Title: Cellular Pathways that Harvest Chemical Energy


1
Cellular Pathways that Harvest Chemical Energy
2
Energy and Electrons from Glucose
  • The sugar glucose (C6H12O6) is the most common
    form of energy molecule.
  • Cells obtain energy from glucose by the chemical
    process of oxidation in a series of metabolic
    pathways.
  • However, cells can also obtain energy from
    lipids, proteins and nucleic acids as well as
    carbohydrates.

3
Energy and Electrons from Glucose
  • Principles governing metabolic pathways
  • Each reaction in the pathway is catalyzed by a
    specific enzyme.
  • Metabolic pathways are similar in all organisms.
  • In eukaryotes, many metabolic pathways are
    compartmentalized in organelles.
  • The operation of each metabolic pathway can be
    regulated by the activities of key enzymes.

4
Energy and Electrons from Glucose
  • When burned in a flame, glucose releases heat,
    carbon dioxide, and water.
  • C6H12O6 6 O2 6 CO2 6 H2O energy
  • The same equation applies for the biological,
    metabolic use of glucose.

5
Energy and Electrons from Glucose
  • About half of the energy from glucose is
    collected in ATP.
  • ?G for the complete conversion of glucose is
    686 kcal/mol.
  • The reaction is therefore highly exergonic, and
    it drives the endergonic formation of ATP.

6
Energy and Electrons from Glucose
  • Three metabolic processes are used in the
    breakdown of glucose for energy
  • Glycolysis
  • Cellular respiration
  • Fermentation

7
Figure 7.1 Energy for Life
8
Energy and Electrons from Glucose
  • Glycolysis produces some usable energy and two
    molecules of a three-carbon sugar called
    pyruvate.
  • Glycolysis begins glucose metabolism in all
    cells.
  • Glycolysis does not require O2 it is an
    anaerobic metabolic process.

9
Energy and Electrons from Glucose
  • Cellular respiration uses O2 and occurs in
    aerobic (oxygen-containing) environments.
  • Pyruvate is converted to CO2 and H2O.
  • The energy stored in covalent bonds of pyruvate
    is used to make ATP molecules.

10
Energy and Electrons from Glucose
  • Fermentation does not involve O2. It is an
    anaerobic process.
  • Pyruvate is converted into lactic acid or
    ethanol.
  • Breakdown of glucose is incomplete less energy
    is released than by cellular respiration.

11
Energy and Electrons from Glucose
  • Redox reactions transfer the energy of electrons.
  • A gain of one or more electrons or hydrogen atoms
    is called reduction.
  • The loss of one or more electrons or hydrogen
    atoms is called oxidation.
  • Whenever one material is reduced, another is
    oxidized.

12
Figure 7.2 Oxidation and Reduction Are Coupled
13
Energy and Electrons from Glucose
  • An oxidizing agent accepts an electron or a
    hydrogen atom.
  • A reducing agent donates an electron or a
    hydrogen atom.
  • During the metabolism of glucose, glucose is the
    reducing agent (and is oxidized), while oxygen is
    the oxidizing agent (and is reduced).

14
Energy and Electrons from Glucose
  • The coenzyme NAD is an essential electron carrier
    in cellular redox reactions.
  • NAD exists in an oxidized form, NAD, and a
    reduced form, NADH H.
  • The reduction reaction requires an input of
    energy
  • NAD 2H NADH H
  • The oxidation reaction is exergonic
  • NADH H ½ O2 NAD H2O

15
Figure 7.3 NAD Is an Energy Carrier
16
Figure 7.4 Oxidized and Reduced Forms of NAD
17
Energy and Electrons from Glucose
  • The energy-harvesting processes in cells use
    different combinations of metabolic pathways.
  • With O2 present, four major pathways operate
  • Glycolysis
  • Pyruvate oxidation
  • The citric acid cycle
  • The respiratory chain (electron transport chain)
  • When no O2 is available, glycolysis is followed
    by fermentation.

18
Table 7.1 Cellular Locations for Energy Pathways
in Eukaryotes and Prokaryotes
19
Glycolysis From Glucose to Pyruvate
  • Glycolysis can be divided into two stages
  • Energy-investing reactions that use ATP
  • Energy-harvesting reactions that produce ATP

20
Glycolysis From Glucose to Pyruvate
  • The energy-harvesting reactions of glycolysis
  • The first reaction (an oxidation) releases free
    energy that is used to make two molecules of NADH
    H, one for each of the two G3P molecules.
  • Two other reactions each yield one ATP per G3P
    molecule. This part of the pathway is called
    substrate-level phosphorylation.
  • The final product is two 3-carbon molecules of
    pyruvate.

21
Figure 7.6 Glycolysis Converts Glucose to
Pyruvate (Part3)
22
Figure 7.6 Glycolysis Converts Glucose to
Pyruvate (Part 4)
23
Figure 7.7 Changes in Free Energy During
Glycolysis
24
Pyruvate Oxidation
  • Pyruvate is oxidized to acetate which is
    converted to acetyl CoA.
  • Pyruvate oxidation is a multistep reaction
    catalyzed by an enzyme complex attached to the
    inner mitochondrial membrane.
  • The acetyl group is added to coenzyme A to form
    acetyl CoA. One NADH H is generated during
    this reaction.

25
Figure 7.8 Pyruvate Oxidation and the Citric
Acid Cycle (Part 1)
26
The Citric Acid Cycle
  • The citric acid cycle (Krebs Cycle) begins when
    the two carbons from the acetate are added to
    oxaloacetate, a 4-C molecule, to generate
    citrate, a 6-C molecule.
  • A series of reactions oxidize two carbons from
    the citrate. With molecular rearrangements,
    oxaloacetate is formed, which can be used for the
    next cycle.
  • For each turn of the cycle, three molecules of
    NADH H, one molecule of ATP, one molecule of
    FADH2, and two molecules of CO2 are generated.

27
Figure 7.8 Pyruvate Oxidation and the Citric
Acid Cycle (Part 2)
For each molecule of glucose, the net gain is 6
NADH, 2 FADH2 and 2 ATP
28
The Respiratory ChainElectrons, Protons, and
ATP Production
  • The respiratory chain uses the reducing agents
    generated by pyruvate oxidation and the citric
    acid cycle. (NADH and FADH)
  • The flow of electrons in a series of redox
    reactions causes the active transport of protons
    across the inner mitochondrial membrane, creating
    a proton concentration gradient.
  • The protons then diffuse through proton channels
    down the concentration and electrical gradient
    back into the matrix of the mitochondria,
    creating ATP in the process.
  • ATP synthesis by electron transport is called
    oxidative phosphorylation.

29
The Respiratory ChainElectrons, Protons, and
ATP Production
  • The respiratory chain consists of four large
    protein complexes bound to the inner
    mitochondrial membrane, plus cytochrome c and
    ubiquinone (Q).

30
Figure 7.10 The Oxidation of NADH H
31
The Respiratory ChainElectrons, Protons, and
ATP Production
  • As electrons pass through the respiratory chain,
    protons are pumped by active transport into the
    intermembrane space against their concentration
    gradient.
  • This transport results in a difference in
    electric charge across the membrane.
  • The potential energy generated is called the
    proton-motive force.

32
The Respiratory ChainElectrons, Protons, and
ATP Production
  • Chemiosmosis is the coupling of the proton-motive
    force and ATP synthesis.
  • NADH H or FADH2 yield energy upon oxidation.
  • The energy is used to pump protons into the
    intermembrane space, contributing to the
    proton-motive force.
  • The potential energy from the proton-motive force
    is harnessed by ATP synthase to synthesize ATP
    from ADP.

33
Figure 7.12 A Chemiosmotic Mechanism Produces
ATP (Part 1)
34
Figure 7.12 A Chemiosmotic Mechanism Produces
ATP (Part 2)
35
The Respiratory ChainElectrons, Protons, and
ATP Production
  • Synthesis of ATP from ADP is reversible.
  • The synthesized ATP is transported out of the
    mitochondrial matrix as quickly as it is made.
  • The proton gradient is maintained by the pumping
    of the electron transport chain.

36
The Respiratory ChainElectrons, Protons, and
ATP Production
  • Two key experiments demonstrated that
  • A proton gradient across a membrane can drive ATP
    synthesis.
  • The enzyme ATP synthase is the catalyst for this
    reaction.

37
Figure 7.13 Two Experiments Demonstrate the
Chemiosmotic Mechanism
38
Fermentation ATP from Glucose, without O2
  • When there is an insufficient supply of O2, a
    cell cannot reoxidize cytochrome c.
  • Then QH2 cannot be oxidized back to Q, and soon
    all the Q is reduced.
  • This continues until the entire respiratory chain
    is reduced.
  • NAD and FAD are not generated from their reduced
    form.
  • Pyruvate oxidation stops, due to a lack of NAD.
  • Likewise, the citric acid cycle stops, and if the
    cell has no other way to obtain energy, it dies.

39
Fermentation ATP from Glucose, without O2
  • Some cells under anaerobic conditions continue
    glycolysis and produce a limited amount of ATP if
    fermentation regenerates the NAD to keep
    glycolysis going.
  • Fermentation uses NADH H to reduce pyruvate,
    and consequently NAD is regenerated.

40
Fermentation ATP from Glucose, without O2
  • Some organisms are confined to anaerobic
    environments and use only fermentation.
  • These organisms lack the molecular machinery for
    oxidative phosphorylation.
  • They also lack enzymes to detoxify the toxic
    by-products of O2, such as H2O2.

41
Fermentation ATP from Glucose, without O2
  • In lactic acid fermentation, an enzyme, lactate
    dehydrogenase, uses the reducing power of NADH
    H to convert pyruvate into lactate.
  • NAD is replenished in the process.
  • Lactic acid fermentation occurs in some
    microorganisms and in muscle cells when they are
    starved for oxygen.

42
Figure 7.14 Lactic Acid Fermentation
43
Fermentation ATP from Glucose, without O2
  • Alcoholic fermentation involves the use of two
    enzymes to metabolize pyruvate.
  • First CO2 is removed from pyruvate, producing
    acetaldehyde.
  • Then acetaldehyde is reduced by NADH H,
    producing NAD and ethanol.

44
Figure 7.15 Alcoholic Fermentation
45
Contrasting Energy Yields
  • A total of 36 ATP molecules can be generated from
    each glucose molecule in glycolysis and cellular
    respiration.
  • Each NADH H generates 3 ATP molecules, and
    each FADH2 generates 2 ATP by the chemiosmotic
    mechanism.
  • Fermentation has a net yield of 2 ATP molecules
    from each glucose molecule.
  • The end products of fermentation contain much
    more unused energy than the end products of
    aerobic respiration.

46
Figure 7.16 Cellular Respiration Yields More
Energy Than Glycolysis Does (Part 1)
47
Figure 7.16 Cellular Respiration Yields More
Energy Than Glycolysis Does (Part 2)
48
Relationships between Metabolic Pathways
  • Glucose utilization pathways can yield more than
    just energy. They are interchanges for diverse
    biochemical traffic.
  • Intermediate chemicals are generated that are
    substrates for the synthesis of lipids, amino
    acids, nucleic acids, and other biological
    molecules.

49
Figure 7.17 Relationships Among the Major
Metabolic Pathways of the Cell
50
Relationships between Metabolic Pathways
  • What happens if inadequate food molecules are
    available?
  • Glycogen stores in muscle and liver are used
    first.
  • Fats are used next. But the brain can only use
    glucose, so it must be synthesized by
    gluconeogenesis which uses mostly amino acids.
  • Therefore, proteins must be broken down.
  • After fats are depleted, proteins alone provide
    energy.

51
Relationships between Metabolic Pathways
  • The levels of the products and substrates of
    energy metabolism are remarkably constant.
  • Cells regulate the enzymes of catabolism and
    anabolism to maintain a balance, or metabolic
    homeostasis.

52
Regulating Energy Pathways
  • Metabolic pathways work together to provide cell
    homeostasis.
  • Positive and negative feedback control whether a
    molecule of glucose is used in anabolic or
    catabolic pathways.

53
Regulating Energy Pathways
  • The amount and balance of products a cell has is
    regulated by allosteric control of enzyme
    activities.
  • Control points use both positive and negative
    feedback mechanisms.
  • The main control point in glycolysis is the
    enzyme phosphofructokinase.
  • This enzyme is inhibited by ATP and activated by
    ADP and AMP.

54
Regulating Energy Pathways
  • The main control point of the citric acid cycle
    is the enzyme isocitrate dehydrogenase which
    converts isocitrate to a-ketoglutarate.
  • NADH H and ATP are inhibitors of this enzyme.
    NAD and ADP are activators of it.
  • Accumulation of isocitrate and citrate occurs,
    but is limited by the inhibitory effects of high
    ATP and NADH.
  • Citrate acts as an additional inhibitor to slow
    the fructose 6-phosphate reaction of glycolysis
    and also switches acetyl CoA to the synthesis of
    fatty acids.

55
Figure 7.20 Feedback Regulation of Glycolysis
and the Citric Acid Cycle (Part 1)
56
Figure 7.20 Feedback Regulation of Glycolysis
and the Citric Acid Cycle (Part 2)
Write a Comment
User Comments (0)
About PowerShow.com
