Pagereplacement policies

1
Page-replacement policies

• On some standard algorithms for the management of
  resident virtual memory pages

2
Use of backing storage

• The Pentiums virtual memory architecture
  supports the swapping of memory pages between
  physical ram and disk storage
• More processes can be in the running state if
  some of their pages are swapped

3
More processes can be running
6 processes
3 processes
PHYSICAL RAM
PHYSICAL RAM
DISK STORAGE
4
Replacing a page

• If a running process needs to reference a page
  that is not current in physical RAM, then that
  page must be read from the disk
• But then some other page current in RAM must be
  overwritten (i.e., replaced)
• Its the Operating Systems job is to decide
  which page will be the one to get replaced

5
What could go wrong?

• If the OS replaces a page that will soon be
  referenced again, then that page will have to be
  re-read back into memory (and some other page
  will need to be replaced)
• Disk-I/O is slow compared to RAM access
• A tasks progress is delayed when it needs to
  wait for disk-I/O operations to complete
• A worst-case senario is disk thrashing

6
Intelligent replacement

• The OS should try to avoid replacing any page
  that will very soon be needed again
• Belady showed (in 1966) that an optimal
  page-replacement policy is to discard the page
  that wont be needed again for the greatest
  amount of time
• But of course the OS has no way to know which
  pages will be needed soonest

7
The LRU policy

• Although the OS cant know the future, it can
  keep track of whats occurred in past
• OS can assume a tasks future behavior will
  probably resemble its past behavior
• So a page that has gone unreferenced for the
  longest amount of time is most likely to
  continue to go unreferenced in future
• This is the Least Recently Used policy

8
LRU is too costly

• Tracking the time when each page gets referenced
  is prohibitively expensive
• For example, with a 4GB physical memory there
  would be one million physical pages
• Hardware would need to support page-tracking in
  parallel with task execution
• So more practical approaches are needed

9
The FIFO policy

• A fixed-size array of pages is organized as a
  ring-buffer (FIRST-IN, FIRST-OUT)
• Whenever a new page must be brought in from the
  disk, it will replace the page that has been in
  RAM for the longest time
• This is simple to implement (and can work well if
  all pages are accessed with roughly the same
  frequency but thats unusual!

10
The CLOCK policy

• An easy way to modify the FIFO policy, so as to
  avoid replacing frequently accessed pages that
  got loaded into RAM very early, is the so-called
  clock policy (also called known as the second
  chance algorithm)
• It uses a single bit of data for each page,
  called the accessed bit (which the CPU
  automatically sets upon a page-access), plus a
  revolving software pointer

11
The clockface pointer
0
0
1
0
1
1
1
0
0 unaccessed 1 accessed
12
How it works

• When a page-replacement is needed, the page
  pointed to is examined
• If its access-bit is 0 (unaccessed), it will get
  replaced, and the pointer will be advanced
• If its access-bit is 1 (accessed), its access-bit
  will be cleared, and the pointer will advance,
  and this will be repeated until an unaccessed
  page is reached (maybe requiring a full circle)
• So accessed pages get a second chance!

13
Clock-policy enhancement?

• The Pentium supports an enhancement to this clock
  page-replacement policy
• Each page-table entry has two sticky bits

5
6
0
31
Page-table entry
A
D
A Accessed the page has been read ( 1 yes,
0 no ) D Dirty the page has been modified (
1 yes, 0 no )
14
Pages clean versus dirty

• When a page is selected for replacement, it does
  not need to be written back to disk unless it has
  been modified (i.e., its dirty)
• So its more efficient if the OS replaces a
  clean page instead of a dirty one
• This leads to an improvement in the clock
  page-replacement policy

15
Keep track of (D,A) bits
1,1
0,0
1,1
0,0
0,1
0,1
1,1
0,0
0,0 unaccessed 0,1 accessed (clean) 1,1
accessed (dirty)
16
How enhancement works

• When a page-replacement is needed, the page
  pointed to is examined (D,A)-bits checked
• If sticky-bits are 0,0 (unaccessed), page is
  replaced and the pointer is advanced
• If sticky-bits are 0,1 (accessed, but clean),
  bits are not changed, but the pointer will be
  advanced
• After a full circle, a second scan begins if a
  clean page is encountered, it gets replaced
  otherwise, after a second full scan (all page are
  dirty), the initial page gets replaced

17
In-class exercise

• Our clockalg.cpp demo simulates three
  page-replacement algorithms optimal, CLOCK, and
  FIFO
• Try adding your own code to implement a
  simulation for the enhanced clock policy
• NOTE youll need to associate a read or
  write attribute with every page-access
