Title: Protoplanetary Disks as Accretion Disks


1
Protoplanetary Disks as Accretion Disks
Roman Rafikov (Princeton)
2
Outline
  • Origin of protoplanetary disks
  • Observational properties
  • Spectra and their formation
  • Angular momentum transport
  • Emphasize differences and similarities with disks
    around compact objects

3
Origin
4
Origin
Collapse of Jeans-unstable dense clumps of
molecular gas. A single time event disk is not
fed externally for a long time.
leads to
Typical accretion rate and time scale
5
Rotational Support
Collapsing cloud slowly rotates at
Conservation of angular momentum leads to disk
formation
Likely that most of the stellar mass has been
processed through the disk. B fields may have
been important.
6
Observational properties
7
Observational properties
8
Observational properties sizes
  • Determined via
  • Hi-res imaging in the visible of scattered (by
    dust) stellar light
  • IR, submm or mm imaging of disks own thermal
    emission
  • IR interferometry can resolve
    sub-AU details
  • SED modelling

Disks sizes range between tens to thousands of
AU, consistent with expectations
9
(No Transcript)
10
Observational properties disk lifetimes
  • Disk age stellar age
  • Determine average disk lifetimes by looking at
    fraction of stars with disks in groups of
    different ages
  • This fraction decays with age
  • Typical lifetimes are of order 1-10 Myrs.
    Disappear due to photoevaporation.

11
Observational properties spectra
  • Protoplanetary disks are usually passive their
    own accretion luminosity is small compared to the
    irradiation by the central star

at r gt 1 AU
  • Irradiated disk is flared

12
Observational properties spectra
Disk flaring plays very important role in shaping
disk spectrum
Spectrum of a flat disk
13
Observational properties masses
14
Minimum Mass Solar Nebula
Protoplanetary Disks
Based on smearing out the refractory content in
SS planets
15
Angular momentum transport
16
Possible angular momentum transport mechanisms
  • Accretion implies outward angular momentum
    transport need some kind of viscosity
  • Keplerian disks are hydrodynamically stable
  • Convection does not provide outward angular
    momentum
  • Magneto-rotational Instability (MRI) is the most
    likely agent, BUT
  • - Unlike the disks around compact objects
    protostellar disks are poorly conducting
  • - MRI gets modified by resistivity in important
    ways (especially at small scales)

17
MRI with resistivity
Lundquist Number
18
Neal Turner
  • Protoplanetary disks around 1 AU are too cold
    for thermal ionization
  • External sources are shielded

Mark Wardle
This gives rise to a dead zone near the disk
midplane (Gammie 1996)
19
Dead zone
Fleming Stone 2003
20
Dead zone
Fleming Stone 2003
  • While magnetic stress virtually dies out in the
    dead zone, Reynolds stress
    gets transmitted

    (albeit at low levels)
    into this zone

    maintaining some
    transport there.
  • Accretion rate is not constant in the dead zone
    - long term steady state is not possible

21
Other things to worry about
  • Other non-ideal MRI effects
  • Ambipolar diffusion
  • Hall effect
  • Dust
  • Small dust grains are efficient charge absorbers
  • Abundance of small dust grains is poorly known
  • Dust can grow and sediment towards midplane
  • This can lead to streaming instabilities and
    turbulence
  • Planets
  • Density waves lead to outward angular momentum
    transport

22
Comparison with disks around compact objects
23
Conclusions
  • Protoplanetary disks are cold, massive accretion
    disks surrounding young stars
  • Stars likely form via fast accretion in the
    initial phases of the disk life
  • They are likely transient objects lifetimes
    1-10 Myrs
  • They are passive, heated mainly by their central
    stars, emit mainly in the IR and sub-mm range
  • Accretion is likely due to MRI, which is
    significantly modified by the non-ideal effects
  • Low ionization makes resistivity very low and
    damps MRI in some parts of the disks creating
    dead zones
