Tightly Structured Peer to Peer Systems

1
Tightly Structured Peer to Peer Systems

• Scalable Content Addressable Network(CAN)
• Chord Scalable Peer-to-Peer Lookup Service for
  Internet Applications
• Surendra Kumar Singhi

2
Background

• Napster - Centralized Index
• Problem Doesn't Scale well
• Gnutella - Decentralized but Flooding
• Problem Too much network traffic, even if better
  search algorithms like IDS or Directed-BFS are
  used the resource utilization is still poor

3
Solution? How to do Better Search?

• Use Hash Tables.
• The file name is now a key.
• And it maps into values which is the location
  of the file.

4
Content Addressable Network

• Basic Design
• Routing
• Construction
• Departure, recovery and maintenance
• Design Improvements
• Multi-dimensional coordinate space
• Realities
• Overloading coordinate zones
• Topologically Sensitive CAN construction
• Multiple Hash functions
• Uniform Partitioning
• Caching and Replication

5
CAN Basic Design

• Virtual d-dimensional Coordinate Space on a
  d-torus.
• The coordinate space partitioned among the nodes.
  Each node has its zone.
• The (K,V) pair is stored at the node which owns
  the point P in coordinate space.

6
Routing in CAN

• Routing table containing IP Address and virtual
  coordinate zone of its neighbors.
• Node greedily forward message to the neighbor
  with coordinates closest to the destination
  coordinate.

7
CAN Construction

• Find a node already in the CAN.
• Randomly choose a point P and send a join request.

8

• Node containing P splits itself into half.
• The (K,V) pairs from halved zone are handed over
  to new node.
• New node learns IP addresses of its neighbors.
  Previous occupant also updates its neighbor set.
• Finally, inform the neighbors of this
  reallocation of space.

9
Node departure, recovery and maintenance

• Node explicitly handing over its zone and
  associated (K,V) database to one of its neighbor.
• Failure Immediate Neighbor Takeover Algorithm.
  (key, value) pairs are lost.
• Nodes entering (K,V) pairs into CAN periodically
  refresh these entries.
• Nodes send periodic update messages to their
  neighbors.
• Background zone-reassignment algorithm

10
Design Improvements

• Reduce path-length or per-CAN-hop latency.
• Tradeoff between improved routing performance and
  system robustness on one hand and system
  complexity and increased per-node state on the
  other.

11
Multi-dimensional coordinate space

• Increase in dimension reduces the routing path
  length
• For n nodes and d dimensions the path length
  scales as O(d(n1/d)).
• Improve in fault tolerance.

12
Realities multiple coordinate spaces

• Node owns one zone per reality.
• Hash table replicated on every reality.
• Can reach distant portions of space in one hop
  hence reducing average path length.
• Improved data availability and fault tolerance.

13
Overloading coordinate zone

• Allow multiple nodes to share the same zone.
• Request neighbors for peers, and retain the node
  with the lowest RTT as its neighbor.
• Contents of hash table may be divided or
  replicated among peers.

14
Multiple hash functions

• Use k different hash functions to map single key
  onto k points in the coordinate space
• query can be send to k nodes in parallel, thus
  reducing average latency

15
Topologically Sensitive Construction of CAN
Network

• Well known set of machines(landmarks).
• Every node measures RTT to landmarks and orders
  landmarks in order of increasing RTT.
• Node joins CAN at portion of coordinate space
  associated with landmark ordering.

16
More Uniform Partitioning

• The node receiving the join message , knows the
  zone coordinates of its neighbors too.
• The zone with the largest volume is split.
• Is it true load balancing?

17
Caching and Replication

• CAN nodes maintain a cache of data keys it
  recently accessed.
• Before forwarding a request for data key, it
  checks whether the requested key is in its own
  cache.
• When a node feels it is overloaded with request
  for particular data key, it can replicate the
  data key at its neighbor.
• Cached and replicated keys must have a TTL field
  and should expire from cache.

18
Design Summary
19
(No Transcript)
20
Few Observations

• Very good results and scales well.
• Denial of Service attacks?
• Topologically sensitive construction not
  satisfactory.
• Keyword Searching?

21
Chord Peer to Peer Lookup Service

• Base Protocol
• Consistent Hashing
• Key Location
• Node joining the network.
• Design Improvements
• Simulation Experimental Result
• Load Balancing
• Path Length
• Node Failures

22
Base Chord Protocol

• Uses Consistent Hashing.
• Improves scalability of consistent hashing.

23
Consistent Hashing

• Each node and key is assigned an m-bit identifier
  using a hash function.
• The size of identifier space is 2m.
• Key k is assigned to first node whose identifier
  is equal to or follows k in the identifier space.

24
Scalable Key Location

• A very simple algorithm will be each node knows
  its successor. But, this doesn't scales.
• Each node maintains a finger table.
• The ith entry in the table contains the identity
  of first node s, that succeeds n by at least 2i-1
  on the identifier circle.

25

• If a node does not knows the successor of a key
  k, it tries to find a node in the finger table
  whose id most immediately precedes k.
• With high probability the number of nodes that
  must be contacted to find a successor in an
  N-node network is O(log N).

26
Node Joins the network

• New node(n) learns the identity of an existing
  Chord node(n') by some means.
• Node n learns its predecessor and fingers by
  asking n' to look them up.
• Node n needs to be entered in the finger tables
  of existing nodes.
• Move responsibility to n for all the keys for
  which node n is now the successor.

27
(No Transcript)
28
Improvements to algorithm

• Use of stabilization protocol to keep node's
  successor pointers up to date.
• When a node n runs stabilize it asks n's
  successors for the successor's predecessor p, and
  decides whether p should be n's successor
  instead.
• When a node n fails, nodes whose finger table
  include n must find n's successors.
• Each node maintains a successor list of its r
  nearest neighbor on the Chord ring.
• If a node notices that its successor has failed,
  it replaces it with the first live entry in its
  successor list.

29
Simulation Experimental Results

• Load Balancing

30
Virtual Nodes
31
Path Length
32
Simultaneous Node failures
33
Experimental Results
34
Few Observations

• Theoretically proved correctness and performance
  in the face of concurrent node arrivals and
  departures.
• Unfortunately, no connection with the physical
  topology.
• Few malicious or buggy Chord participants could
  present an incorrect view of the ring.

35
Questions?
