M'Sc Computing Science Software Engineering Lecture 8

1
M.Sc Computing Science Software Engineering
Lecture 8

• Niki Trigoni
• Department of Computer Science
• and Information Systems
• Birkbeck College, University of London
• Email niki_at_dcs.bbk.ac.uk
• Web Page http//www.dcs.bbk.ac.uk/niki

2
Review of lecture 7

• We identified new requirements in Iteration 2 of
  elaboration
• Support for variations in third-party external
  services
• Complex pricing rules
• Pluggable business rules
• GUI window updates when information changes
• We focused on first requirement and introduced a
  set of patterns to help its design
• GRASP Polymorphism, Pure Fabrication,
  Indirection, Protected Variations
• GoF Adapter, Factory and Singleton

3
Overview of lecture 8

• Examples of applying the following patterns
• GRASP Polymorphism, Pure Fabrication,
  Indirection, Protected Variations
• GoF Adapter, Factory and Singleton
• More GoF patterns
• Strategy and Composite
• Facade
• applicable to requirements
• Complex pricing rules
• Pluggable business rules

4
Orientation within the Unified Process
quick overview
focus of this lecture
5
Polymorphism example

• When related alternatives or behaviors vary by
  type (class), assign the same name to services
  (methods) in different classes. The different
  classes usually implement a common interface or
  have a common superclass.
• Example
• Consider a bank application with two types of
  accounts CheckingAccount and SavingsAccount.
• Suppose that you want to evaluate for each
  account the interest accumulated over a period.
• The implementation of evaluating interest is
  different for each account type. It uses a
  different set of interest rates.

6
Polymorphism example (cont.)

• Solution 1 Class SavingsAccount with method
  getSavAccInterest(startDate, endDate), and class
  CheckingAccount with method getChAccInterest(start
  Date, endDate).
• First go through objects of class SavingsAccount
  and invoke their method getSavAccInterest()
• Then go through objects of class CheckingAccount
  and invoke their method getChAccInterest()
• Solution 2 Same as Solution 1, but
  SavingsAccount and CheckingAccount have the same
  superclass Account.
• Go through all objects of class Account. If an
  object is of subclass SavingsAccount, invoke
  getSavAccInterest(), else invoke
  getChAccInterest()

7
Polymorphism example (cont.)

• Solution 3 Class SavingsAccount with method
  getInterest(startDate, endDate), and class
  CheckingAccount with method getInterest(startDate,
  endDate) inherit from a common superclass with
  method getInterest(startDate, endDate).
• Go through all objects of class Account. Invoke
  their method getInterest()
• What are the advantages of solution 3 over the
  previous two solutions?
• In terms of code
• In terms of maintenance

8
Pure Fabrication example

• Assign a highly cohesive set of responsibilities
  to an artificial or convenience class that does
  not represent a problem domain concept
  something made up to support high cohesion, low
  coupling, and reuse.
• Example Consider a bank application with objects
  of class Account, Customer, Transaction etc.
  that need to be inserted into, updated, or
  deleted from the database.
• Solution 1 By Information Expert, assign methods
  insertIn(OODB db), update(OODB db),
  deleteFrom(OODB db) to classes Account, Customer,
  Transaction etc.
• Solution 2 Use polymorphism and assign methods
  insertIn(OODB db), update(OODB db),
  deleteFrom(OODB db) to superclass Object.

9
Pure Fabrication example (cont.)

• Solution 3 Since these functions are highly
  correlated, and they do not concern domain logic,
  group them together into class OODB with methods
  insert(Object obj), delete(Object obj),
  update(Object obj).
• What are the advantages of solution 2 over
  solution 1?
• What are the advantages of solution 3 over
  solution 2?

10
Indirection example

• Avoid creating multiple couplings to an unstable
  class C1?UnstClass, C2 ?UnstClass,, Cm
  ?UnstClass. Instead, devise a mediator stable
  class StableClass, and use it to connect
  indirectly C1, , Cm with UnstClass.
• Example Suppose that our company initially
  decides to use an object-oriented database
  system. If performance issues arise, the company
  will switch to a relational db. How should we
  perform database-related operations for storing
  objects of classes Transaction, Account,
  Customer, etc.?
• Solution 1 Wherever db operations are needed in
  the code interact directly with an object of
  class OODB to perform them.

11
Indirection example

• Solution 2 Wherever db operations are needed in
  the code interact with an object of a new class
  PersistentStorage to perform them. The methods of
  PersistentStorage (insert, update, delete) invoke
  the corresponding methods of OODB.
• Which solution do you prefer?
• What is the impact of change (to relational DB)
  for each one of the solutions?

12
Protected Variations example

• Design objects, systems and subsystems so that
  the variations and instability in these elements
  does not have an undesirable impact on other
  elements.
• All previous examples are instances of applying
  this general principle.
• Another example is the Dont Talk to Strangers
  principle avoid sending messages to distant,
  indirect objects, because this leads to fragile
  code fragments.
• Example Suppose that within a method of Sale, we
  want to access the holder of the account of the
  payment of this sale.
• Sale has an attribute paymentPayment
• Payment has an attribute accountAccount
• Account has an attribute holderPerson.

13
Protected Variations example (cont.)

• Solution 1
• public void methodOfSale()
• Person holder this.getPayment().getAccount
  ().getHolder()
• Solution 2
• public void methodOfSale()
• Person holder this.getAccountHolderOfPayme
  nt()
• Which solution do you prefer and why?

14
Adapter (GoF) example

• Use adapter classes when in need of common stable
  interface to similar classes with different
  interfaces
• Example Consider the problem of processing
  payments in a store using two external credit
  services
• Visa.sendPayment(cardID, sale.amount)
• Mastercard.makePayment(cardID, sale.amount,
  sale.date)
• Solution 1 In method Sale.makePayment method, we
  check whether the cardID corresponds to a Visa or
  a Mastercard and we invoke either of the methods
  accordingly.
• Visa.sendPayment(cardID, sale.amount)
• Mastercard.makePayment(cardID, sale.amount,
  sale.date)

15
Adapter (GoF) example (cont.)

• Solution 2 We create two adapter classes,
  VisaAdapter and MastercardAdapter, with the same
  method signature arrangePayment(cardIDCardID,
  saleSale). Continue
• Which solution do you prefer and why?
• Can you think of other scenarios where adapters
  are useful?

16
Factory (GoF) example

• Use Factory objects to create objects when
  creation logic is complex, or efficient memory
  management is needed, or many related creation
  responsibilities should be separated for better
  cohesion.
• Example Suppose that a store adjusts the prices
  of its products each day. Based on the profits of
  the previous 10 days and the recommendations of
  managers, it comes up with a different pricing
  policy. How do we apply the daily pricing policy
  to sales?

17
Factory (GoF) example

• Solution 1 Each Sale object constructs a new
  PricingPolicy object by passing as arguments the
  date, profits, etc.
• Solution 2 Like Solution 1, except that the
  Register object constructs the PricingPolicy
  object once and makes it visible to each Sale.
• Solution 3 A new PricingPolicyFactory is defined
  that is responsible for instantiating the
  PricingPolicy object at the beginning of each day
  (or when the first Sale occurs).
• Which solution do you prefer and why?
• In solution 3, who creates the PricingPolicyFactor
  y object and how does it become visible to Sale
  objects.

18
Singleton (GoF) example

• How to get global visibility to a single instance
  of a class?
• Example How will Sale objects obtain visibility
  to the PricingPolicy instance created at the
  beginning of the day?
• Solution 1 Create a PricingPolicyFactory
  instance in Register, call its method
  getPricingPolicy and store the PricingPolicy
  object as an attribute of Register. Register will
  then pass it as parameter to all invocations of
  Sale methods.
• Solution 2 Create a PricingPolicyFactory
  instance in Register, call its method
  getPricingPolicy (like solution 1). Get global
  visibility to the policy instance, by invoking a
  static method PricingPolicy.getInstance().

19
Singleton (GoF) example (cont.)

• Solution 3 Get global visibility to a
  PricingPolicyFactory instance by calling
  PricingPolicyFactory.getInstance(). Let factory
  be the returned object. Then get the actual
  pricingPolicy object by calling
  factory.getPricingPolicy(). Think of an efficient
  implementation of the last method.
• Which solutions apply the Singleton pattern and
  at which point?

20
Overview of lecture 8

• Examples of applying the following patterns
• GRASP Polymorphism, Pure Fabrication,
  Indirection, Protected Variations
• GoF Adapter, Factory and Singleton
• More GoF patterns
• Strategy and Composite
• Facade
• applicable to requirements
• Complex pricing rules
• Pluggable business rules

21
Complex pricing rules

• There may be more than one pricing
  policies/strategies for a sale
• 10 off for one period
• 10 pounds off if the sale is greater than 100
  pounds
• senior person discount of 5
• Sunday sale for specific items
• a combination of simple policies

22
The Strategy (GoF) pattern
Problem How to design for varying, but related
algorithms or policies? How to design for the
ability to change these algorithms or
policies? Solution Define each
algorithm/policy/strategy in a separate class
with a common interface. Which GRASP pattern
does this remind you of? How can it be used to
address the need for complex pricing rules?
23
Strategy (GoF) example
ltltinterfacegtgt ISalePriceStrategy getTotal(Sale)M
oney
PercDiscountSaleStrategy percentage getTotal(Sal
e)Money
AbsoluteDiscountPriceStrategy discountMoney
thresholdMoney getTotal(Sale)Money
24
The Composite (GoF) pattern
Problem How to treat a group or composition
structure of objects the same way
(polymorphically) as a non-composite atomic
object? Solution Define classes for composite
and atomic objects so that they implement the
same interface. How can this pattern be used to
address the need for complex pricing rules?
25
Composite (GoF) pattern example
ltltinterfacegtgt ISalePriceStrategy getTotal(Sale)M
oney
pricingStrategies
1..
CompositePriceStrategy add(ISalePriceStrategy) g
etTotal(Sale)Money
PercDiscSaleStrategy percentage getTotal(Sale)M
oney
AbsoluteDiscount PriceStrategy discountMoney
thresholdMoney getTotal(Sale)Money
Composite1Strategy getTotal(Sale)Money
Composite2Strategy getTotal(Sale)Money
26
Composite (GoF) pattern example (cont.)
public abstract class CompositePriceStrategy
implements ISalePriceStrategy protected List
pricingStrategies new ArrayList() public add
(ISalePricingStrategy s) pricingStrategies.add
(s). public abstract Money
getTotal ( Sale sale) //end of class public
class Composite1Strategy extends
CompositePriceStrategy public Money
getTotal(Sale sale) Money lowestTotal new
Money (Integer.MAX_VALUE) for (Iterator i
pricingStrategies.iterator() i.hasNext()) I
SalePricingStrategy strategy(ISalePricingStrategy
)i.next() Money total strategy.getTotal(sal
e) lowestTotal total.min(lowestTotal)
return lowestTotal
27
Pluggable business rules

• We would like to customize the behavior of the
  system based on a set of business rules
• If a sale is paid by a gift certificate, the sale
  must contain only one item. Subsequent items must
  be invalidated.
• If the sale is paid by a gift certificate, change
  is given only by means of another gift
  certificate, but not in cash.
• A new sale may be created for charitable
  donation, only if the currently logged in
  cashier is a manager.
• Goal
• Implement these rules with as low impact as
  possible on the existing code
• Keep coupling low

28
The Facade (GoF) pattern
Problem A common, unified interface to a
disparate set of implementations or interfaces is
required. There may be undesirable coupling to
many things in the subsystem, or the
implementation of the subsystem may change. What
to do? Solution Define a single point of
contact to the subsystem a facade object that
wraps the subsystem. This facade object presents
a single unified interface and is responsible for
collaborating with the subsystem
components. How can this pattern be used to
address the need for pluggable business rules?
29
Facade (GoF) pattern example
public class Sale public void makeLineItem
(ProductSpec spec, int quantity) //call to
the Facade if ( RuleEngineFacade.getInstance().i
sInvalid ( sli,this ) ) return lineItems.add
(sli)
1

RuleEngineFacade InstanceRuleEngineFacade get
Instance()RuleEngineFacade isInvalid(SalesLineIte
m, Sale) isInvalid(Payment, Sale)

• ltltinterfacegtgt
• IRule

• Rule1

• Rule2

30
Summary of lecture 8

• We elaborated on the principles of polymorphism,
  indirection, pure fabrication, adapter, factory
  etc. used during software design.
• We used examples to discover benefits of design
  patterns
• reusable code
• programs easy to understand and maintain
• low impact of requirements changes
• We introduced three new GoF design patterns i)
  strategy, ii) composite and iii) facade
• We applied these patterns in order to provide
  good designs for the following requirements
• complex pricing rules (strategy and composite)
• pluggable business rules (facade)
