion and Synchronization

• .

2
Concurrency

• Multiple applications
• Multiprogramming
• Structured application
• Application can be a set of concurrent processes
• Operating-system structure
• Operating system is a set of processes or threads

3
Difficulties with Concurrency

• Sharing global resources
• Management of allocation of resources
• Programming errors difficult to locate

4
Concurrent Execution Problems

• Concurrent processes (or threads) often need to
  access shared data and shared resources
• Uncontrolled access to shared data will lead to
  an inconsistent view of the data or data races
• Data races are also called race conditions

5
Example

• Thread T1 and T2 are running procedure
  printtid()
• Assume both have access to the same variable
  a and to a function call mytid() which returns
  the thread id of the current thread
• Assume the thread can be interrupted at any
  point in the execution of printtid()
• If T1 is first interrupted after it sets a and
• T2 executes in its entirety (both statements)
• then the character echoed by T1 will be the tid
  assigned by T2
• The output will be two outputs of T2s TID
  instead of the two distinct values expected
• static int a
• void printtid()
• a mytid()
• cout ltlt a

6
.
7
Why the above problem ?

• Thread/process scheduling is done at regular
  intervals using timer
• Does not bother about what part of the code is
  executed by which thread
• So what is the solution ?
• Implement a mechanism which will produce expected
  output even in the case of concurrency across
  the critical section
• The above mechanism is called synchronization

8
Synchronization

• Threads cooperate in multithreaded programs by
  sharing resources, and data structures
• For correctness, we need to control this
  cooperation
• Threads interleave executions arbitrarily and at
  different rates
• Scheduling is not under program control
• We control cooperation using synchronization
• Synchronization enables us to restrict the
  possible interleavings of thread executions
• Discuss in terms of threads, also applies to
  processes

9
Shared Resources

• We will initially focus on coordinating access to
  shared resources
• Basic problem
• If two concurrent threads (processes) are
  accessing a shared variable, and that variable is
  read/modified/written by those threads, then
  access to the variable must be controlled to
  avoid erroneous behavior
• Over the next couple of lectures, we will look at
• Mechanisms to control access to shared resources
• Locks, mutexes, semaphores, monitors, condition
  variables,
• Patterns for coordinating accesses to shared
  resources
• Bounded buffer, producer-consumer, etc.

10
Classic Example

• Suppose we have to implement a function to handle
  withdrawals from a bank account
• withdraw (account, amount)
• balance get_balance(account)
• balance balance amount
• put_balance(account, balance)
• return balance
• Now suppose that you and your significant other
  share a bank account with a balance of 1000.
• Then you each go to separate ATM machines and
  simultaneously withdraw 100 from the account.

11
Example Continued
12
Interleaved Schedules
13
What is a race condition ?

• The problem is that two concurrent threads (or
• processes) accessed a shared resource (account)
• without any synchronization
• Known as a race condition (memorize this
  buzzword)
• We need mechanisms to control access to these
  shared resources in the face of concurrency
• So we can reason about how the program will
  operate
• Our example was updating a shared bank account
• Also necessary for synchronizing access to any
  shared data structure
• Buffers, queues, lists, hash tables, etc.

14
When Are Resources Shared?

• Local variables are not shared (private)
• Refer to data on the stack
• Each thread has its own stack
• Never pass/share/store a pointer to a local
  variable on another threads stack
• Global variables and static objects are shared
• Stored in the static data segment, accessible by
  any thread
• Dynamic objects and other heap objects are
  shared
• Allocated from heap with malloc/free or
  new/delete

15
Mutual Exclusion

• We want to use mutual exclusion to synchronize
  access to shared resources
• Code that uses mutual exclusion to synchronize
  its execution is called a critical section
• Only one thread at a time can execute in the
  critical section
• All other threads are forced to wait on entry
• When a thread leaves a critical section, another
  can enter

16
Critical Section Requirements

• Critical sections have the following
  requirements
• 1) Mutual exclusion
• If one thread is in the critical section, then
  no other is
• 2) Progress
• If some thread T is not in the critical section,
  then T cannot prevent some other thread S from
  entering the critical section
• 3) Bounded waiting (no starvation)
• If some thread T is waiting on the critical
  section, then T will eventually enter the
  critical section
• 4) Performance
• The overhead of entering and exiting the critical
  section is small with respect to the work being
  done within it

17

Mechanisms For Building Critical Sections

• Locks
• Very primitive, minimal semantics, used to build
  others Semaphores
• Basic, easy to get the hang of, but hard to
  program with
• Monitors
• High-level, requires language support,
  operations implicit
• Messages
• Simple model of communication and
  synchronization based on atomic transfer of
  data across a channel
• Direct application to distributed systems
• Messages for synchronization are straightforward
  (once we
• see how the others work)

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
Problems with Spinlocks

• The problem with spinlocks is that they are
  wasteful
• If a thread is spinning on a lock, then the
  thread lock cannot make progress
• How did the lock holder give up the CPU in the
  first place?
• Lock holder calls yield or sleep
• Involuntary context switch
• Only want to use spinlocks as primitives to
  build higher-level synchronization constructs

25
Disabling Interrupts

• Another implementation of acquire/release is to
• disable interrupts
• Note that there is no state associated with the
  lock
• Can two threads disable interrupts
  simultaneously?
• struct lock
• void acquire (lock)
• disable interrupts
• void release (lock)
• enable interrupts

26
On Disabling Interrupts

• Disabling interrupts blocks notification of
  external events that could trigger a context
  switch (e.g., timer)
• Disabling interrupts is insufficient on a
  multiprocessor
• In multiprocessor scenario back to atomic
  instructions
• Like spinlocks, only want to disable interrupts
  to
• implement higher-level synchronization
  primitives

27
Summarize Where We Are
28
Higher-level synchronization

• We looked at using locks to provide mutual
  exclusion
• Locks work, but they have some drawbacks when
  critical sections are long
• Spinlocks inefficient
• Disabling interrupts can miss or delay
  important events
• Instead, we want synchronization mechanisms
  that
• Block waiters
• Leave interrupts enabled inside the critical
  section
• Look at two common high-level mechanisms
• Semaphores binary (mutex) and counting
• Monitors mutexes and condition variables
• Use them to solve common synchronization
  problems

29
Blocking in semaphore

• Associated with each semaphore is a queue of
  waiting processes, a counter and methods wait( )
  signal( )
• When wait() is called by a thread
• Decrement the counter and
• If semaphore is open thread continues
• If semaphore is closed, thread blocks on queue
• signal() opens the semaphore
• Increment the count and
• If a thread is waiting on the queue, the thread
  is unblocked
• If no threads are waiting on the queue, the
  signal is remembered for the next thread
• In other words, signal() has history
• This history is a counter
• Wait and signal operations cannot be interrupted
• Queue is used to hold processes waiting on the
  semaphore

30
Semaphore types

• Semaphores come in two types
• Mutex semaphore
• Represents single access to an resource
• Guarantees mutual exclusion to a critical
  section
• Counting semaphore
• Represents a resource with many units available
• I.e. A resource that allows certain kinds of
  unsynchronized
• concurrent access (e.g., reading)
• Multiple threads can pass the semaphore
• Number of threads determine by the semaphore
  count
• mutex has count 1, counting has count N

31
Definition of semaphore primitives

• struct semaphore
• int count
• queueType queue
• void wait(semaphore s)
• s.count--
• if (s.count lt 0)
• place this process in s.queue
• block this process
• void signal(semaphore s)
• s.count
• if (s.count lt 0)
• remove a process P from s.queue
• place process P on ready list

32
Semaphore details

• Semaphore can be defined as an integer variable
  upon which three operations are defined
• Semaphores counter may be initialized to a
  non-negative value (Generally 1)
• Wait operation decrements the semaphore value.
• If the value becomes negative ,then the process
  executing the wait is blocked
• The signal operation increments the semaphore
  value
• If the value is not positive ,then a process
  blocked by a wait operation is unblocked
• Other than these three operations,there is no way
  to inspect or manipulate semaphores
• Wait and signal primitives are assumed to be
  atomic
• They can not be interrupted and each routine can
  be treated as an indivisible step

33
Binary semaphore structure

• struct binary_semaphore
• enum (zero, one) value
• queueType queue
• void waitB(binary_semaphore s)
• if (s.value 1)
• s.value 0
• else
• place this process in s.queue
• block this process
• void signalB(semaphore s)
• if (s.queue.is_empty())
• s.value 1
• else

34
Using semaphores
35
Readers/Writers problem

• An object is shared among several threads
• Some threads only read the object, others only
  write it
• We can allow multiple readers
• But only one writer
• How can we use semaphores to control access to
  the
• object to implement this protocol?
• Use three variables
• int readcount number of threads reading object
• Semaphore mutex control access to readcount
• Semaphore w_or_r exclusive writing or reading

36
(No Transcript)
37
Readers/writers Notes

• If there is a writer
• First reader blocks on w_or_r
• All other readers block on mutex
• Once a writer exits, all readers can fall
  through
• Which reader gets to go first?
• The last reader to exit signals a waiting writer
• If no writer, then readers can continue
• If readers and writers are waiting on w_or_r,
  and a
• writer exits, who goes first?
• Again, depends on scheduler

38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
