Use of RCP for Instrument Control

1
Use of RCP forInstrument Control

• Tony Lam
• 2006 Eclipse Meeting _at_ SLAC

2
Outline

• GumTree
• GumTree Demo
• GumTree Vista
• Scientific Eclipse
• NOMAD (ILL)
• FABLE (ESRF)
• Collaboration Issues

3
Problem Domain Complex Instrument Ecosystem
Web Resource
Web Service
Proposal DB
GRID
Control System
Data Archive
Internet
Instrument Server
Device Server
Device Drivers
4
Solution Integrated Scientific Experiment
Environment
Web Resource
Web Service
Proposal DB
GRID
Control System
Data Archive
Internet
Instrument Server
Device Server
Device Drivers
ISEE!!
cf. IDE
5
GumTree Project

• GumTree is a scientific workbench that manages
  the complete experiment lifecycle for users
• Integrated Scientific Experiment Environment
• Instrument Control Data Acquisition
• Online and Offline Data Analysis
• Electronic Laboratory Notebook Report (OLE,
  BIRT)
• proposed Collaborative environment for
  multi-national experiment (ECF)

6
(No Transcript)
7
(No Transcript)
8
Demo

• 6 minutes demo

9
GumTree Vista

• GumTree has been built on a new architecture,
  with codename Vista

GumTree
10
New Architecture
GumTree RCP GumTree RAP
Swing Based Diagnostic Tools
J2EE Web Interface
Instrument Model Server
Batch Server
Instrument model definition
Project Vista
Control System (SICS, EPICS, TANGO)
11
GumTree Vista

• Motivation
• Data analysis team wants to access experiment
  data via instrument component
• Web interface for status monitoring
• Model / data flow driven development
• GumTree RCP remains its role as the integrated
  scientific workbench
• First prototype will be available on Jul 06

12
New Features

• What can GumTree Vista offer
• Simplified API for adapting to other control
  system
• Stronger security in new layered architecture
• Validation of user request based on various
  sources (eg current instrument status, database,
  etc)
• Multi-clients connectivity (independent of
  technology choice)

13
RCP Control System

• Controlling instrument via instrument model
  (JaveBean data structure)
• Instrument model server can produces a model
  driven data set
• Instrument model server can be adapted to other
  control system

14
(No Transcript)
15
RCP Visualisation

• Visualisation component will be split into two
  levels
• General purpose SWT widget with no dependency on
  the rest of GumTree system
• Extension of GumTree (allows binding with
  internal GumTree data for display)

extends
extends
SWT VIS
SWT/OpenGL
NeXus VIS
GumTree VIS
Can be used by other SWT/RCP applications
16
RCP Data

• Internal data format has been chosen to Extended
  NeXus format
• It describes the whole instrument model
• Strong linking to control system, experiment
  setup (via wizard), monitoring, etc
• NeXus format can be transformed to other data
  format via XSLT (heavy commitment by ANSTOs data
  analysis team)
• Another possible GumTree internal data
  representation EMF

17
Data Analysis
Run algorithm remotely by RMI, TANGO, Web Service
(GRID), or PTP API??
18
DANSE like simplified scientific workflow
19
(No Transcript)
20
(No Transcript)
21
NOMAD

• Developed by Institut Laue-Langevin (France)
• To be deployed on 11 neutron beam instruments in
  June
• Based on SWT and OpenGL
• User interface components are generated by XML
  definition (like XSWT)
• Has a cool way to perform experiment!
• Collaboration? Well, its not open source.

22
FABLE

• Joint collaboration between ESRF (France) and
  Risø Institute (Denmark)
• Scientific workbench for crystallography data
  analysis with synchrotron data
• Can be extended to acquire data from the
  synchrotron beamline.
• http//fable.sourceforge.net/wiki/index.php/Main_P
  age

23
Collaboration

• Share development experience
• Discussion
• Recommendations
• Do not duplicate our efforts
• Reusable code / plugin
• Manage existing open source projects

24
Possible Collaboration Methods

• Scientific Plugin Library
• Every facility requires different system
  architecture
• Sharing codes in plugin level is more realistic
• SciForge.net??
• Eclipse based scientific community
• A community under Eclipse Foundation
• Benefits website space, mailing list, bugzilla,
  newsgroup, gaining publicity in mainstream IT
  industry
• Drawback management is time consuming

25
Case Study onEclipse Community Model

• A dedicated scientific eclipse project
• Example Parallel Tools Platform (PTP) Project
• Managing individual sub-projects under a
  community
• Example Generative Model Transformer (GMT)
  Project
• Promotion of Eclipse technology with almost no
  software artefacts
• Example Eclipse Community Education Project
  (ECESIS)

26
Case Study onEclipse Community Model

• Foundation Member Working Groups
• Example Japan Working Group
• Should we call ourselves Scientific Woking
  Group??
• Initial subproject under existing Eclipse
  Technology Project
• Example NO
• Greg Watson (Los Alamos Cluster computing team)
  from PTP has offered his help

27
Conclusion

• Increasing adoption of Eclipse Technology creates
  opportunity for us to share codes
• Question Are we on the same road?
