Evaluation of Shock in Adults

1
Evaluation of Shock in Adults

• Charles B. Lehman, MD
• University Medical Center
• Hospitalist Service

2
Hemodynamic profilesof the shock states
3
Introduction

• Definition a physiologic state caused by
  inadequate tissue perfusion leading to decreased
  tissue oxygen delivery.

4
Introduction

• Effects are initally reversible, but lead to
  cellular hypoxia which can cause
• Cell membrane and ion pump dysfuction
• Intracelluar edema
• Leakage of intracellular contents into the
  extracelluar space
• Inadequate regulation of intracelluar pH

5
Introduction

• Effects rapidly become irreversible and lead to
  cell death, end-organ damage, multi-system organ
  failure and finally death.
• Prompt recognition of symptoms is the key to
  treatment.

6
Introduction

• Despite extensive research, mortality rates
  remain high
• Septic 35-40
• Cardiogenic 60-90
• Hypovolemic variable, depends on etiology and
  time to treatment

7
Stages

• Pre-shock
• Shock
• End-organ dysfunction

8
Stages Pre-shock

• Warm or compensated shock
• Regulatory mechanisms are able to compensate for
  diminished perfusion.

9
Stages pre-shock

• Low-preload
• Tachycardia
• Peripheral vasoconstriction
• Decrease in blood pressure
• Low-afterload
• Peripheral vasodilation
• Hyperdynamic state

10
Stages shock

• Compensatory mechanisms become overwhelmed,
  resulting in
• Tachycardia
• Tachypnea
• Metabolic acidosis
• Oilguria
• Cool, clammy skin

11
Stages shock

• Usually occur with
• Loss of 20-25 of effective blood volume
• Fall in cardiac index to 2.5 L/min/M2
• Activation of mediators of the sepsis syndrome

12
Sepsis end-organ dysfunction

• Decreasing urine output
• Restlessness leading to agitation, obtundation
  and coma
• Mutiple organ system failure which leads to death

13
Physiologic determinants

• Systemic Vascular Resistance (SVR)
• Vessel length
• Blood viscosity
• Vessel diameter

14
Physiologic determinants

• Cardiac Output (CO) heart rate x stroke volume
• Stroke volume depends on preload, myocardial
  contractility and afterload

15
Physiologic Determinants

• SVR and CO can be used to differentiate between
  forms of shock

16
Classification

• Hypovolemic
• Cardiogenic
• Distributive

17
Hypovolemic shock

• Result of decreased preload
• CO HR x SV, and SV depends on preload
• Decrease in preload therefore leads to decrease
  in CO

18
Hypovolemic shock

• Hemorrhage
• Trauma
• GI bleeding
• Ruptured aneurysm or hematoma
• Hemorrhagic pancreatitis
• Fractures

19
Hypovolemic shock

• Fluid loss
• Diarrhea
• Vomiting
• Heat stroke
• Inadequate repletion of insensible losses
• Burns
• Third spacing (intestinal obstruction,
  pancreatitis, cirrhosis)

20
Cardiogenic shock

• Results from pump failure and decreased cardiac
  output
• Main categories
• Myopathies
• Arrythimia
• Mechanical
• Extracardiac/obstructive

21
Cardiogenic shock

• Cardiomyopathies
• Infarction involving 40 of the LV
• RV infarction
• Dilated cardiomyopathies
• Stunned myocardium following prolonged ischemia
  or cardiopulmonary bypass
• Myocardial depression in advanced septic shock

22
Cardiogenic shock

• Arrythmia
• Loss of syncrhonized filling between the atria
  and ventricles with atrial fibrillation
• Complete loss of CO with ventricular fibrillation
• Decrease in heartrate with bradyarrythmias and
  heart block leads to decrease in CO

23
Cardiogenic shock

• Mechaincal
• Mitral regurgitation from chordae tendineae
• Aortic insufficiency due to dissection of
  ascending aorta into the aortic valve ring
• Critical aortic stenosis
• VSD
• Atrial myxoma

24
Cardiogenic shock

• Obstructive
• Pulmonary embolism
• Tension pneumothorax
• Constrictive pericarditis
• Pericardial tamponade
• Severe pulmonary hypertension
• These can also present as hypovolemic shock if
  the primary disturbance creates decreased preload

25
Distributive shock

• Causes
• Sepsis
• Activation of systemic inflammatory response
  system (pancreatitis, burns, multiple trauma
• Anaphylaxis
• Drug or toxin reactions (insect bites,
  transfusion reactions, heavy metal poisoning)

26
Heavy metal poisoning
27
Distributive shock

• Causes
• Addisonian crisis
• Myxedema coma
• Neurogenic shock due to CNS or cord trauma
• MI with systemic inflammatory state
• Cardiopulmonary bypass

28
Common features

• Hypotension
• SBP
• Occurs in most shock patients
• Initially will be relative to patients baseline
  blood pressure
• Drop in SBP 40 can be an early indicator
• Progresses to profound hypotension, often
  requiring vasopressors

29
Common features

• Cool, clammy skin
• Regulatory processes compensating for decreased
  effective tissue perfusion
• Bloodflow redirected to vital organs to maintain
  coronary, cerebral and splanchnic perfusion
• Lack of peripheral flow leads to classic cool,
  clammy picture of shock

30
Common features

• Oliguria
• Result of shunting of renal bloodflow to other
  vital organs
• Objective measure of intravascular volume
  depletion
• Related signs tachycardia, orthostatic
  hypotension, poor skin turgor, absent axillary
  sweat, dry mucous membranes

31
Common features

• Mental status changes
• Begins with agitation
• Progresses to confusion/delirium
• Ends in obtundation/coma

32
Common features

• Metabolic acidosis
• May initally have a respiratory alkalosis
• Acidosis will eventually prevail
• Related to accumulation of lactate due to lack of
  clearance by liver, kidneys and skeletal muscle
• Increased anaerobic metabolism due to tissue
  hypoxia contributes in later stages

33
Initial approach

• History
• Food/medicine allergies
• Recent medication changes
• Potential acute/chronic drug intoxication
• Preexisting diseases
• Immunosupression
• Hypercoagulable states

34
Initial approach

• Physical exam HEENT
• Scleral icterus
• Dry conjunctivae
• Dry mucous membranes
• Pinpoint pupils
• Fixed/dilated pupils
• Nystagmus

35
Initial approach

• Physical exam Neck
• JVD
• Delayed carotid upstroke
• Carotid bruits
• Meningeal signs

36
Initial approach

• Physical exam lungs
• Tachypnea
• Shallow respirations
• Crackles/rales
• Consolidation
• Egophony
• Absent breath sounds

37
Initial approach

• Physical exam cardiovascular
• Arrythmia
• Murmurs or S3 gallop
• Diffuse PMI
• Right or left ventricular heave
• Distant heart sounds
• Rub
• Pulsus paradoxus

38
Initial approach

• Physical exam Abdomen
• Tenseness
• Distension
• Tenderness
• Rebound/guarding
• Absent bowel sounds
• Pulsitile masses
• Ascites

39
Initial approach

• Physical exam rectal
• Decreased tone
• Blood (hematochezia or melena)

40
Initial approach

• Physical exam extremities
• Calf swelling/palpable cords
• Unequal pulses
• Disparity of blood pressure between upper
  extremities

41
Initial approach

• Physical exam neurologic
• Agitation
• Confusion
• Delirium
• Obtundation
• Coma

42
Initial approach

• Physical exam skin
• Cold, clammy
• Warm, hyperemic
• Rashes
• Petechiae
• Urticara
• Cellulitis

43
Initial approach

• Lab evaluation
• CBC with differential
• Basic chemistries
• Liver function tests
• Amylase/lipase
• Fibrinogen and fibrin split products
• Lactate
• Cardiac enzymes

44
Initial approach

• Lab evaluation
• ABGs
• Toxicology screen
• Chest x-ray
• Abdominal x-ray
• Echocardiogram
• Urinalysis

45
Pulmonary arterycatheterization

• Can be used to provide hemodynamic measurements
  such as
• Cardiac output
• Pulmonary artery wedge pressure
• SVR
• Helpful in determining a cause when the
  differential is broad

46
Pulmonary arterycatheterization

• Can also help with
• Monitoring fluid resuscitation
• Titration of vasopressors
• Measuring effects of changes in ventilator
  settings (PEEP) on hemodynamics

47
Pulmonary arterycatheterization

• PA catheters are associated with significant
  clinical risks and have never been proven to
  improve clinical outcomes

48
Hemodynamic profilesof the shock states
49
Hemodynamic profilesof the shock states
50
Treatment of Shock in Adults

• Charles B. Lehman, MD
• University Medical Center
• Hospitalist Service

51
Ultimate cure for sepsis

• Chuck Norris tears cure sepsis.
• Too bad hes never cried.
• Ever.

52
Therapeutic priorities

• Supportive measures to treat hypoxemia,
  hypotension and impaired tissue oxygenation
• Distinguish between sepsis and SIRS (systemic
  inflammatory response syndrome) so
  medical/surgical treatment of the source of
  infection can be started
• Assess for adequate tissue perfusion

53
Initial management

• Resuscitation
• Assess airway, respiration and perfusion
• Supplemental O2 should be given to all patients
• Intubation often required to protect airway
• Mechanical ventilation often needed due to
  development of lung injury or ARDS

54
Initial management

• Monitoring of tissue perfusion
• Hypotension is typically present
• Prompt volume resuscitation and restoration of
  perfusion pressure can limit end organ damage
• Consider arterial catheterization if restoration
  of perfusion pressure is expected to be a
  protracted process

55
Initial management

• Signs of inadequate organ perfusion
• Cool, vasoconstricted skin due to redirection of
  bloodflow to vital organs
• Obtundation/restlessness
• Oliguria/anuria
• Lactic acidosis

56
Initial management

• Restoration of tissue perfusion
• CVP 8 - 12
• MAP 65
• Urine output 0.5 ml/kg/hr
• Mixed venous O2 70
• Can use IV fluids, PRBCs and pressors to achieve
  these goals depending on patients intravascular
  volume, cardiac status and severity of shock

57
Initial management

• IV fluids
• Rapid, large volume infusions are usually
  indicated
• CHF is the primary contraindication
• Relative hypovolemia is often severe
• Not unusual for a patient to require 10 liters
  within the first 24 hours

58
Initial management

• IV fluids
• Should be given in well-defined, rapidly infused
  boluses
• Assess volume status, tissue perfusion, blood
  pressure, and for pulmonary edema before/after
  each bolus
• Colloids have not been proven to have any
  advantage over crystalloids

59
Initial management

• May repeat IV fluid boluses until
• Blood pressure, tissue perfusion and oxygen
  delivery are acceptable
• PAWP 18
• Development of pulmonary edema
• Note that septic patients can develop pulmonary
  edema with relatively normal wedge pressures

60
Initial management

• IV fluids how much?
• Central venous catheters can be used to monitor
  central venous pressures
• Can also be used to estimate mixed venous oxygen
  content

61
Initial management

• Vasopressors
• Second-line agents
• Useful in patients who fail to reach adequate
  blood pressures despite adequate volume
  resuscitation
• Also useful in patients who develop cardiogenic
  pulmonary edema

62
Initial management

• Vasopressors
• Dopamine and levophed recommended and
  first-choice drugs
• Phenylephrine (pure a-adrenergic) can be useful
  when tachycardia or arrythmia due to b-adrenergic
  activity becomes problematic
• Vasopressin can be used in patients refractory to
  first-choice agents

63
Properties of Vasopressors
64
Monitoring response to therapy

• All patients require close monitoring
• Evidence of deterioration merits a prompt,
  thorough reevaluation

65
Monitoring response to therapy

• Monitoring parameters
• Respiratory PaO2/FiO2 ratio
• Renal urine output, creatinine
• Hematologic platelet counts
• CNS Glascow coma scale
• Hepatobiliary bilirubin, LFTs
• CV blood pressure, arterial lactate
• GI ileus, blood in NG aspirate

66
Monitoring response to therapy

• Ebb phase
• Restore arterial perfusion pressures to
  pre-sepsis levels
• Flow phase
• Maintain oxygen delivery to meet ongoing tissue
  needs

67
Monitoring response to therapy

• Detection of tissue hypoxia
• Arterial lactate concentration is the most useful
  measure of tissue perfusion
• Limited in that it is a global measure and can
  miss significant injury to a specific organ
  system

68
Monitoring response to therapy

• Treatment of tissue hypoxia
• Study compared standard treatment (MAP65, CVP8,
  urine output0.5 ml/kg/hr) to maintaining central
  venous O2 saturation 70

69
Monitoring response to therapy

• Results
• Decreased in-hospital mortality (30 vs. 46)
• Lower arterial lactate concentration following 6
  hours of therapy
• Lower APACHE II and SAPS II scores
• Decreased evidence of multiple organ dysfunction

70
Monitoring response to therapy

• Red blood cell transfusions were used
  aggressively in this study to maintain DO2 (70
  in study arm vs. 45 in control arm)
• Recommend maintaining Hct 30 to maintain
  adequate tissue oxygen delivery

71
Monitoring response to therapy

• If arterial lactate concentrations fail to fall
  with adequate transfusion, cardiac output must be
  increased
• Further IV fluid therapy can be given
• Dobutamine can be given when arterial pressures
  are adequate to tolerate vasodepression
  (phenylephrine/norepineprhine can be added if
  needed)

72
Control of septic focus

• Prompt identification and treatment of infectious
  source are critical
• Previously mentioned treatments are supportive
  only

73
Control of septic focus

• Identification of septic focus
• Blood cultures (2 sets, aerobic and anaerobic)
• Urine Gram stain and culture
• Sputum in a patient with productive cough
• Intra-abdominal collection in post-operative
  patients

74
Control of septic focus

• Investigational methods
• TREM-1 (triggering receptor expressed on myeloid
  cells)
• Elevated serum procalcitonin

75
Control of septic focus

• Eradication of infection
• Potentially infected foreign bodies (vascular
  access devices)
• Percutaneous or surgical drainage of abscesses
• Soft-tissue debridement or amputation if necessary

76
Control of septic focus

• Antimicrobial regimen
• Should be started promptly after cultures have
  been obtained
• Inappropriate antibiotic selection is
  surprisingly common and has been shown to
  increase mortality
• Time to initiation of treatment has been shown to
  be the strongest predictor of mortality

77
Control of septic focus

• If pseudomonas is not likely, vancomycin and
• 3rd/4th generation cephalosporin
• b-lactam/b-lactamase inhibitor
• Carbapenem

78
Control of septic focus

• If pseudomonas is likely, vancomycin and 2 of the
  following
• Antipseudomonal cephalosporin
• Antipseudomonal penicillin/b-lactamase inhibitor
• Antipseudomonal carbepenem
• Floroquinolone with good antipseudomonal activity
• Aminolgycoside

79
Recombinant HumanActivated Protein C (Xigris)

• Coagulation abnormalities are common in septic
  shock
• Several reports have suggested that protein C
  supplementation may produce clinical benefit,
  epecially in setting of purpura fulminans

80
Recombinant HumanActivated Protein C (Xigris)

• PROWESS trial
• Lower 28-day mortality rate (24.7 vs. 30.8)
• Non-significant increase in serious bleeding
• Was of greater benefit in the most acutely ill
  patients (APACHE II 25)

81
Recombinant HumanActivated Protein C (Xigris)

• PROWESS trial limitations
• Excluded patients with chronic renal failure
• Patients with metastatic cancer, pancreatitis and
  organ transplant recipients were excluded after
  720 patients were enrolled
• Cell line used to produce drug was changed during
  the trial

82
Recombinant HumanActivated Protein C (Xigris)

• ENHANCE trial
• Similar 28-day all-cause mortality rates
• Increase in incidence of serious bleeding
  (specifically intracranial hemorrhage) was
  significant
• Treatment within 24 hours of first sepsis-related
  organ dysfunction showed significantly lower
  mortality than those treated after 24 hours

83
Recombinant HumanActivated Protein C (Xigris)

• ADDRESS trial
• Patients with APACHE II scores
• Designed to enroll 11,000 patients
• Stopped after 2,600 patients were enrolled
  because it was unlikely to show any benefit

84
Nutrition

• Essential for optimal immune function
• Beneficial in both treatment of and prevention of
  sepsis
• Early enteral nutrition probably offers more
  benefit that parenteral nutrition
• Results in higher neutrophil counts and higher
  albumin levels

85
Glucose control

• Critically ill patients can develop hyperglycemia
  and insulin resistance regardless of a history of
  diabetes
• Several papers have shown improvement in outcome
  with aggressive glucose control

86
Summary

• Initial management secure airway and correct
  hypoxemia. Intubation and mechanical intubation
  are often necessary

87
Summary

• Prompt restoration of tissue perfusion using IV
  fluids, vasopressors, oxygen, PRBCs and
  inotropes
• CVP 8-12
• MAP 65
• Urine output 0.5 ml/kg/hr
• Central venous or mixed venous O2 sat 70

88
Summary

• IV fluids are first-line treatment
• Repeat until BP and perfusion are acceptable,
  patient develops pulmonary edema or PAWP 18
• Assess patient before and after each bolus
• No data to demonstrate using colloids over
  crystalloids

89
Summary

• Vasopressors recommended for patients who remain
  hypotensive after adequate volume replacement
• Dopamine and norepineprhine are preferred agents

90
Summary

• If patient has evidence of ongoing tissue hypoxia
  (increased arterial lactate) despite restoration
  of intravascular volume and perfusion pressure,
  transfusion and inotropes can be used to increase
  oxygen delivery

91
Summary

• Prompt identification of the source of infection
  is essential
• Sputum and urine for Gram stain
• Intra-abdominal fluid should be percutaneously
  sampled
• Blood from 3 distinct sites and from indwelling
  catheters cultured aerobically and anaerobically

92
Summary

• Prompt administration of appropriate antibiotics
  after cultures have been obtained
• Potentially infected vascular devices should be
  removed, abcesses should be drained, and soft
  tissue infections must be debrided or amputated

93
Summary

• Xigris can be administered to patients with
  severe sepsis and a high-risk of death (APACHE II
  25), but has not been shown to be of benefit in
  lower risk patients or in children

94
Summary

• Glucose should be aggressively (goal 80-110)
• Nutritional support can improve outcomes, and an
  enteral route is favored over parenteral

95
GI bleed case study

• 51 year-old white male transferred to University
  Medical Center for severe GI bleeding
• Required total of 18 units of PRBCs in first 3
  days after admission, then continued to require 2
  4 units per day to maintain adequate Hb/Hct

96
GI bleed case study

• EGD extensive ulcerations extending from
  mid-palate to duodenum
• Colonscopy extensive ulcerations from the rectum
  to the terminal ileum with active bleeding noted
  at many sites
• Bleeding scan suggested small bowel involvement
  as well

97
GI bleed case study

• Biopsies obtained from the EGD were consistent
  with Crohns disease
• Attempts to treat with steroid enemas and
  systemic steroids were only partially effective.

98
GI bleed case study

• Case was presented on GI/surgical conference
  rounds.
• They decided that further medical treatment was
  futile, and that a definitive surgical approach
  would be required

99
GI bleed case study

• The patient became the first person in the world
  to undergo an oro-pharyngeo-esophago-gastro-duoden
  o-jejuno-ileo-colectomy with oro-anal anastomosis.

100
GI bleed case study

• Thank God!
• My Crohns disease is
• finally completely
• cured!
