The Intel Itanium 2 Architecture

1
The Intel Itanium 2 Architecture

• By
• Alexandra Martinez

2
Contents

• Overview
• EPIC Model
• The Itanium 2 Processor and Pipeline
• Instruction Processing
• Instruction Execution
• Control
• Memory Subsystem
• Conclusions
• Bibliographic Sources

3
1.Overview

• Itanium 2 is the second implementation of the
  Itanium ISA.
• EPIC for scaling performance increasing ILP.
• 6-wide, 8-stage deep pipeline running at 1.5 GHz.
• Resources
• 6 integer and 6 multimedia ALUs,
• 2 load and 2 store units,
• 3 branch units,
• 2 extended-precision and 2 single-precision FP
  units
• 128 integer reg, 128 FP reg, 8 branch reg, 64
  predicate reg.
• Can fetch, issue, execute, and retire 6 instr (2
  bundles) / clock.
• Three levels of on-die cache minimize memory
  latency.
• Uses dynamic prefetch, branch prediction,
  register scoreboard.
• System bus for MP support (up to 4 proc/bus)
  building block

4
1.1 EPIC Explicitly Parallel Instruction
Computing Model

• Designed to achieve high degree of parallelism.
• Provides tighter coupling between hardware and
  software.
• Compiler exploits compile-time information to
  optimize code.
• Processor executes instructions as rapidly as
  possible.
• Current Itanium processors can execute up to 6
  instructions in parallel.
• Increased parallelism will be enabled by EPIC on
  future processor generations.
• Maximum number of simultaneous instructions is
  not the only measure of performance.
• The processor must sustain high levels of
  parallelism to optimize total throughput, e.g.
  extensive computational resources, predication
  and speculation.

5
1.2 Predication

• Conditional branches would normally stall the
  processor until the conditional statement is
  processed .
• In branch-intensive code, this can become a major
  limitation for the overall throughput .
• With EPIC model Predication
• Predication allows the compiler to explicitly
  identify instruction streams that can be
  processed in parallel.
• Also allows the processor to pre-load
  instructions and data and begin processing for
  both branches simultaneously.
• Once the conditional statement is processed, the
  information gathered for the incorrect path is
  simply discarded.
• Improves performance by eliminating branches and
  associated branch misprediction penalties.

6
1.3 Speculation

• Speculation allows the compiler to identify
  future data needs, so data can be loaded ahead of
  branches and stores.
• Helps hiding memory latency.
• Intel Itanium 2 Processors include a
  fully-associative Advanced Load Address Table
  (ALAT), which manages speculative data more
  efficiently.
• Reduces penalty (recovery time) for a wrong
  speculation.
• The Itanium 2 cache subsystem also accelerates
  speculative data loading.
• Data can be stored and read faster from this
  integrated cache than from an out-of-processor
  cache.

7

• 2. The Itanium 2 Processor
• and Pipeline

8
2.1 The Pipeline
Exception detection
Write Back
Instruction Fetch
Instruction Rotation
Expand (disperse)
Register Rename
Register Read
9
2.2 The Processor
Instruction Processing
IA-32 execution engine
Control Block
Memory Subsystem
Execution Block
10
2.3 Instruction Processing (1)

• Instruction Prefetch and Fetch
• Instruction Prefetch?
• Moving instructions cache lines from higher
  levels of cache or memory into L1i cache.
• Speculative prefetches are based on the branch
  prediction strategy and compiler hints.
• The processor reads 2 instruction bundles from
  L1i cache and places them in the 8-bundle
  instruction buffer (IB).
• The IB holds bundles of instructions until they
  are consumed by the functional units.
• The bundles are then sent to the instruction
  issue and rename logic, according to available
  execution resources.
• The instruction address generator unit selects
  the next IP.

11
2.3 Instruction Processing (2)

• Branch Prediction (BP)
• Itanium 2 employs both static and dynamic methods
  for branch prediction.
• For static BP, hint completers are used.
• Branch hints encode information about branch
  behavior that is used by the processor to improve
  branch prediction.
• Branch hints in Itanium 2 are sptk, spnt, dptk,
  dpnt
• sp for static prediction, dp for dynamic
  prediction, tk for taken, nt for not taken.
• For dynamic prediction, various hardware
  structures are used.
• BP in Itanium 2 is closely tied to the L1i cache,
  which allows for the zero-bubble BP algorithm.

12
2.3 Instruction Processing (3)

• Dispersal Logic (DL)
• The process of mapping instructions within
  bundles to functional units is called dispersal.
• The dispersal logic sends each instruction to one
  functional unit through its issue ports.
• Instructions type and position define its issue
  port.
• Instruction Buffer (IB) can hold up to 8
  instruction bundles, and delivers 2 bundles per
  cycle to the dispersal logic.
• An instruction bundle has a template indicator,
  assigned by the compiler.
• 12 templates for Itanium 2 instructions.
• Template concatenate types of instructions
  within a bundle.
• Instructions issued as a group will proceed as a
  group through the pipeline (if one stalls, whole
  group stalls).

13
2.4 Instruction Execution (1)

• Processor execution logic contains
• 6 multimedia units 6 integer units
• 4 load/store units 3 branch units 2 FP units
• 128 int registers 128 FP registers
• 8 branch registers 64 predicate registers
• Integer loads processed by L1 cache.
• Integer stores processed by L2 cache.
• FP loads and stores processed by L2 cache.
• Multimedia engines treats 64-bit data as
• 2 x 32-bit, 4 x 16-bit, or 8 x 8-bit packed data
  types.
• Ops on packed (SIMD) data by MM engines
• Arithmetic, shift, and data arragement
• Ops non-packed data by Integer engines
• Up to 6 integer arithmetic and logical ops.

14
2.4 Instruction Execution (2)

• Floating-Point Unit (FPU)
• The FPU has 4 pipeline stages.
• Bypassing logic allows data forwarding from
  various FP stages to the FP write back stage.
• FPU includes
• 2 FP Multiply-Accumulate (FMAC) units
• 2 FMISC units
• Support for SIMD formats
• Operands are check for exceptions before
  instruction enters FP pipeline.
• A maximum of 4 FP ops can be executed per cycle.

15
2.4 Instruction Execution (3)

• Predicate Registers
• Set of 64 1-bit predicate registers (PR0 PR63).
• Used to hold results of compare instructions for
  conditional execution of instructions.
• Partition in 2 subsets
• 0-15 static predicate registers
• 16-63 rotating predicate registers
• Branch Registers
• Set of 8 64-bit registers (BR0 BR7).
• Used to hold branching information (branch target
  address) for indirect branches.

16
2.5 Control

• The control block includes the exception handler
  and pipeline control.
• The exception handler implements exception
  prioritizing.
• The pipeline control
• Has a scoreboard that detects dependencies,
  supports data speculation, and tracks multi-cycle
  operations.
• Supports predication via predication registers.
• Contains a Performance Monitoring unit.
• The processor stalls only when source operands
  are not yet available.

17
2.6 Memory Subsystem (1)

• Three-level non-blocking cache structure.
• Split L1 cache for data and instructions.
• Unified L2 cache.
• Unified L3 cache.

18
2.6 Memory Subsystem (2)

• Advanced Load Address Table (ALAT)
• Cache structure that enables data speculation by
  holding the state for advanced load and check
  operations.
• It keeps information of speculative data loads
  issued and stores that are aliased with these
  loads.
• 32 entries, fully associative array
• It can handle 2 stores and 2 loads per cycle.
• Translation Lookaside Buffers (TLBs)
• 2 Types Data TLB (DTLB) and Instruction TLB
  (ITLB).
• DTLB and ITLB each has 2 levels (L1 and L2)
• TLB-L1 32 entries, fully associative, supports
  4KB pages.
• TLB-L2 128 entries, fully associative, pages 4KB
  to 4GB.

19
3. Conclusions

• Last Released Itanium 2 Performance
• Provides performance increases of up to 30 to 50
  percent over the original Itanium 2 processor.
• Itanium 2 processors are ideal for...
• Enterprise requirements, including database
  consolidation, enterprise resource planning,
  business intelligence, and high performance
  computing.
• Pricing
• The Itanium 2 with 6 MB of L3 cache at 1.50 GHz
  costs 4,226
• Itanium Family Roadmap
• Mid 2003 Itanium 2 processor with on-chip 6MB L3
  cache and 1.5 GHz speed (formerly Madison)
• End 2003 a low-voltage Intel Itanium 2 processor
  will be released.
• Mid 2004 Madison 9M processor with an on-chip
  9MB L3 cache and a further clock increase.
• 2005 Montecito will add a new feature called
  dual-core which means two separate logical
  processors on one physical chip.

20
Sources

• Intel Itanium 2 Processor Reference Manual for
  Software Development and Optimization, April 2003
  ftp//download.intel.com/design/Itanium2/manuals/2
  5111002.pdf
• Intel Itanium 2 Processor Hardware Developer's
  Manual, July 2002 ftp//download.intel.com/design/
  Itanium2/manuals/25110901.pdf
• Intel Itanium 2 Processor http//www.intel.com/ebu
  siness/products/itanium/index.htm
• Intel Itanium 2 Processor Product Overview
  http//developer.intel.com/design/itanium2/prodbre
  f/index.htm
• Intel Itanium 2 Processor Product Features
  http//www.intel.com/design/itanium2/index.htm?iid
  ipp_srvr_proc_itanium2prod_procspecfeatures
• EPIC Technology Moves Forward http//developer.int
  el.ru/download/eBusiness/pdf/wp022404.pdf
• Intel Press Release New Intel Server Processors
  Strengthen High-End Line-Up http//www.intel.com/p
  ressroom/archive/releases/20030630comp.htm
• Intel E8870 Chipset http//www.intel.com/design/ch
  ipsets/e8870/index.htm
• The Intel Itanium Architecture Comes of Age
  http//www.intel.com/ebusiness/pdf/prod/itanium/ec
  osystem.pdf
• Roadmap Report How Industry Leading Software
  Maps to Intel's Hardware Plans
  http//cedar.intel.com/cgi-bin/ids.dll/content/con
  tent.jsp?cntKeyGenericEditorial3a3axeon_develo
  percntTypeIDS_EDITORIALcatCodeDASpath3
