Title: Concurrency: Mutual Exclusion and Synchronization


1
Concurrency Mutual Exclusion and Synchronization
  • Concurrency 1
  • Concurrency and Mutual Exclusion

2
Relevant Definitions
  • Multiprogramming multiple processes on a single
    processor
  • Multiprocessing multiple processes on multiple
    processors
  • Distributed processing multiple processes on
    multiple independent computer systems.

3
Principles of Concurrency
  • Concurrent processes (or threads) execute during
    a shared time interval and may need to share
    resources files, data structures,
  • Concurrent processes are asynchronous the order
    of interleaved or overlapped instructions cant
    be predicted, and may vary from one time to the
    next

4
Process Isolation Shared Memory
  • Normally, processes run in a protected address
    space, as we have seen.
  • Sometimes processes need to share data by reading
    and writing to the same memory locations. The OS
    provides system calls to make this possible.
  • Threads in a single process may share information
    by reading/writing shared memory in the process.

5
Problems
  • If there is no controlled access to shared data,
    processes or threads may get an inconsistent view
    of this data
  • The result of concurrent execution will depend on
    the order in which instructions are interleaved.
  • Errors are timing dependent and usually not
    reproducible.

6
A Simple Example (p.204-205)
  • Assume P1 and P2 are executing this code segment
    and have access to the same variable a
  • Processes can be preempted at any time.
  • Assume P1 is preempted after the input statement,
    and P2 then executes entirely
  • The character echoed by P1 will be the one read
    by P2 !!
  • Similar problems arise if P1 and P2 run
    concurrently on an SMP

static char a void echo() cin gtgt a
cout ltlt a
7
Whats the Problem?
  • This is an example of a race condition the
    situation that exists when two or more processes
    are changing shared data and the final result
    depends on timing.
  • Individual processes (threads) execute
    sequentially in isolation, but concurrency causes
    them to interact.
  • We need to prevent concurrent execution by
    processes when they are changing the same data.
    We need to enforce mutual exclusion.

8
The Critical Section Problem
  • When a process executes code that manipulates
    shared data (or resources), we say that the
    process is in its critical section (CS) for that
    shared data
  • We must enforce mutual exclusion on the execution
    of critical sections.
  • Only one process at a time can be in its CS (for
    that shared data or resource).

9
The Critical Section Problem
  • Enforcing mutual exclusion guarantees that
    related CSs will be executed serially instead of
    concurrently.
  • The critical section problem is how to provide
    mechanisms to enforce mutual exclusion so the
    actions of concurrent processes wont depend on
    the order in which their instructions are
    interleaved

10
The Critical Section Problem
  • Processes/threads must request permission to
    enter a CS, signal when they leave CS.
  • Program structure
  • entry section requests entry to CS
  • exit section notifies that CS is completed
  • remainder section (RS) code that does not
    involve shared data and resources.
  • The CS problem exists on multiprocessors as well
    as on uniprocessors.

11
Process Interaction (p. 207)
  • Concurrent processes may be independent (unaware
    of each other) but in competition for shared
    resources e.g., printer. The OS must manage this
    type of interaction.
  • Other processes may be aware of each other,
    indirectly or directly. They must cooperate to
    use shared resources. OS may provide the
    mechanisms.

12
Concurrency Control Problems
  • Mutual Exclusion and Data Coherence
  • Deadlock
  • Starvation
  • See Table 5.2 (p. 208)

13
Mutual Exclusion and Data Coherence
  • Mutual Exclusion ensures data coherence if
    properly used.
  • Critical Resource (CR) - a shared resource such
    as a variable, file, or device
  • Data Coherence
  • The final value or state of a CR shared by
    concurrently executing processes is the same as
    the final value or state would be if each process
    executed serially, in some order.

14
Deadlock and Starvation
  • Deadlock two or more processes are blocked
    permanently because each is waiting for a
    resource held in a mutually exclusive manner by
    one of the others.
  • Starvation a process is repeatedly denied access
    to some resource which is protected by mutual
    exclusion, even though the resource periodically
    becomes available.

15
Requirements for Mutual Exclusion
  • Mutual Exclusion At most one process can be in
    its CS.
  • Non-interference A process that halts in its
    remainder section must not interfere with other
    processes.
  • Progress If no process is executing in its CS a
    process that wishes to enter its CS must be
    allowed to do so at once.

16
Requirements for Mutual Exclusion
  • Bounded waiting when a process requests access
    to its CS it cannot be delayed indefinitely (no
    deadlock, no starvation)
  • No assumptions can be made about relative process
    speeds or number of processors
  • A process remains in its critical section a
    finite amount of time.

17
Solutions to the Mutual Exclusion Problem
  • Four levels of solutions
  • software implemented by individual cooperating
    processes without additional support from
    hardware, language, or OS
  • hardware require special instructions or other
    hardware features
  • OS special system calls supported by kernel
  • Language features provided by programming
    languages

18
Software Solutions(See Appendix A.1 p. 730)
  • All solutions are based on a fundamental
    characteristic of computer hardware the
    indivisible load and store operations.
  • If two accesses to the same memory location occur
    at the same time, the hardware will serialize the
    accesses.
  • This feature mediates between CPU and DMA device,
    and between two processors on an SMP

19
Software Solutions Good Bad
  • First consider 2 - process solutions (p.731)
  • Algorithm 1, 2, and 3 are incorrect
  • Algorithm 4 is almost correct
  • Petersons algorithm (Fig. A.3 p.736) is
    correct
  • Notation
  • Call the two processes P0 and P1
  • When the notation Pi, Pj is used, assume (i ! j)

20
First Attempt
  • Turn is either 0 or 1 before the processes begin
    to run.
  • Pi may enter critical section when turn i (e.g.
    P0 enters if i0)
  • Mutual exclusion satisfied
  • P0 will hang at the while loop as long as turn
    1, and vice versa
  • Progress requirement not satisfied
  • Strict alternation
  • P0 enters CS first
  • P0 exits CS, sets turn 1
  • P0 executes short RS
  • P0 wants to enter CS again
  • P1 must enter CS first to set the turn variable
    back to 0.

Process P0 repeat while(turn!0) CS
turn1 RS forever
Process P1 repeat while(turn!1) CS
turn0 RS forever
21
Second Attempt
  • Flag stores a Boolean variable for each
    process
  • P0 tests flag1 while it is true, continue to
    test (busy-wait)
  • When flag1 is false P0 signals that it wants to
    enter its CS by setting flag 0 true
  • Mutual Exclusion is not satisfied
  • P0 tests flag1 and finds it false
  • P1 tests flag0 and finds it false
  • P0 sets flag0 true - too late!
  • P1 sets flag1 true - too late!
  • P0 and P1 both have permission to execute the
    critical section

Process P0 repeat while(flag1)
flag0true CS flag0false
RS forever
Process P1 repeat while(flag0)
flag1true CS flag1false
RS forever
22
Third Attempt
  • Try to fix the problem by setting your own flag
    before testing the other flag.
  • Assume P0 sets flag 0 true
  • Mutual Exclusion is satisfied
  • P1 will not enter CS because flag 0 is set to
    true
  • But bounded waiting requirement is not
    satisfied
  • P0 sets flag 0 true
  • P1 sets flag 1 true
  • P0 tests flag1 - its true!
  • P1 tests flag0 - true also!
  • Both processes will loop forever deadlock

Process P0 repeat flag0true
while(flag1) CS flag0false
RS forever
Process P1 repeat flag1true
while(flag0) CS flag1false
RS forever
23
Fourth Attempt
  • Try to fix the problem by turning off your flag
    for a random delay.
  • Mutual exclusion is satisfied, but waiting may
    not be bounded
  • P0 sets flag 0 true
  • P1 sets flag 1 true
  • P0 tests flag1 - its true!
  • P1 tests flag0 - true also!
  • P0 sets flag0 false
  • P1 sets flag1 false
  • P0 sets flag0 true
  • P1 sets flag1 true
  • ad infinitum
  • Both processes could loop forever livelock

Process P0 flag0true while(flag1)(
flag0false / delay / flag0
true CS flag0 false
Process P1 flag1true while(flag0)(
flag1false / delay / flag1
true CS flag1 false
24
Petersons Algorithm
  • Initialization
  • flag0 flag1 false
  • turn 0 or 1
  • Willingness to enter CS specified by flagi
    true
  • If both processes want to access the CS at the
    same time, the variable turn will decide it will
    be either 0 or 1 never both.
  • Exit section specifies that Pi is no longer in CS

Process P0 repeat flag0 true turn 1
while(flag1 turn1) CS
flag0false RS forever
Process P1 repeat flag1 true turn 0
while(flag0 turn0) CS
flag1false RS forever
25
Correct Software Solutions
  • Dekkers algorithm was the first correct solution
    proposed, but is complex.
  • Petersons algorithm is a simpler implementation
    of the same general idea.
  • L. Lamports Bakery Algorithm is an n-process
    solution which uses the take-a-number concept
    to resolve conflicts when multiple processes want
    to enter CS.

26
Performance of Software Solutions
  • If all criteria (ME, progress, bounded waiting,
    etc.) are satisfied, then a valid solution will
    protect against the failure of a process in its
    remainder section (RS)
  • No solution can provide robustness against a
    process failing in its critical section (CS)
  • A process Pi that fails in its CS is equivalent
    to a process with an infinitely long CS
  • Software solutions use busy-waiting.

27
Hardware Solutions 5.2
  • Disable interrupts
  • Test-and-set instruction
  • Exchange instruction

28
Disable Interrupts
  • On a uniprocessor
  • mutual exclusion guaranteed, since nothing can
    interrupt the running process.
  • But OS has no control if user program decides
    not to enable the interrupts
  • OS cannot preempt process
  • Multiprogramming is lost
  • On a multiprocessor
  • mutual exclusion is not preserved

Process Pi repeat disable interrupts
critical section enable interrupts remainder
section forever
29
Special Machine Instruction - Test-and-Set
  • Test-and-set is a hardware instruction that tests
    the value of its argument i and returns true if i
    0, false if i 1. In every case, i 1 after
    the instruction completes.
  • The key point is that this all happens in a
    single machine instruction there is no way to
    separate the test operation from the set
    operation.

30
The test-and-set instruction
  • Using test-and-set
  • shared variable i is initialized to 0
  • The first Pi to find i0 gets to enter CS
  • C description of testset

bool atomic testset(int i) if (i0)
i1 return true else return
false // atomic means the entire
function must execute atomically without
interruption //
Process Pi repeat repeat until
testset(i) CS i0 RS forever
31
The Problem with test-and-set
  • Mutual exclusion is preserved if Pi enters CS, i
    is set to 1, so no other process can enter.
  • Problem still uses busy waiting (constant
    looping)
  • When a process exits CS, the selection of the
    next process to enter the CS is unpredictable, so
    the bounded wait requirement is violated and
    starvation is possible.

32
The Exchange Instruction
  • Some processors (i.e. Pentium) provide an atomic
    exchange instruction (xchg(a,b) ) that swaps the
    contents of a and b.
  • But xchg(a,b) suffers from the same drawbacks as
    test-and-set busy-wait, possibility of
    starvation, and deadlock due to priority
    inversion.

33
Advantages of Machine Instruction Approach
  • Test-and-set, exchange have drawbacks, as noted,
    but they also have advantages
  • will work for any number of processes
  • will work on a uniprocessor or a multiprocessor
  • simple to implement

34
Summary of Process Synchronization
  • Cooperating concurrent processes are processes
    that can affect each other by modifying shared
    data or resources.
  • Atomic actions are indivisible. In hardware,
    loads and stores are indivisible. Complex atomic
    machine instructions such as test-and-set may
    also be provided.
  • On a uniprocessor, a process switch can occur
    between any two atomic actions thus the atomic
    actions of concurrent processes may be
    interleaved in any possible order.
  • On a multiprocessor, atomic actions may be also
    be overlapped, (although memory accesses are
    still indivisible).

35
Summary of Process Synchronization
  • Consequently, process results may be
    non-deterministic and non-repeatable if actions
    are not synchronized.
  • Race Condition when two or more processes (or
    threads) modify a shared object concurrently and
    the results of the modification are different
    than they would have been if each process
    executed serially, in some order.
  • Solutions to the mutual exclusion problem have
    the effect of making critical sections behave as
    if they are atomic operations. The objective is
    to avoid race conditions and ensure that process
    execution is deterministic.
Write a Comment
User Comments (0)
About PowerShow.com
