LOGIC:

1
LOGIC

• SYLLOGISMS

2
Syllogism A set of statements called premises,
which lead to one logical conclusion.
3
If the premises are true, (and we assume they
are), then the conclusion must be true.
4
(Note This symbol means Therefore.
It signals the conclusion.)
5
Law of Syllogism
6

• If a figure is a rectangle, then it is a
  parallelogram.
• If a figure is a parallelogram, then its
  diagonals bisect each other.
• __________________________

7

• If a figure is a rectangle, then it is a
  parallelogram.
• If a figure is a parallelogram, then its
  diagonals bisect each other.
• __________________________

8

• If a figure is a rectangle, then it is a
  parallelogram.
• If a figure is a parallelogram, then its
  diagonals bisect each other.
• __________________________

9

• If a figure is a rectangle, then it is a
  parallelogram.
• If a figure is a parallelogram, then its
  diagonals bisect.
• __________________________

If a figure is a rectangle, then its diagonals
bisect.
10
Law of Detachment
11

• If a figure is a rectangle, then it is a
  parallelogram.
• ABCD is a rectangle.
• __________________________

12

• If a figure is a rectangle, then it is a
  parallelogram.
• ABCD is a rectangle.
• __________________________

13

• If a figure is a rectangle, then it is a
  parallelogram.
• ABCD is a rectangle.
• __________________________

ABCD is a parallelogram.
14
Law of Contrapositive
15

• If a figure is a rectangle, then it is a
  parallelogram.
• ABCD is not a parallelogram.
• __________________________

16

• If a figure is a rectangle, then it is a
  parallelogram.
• ABCD is not a parallelogram.
• __________________________

17

• If a figure is a rectangle, then it is a
  parallelogram.
• ABCD is not a parallelogram.
• __________________________

ABCD is not a rectangle.
18
Time to Practice
19
In the following examples, use the given law of
syllogism to draw the correct conclusion from the
set of premises.
20
1. If frogs fly then toads talk. Frogs
fly. -----------------------------
21
Law of Detachment
22
1. If frogs fly then toads talk. Frogs
fly. -----------------------------
23
1. If frogs fly then toads talk. Frogs
fly. ----------------------------- Toads
talk.
24
2. If hens heckle then crows dont care. Crows
care. -----------------------
25
Law of Contrapositive
26
2. If hens heckle then crows dont care. Crows
care. -----------------------
27
2. If hens heckle then crows dont care. Crows
care. ----------------------- Hens dont
heckle.
28
3. If ants dont ask then flies dont fret. Ants
dont ask. ----------------------------
29
Law of Detachment
30
3. If ants dont ask then flies dont fret. Ants
dont ask. ----------------------------
31
3. If ants dont ask then flies dont fret. Ants
dont ask. ---------------------------- Flies
dont fret.
32
4. If Dave dives then Cal caves. If Cal caves
then Hank hikes. ---------------------------------
----
33
Law of Syllogism
34
4. If Dave dives then Cal caves. If Cal caves
then Hank hikes. ---------------------------------
----
35
4. If Dave dives then Cal caves. If Cal caves
then Hank hikes. ---------------------------------
---- If Dave dives then Hank hikes.
36
5. If dogs duel then rats wrestle. Rats dont
wrestle. -----------------------------
37
Law of Contrapositive
38
5. If dogs duel then rats wrestle. Rats dont
wrestle. -----------------------------
39
5. If dogs duel then rats wrestle. Rats dont
wrestle. ----------------------------- Dogs
dont duel.
40
Why does this one work?
41
Here are the premises
42
Replace with contrapositive
43
Replace with contrapositive
44
Use Law of Detatchment
45
Law of Contrapositive
