Order processing and order picking

1
Order processing and order picking

• Chen Zhou
• April 24, 2004

2
Objective

• To understand the challenges in order picking
• To understand the strategies in order picking
• To link the strategies with our key measures
  pick density and sku density

3
Order processing
4
Another form of pick list sequenced labels

• Sequenced sticky labels

5
Other form or pick list

• Data table for PLC for pick to light
• Sequenced voice instructions to pick to voice
  (later)
• Instructions to automated systems

6
Issues in order processing

• Objectives
• Minimize travel (or other handling)
• Subject to
• Time window, batch to waves
• Day in a week
• Departing time
• Items to pass to other DCs
• WMS normally support this function.
• It requires customization and adaptation

7
Order picking
8
Order picking

• Most demanding operation 55 of operation cost
• Amazon.com
• Office depot
• Big-box retailer DCs
• Spare parts DC
• Grocery DC
• Why does picking cost more than put away?

9
How does storage affect picking

• Type of equipment affect sku density
• Sku density affect pick density
• Slotting affect travel

10
Simple strategy one-order-one-picker

• Pick one-line at a time
• Pick-pack-ship one customer order at a time
• Straightforward
• Small orders low pick density (Amazon)
• Large orders Wal-Mart store order

11
Order picking strategy fast pick area

• Fast pick or forward area low volume reserve
  restocking
• Higher pick density in forward
• Infrequent replenishment from reserve with large
  volume
• Double handling
• Models in the book which one should go to fast
  pick and how much to put there for a fixed fast
  pick area

Reserve
Forward/ Fast pick
Restock
12
Batch picking multiple-orderone-picker

• Batch picking
• Combine small orders into the same trip
• Higher pick density
• Orders of small items (relative to the equipment)
• If orders are mixed during picking, sorting is
  needed later

13
Batch picking of large orders with truck
14
Batching picking with push carts
Pick to order specific containers, no sorting is
required afterwards
15
Time based batching wave picking

• Many DCs organize batches based on time window
• Truck/ship/train departure times
• Shifts
• Cycle times
• Delivery requirements
• Designations
• Beijing wave
• 10 AM wave
• Yellow wave

16
Zone picking one-order-multiple-picker

• Zone can be for multiple order also (batching
  zoning)
• Can achieve extremely high pick density
• Sorting is needed if not into order specific
  containers

17
Schematic of a picking zone
Pick module
Forward
Reserve
Sort to shipping docks
Receiving docks
18
A graphical view of a pick module

• A case picking zone

19
Zone picking

• No Sorting is required

• Sorting is required

20
More zone picking, station lighting

• Increase accuracy
• Reduce search time

21
Put-to-light

• Open a case, put items into light indicated boxes
• Similar to zone picking with changing skus in a
  zone

Put as indicated
22
Automated picking with A - Frame

• A frame
• Automated dispensing

23
Sorting

• Manual
• Barcode directed
• Vision directed
• High speed sorters

24
Sorting High Rate Tilt Tray

• 12,000 items/hr.
• Unit sorter
• Can sort to two sides

25
High speed conveyor sorters
Roller sorter
26
Checking, packing and packaging
27
Shipping
28
How would you characterize this?
29
Automated order fulfillment initiation

• Container types
• Labels and tracking

30
Automated picking with A - Frame

• A frame
• Automated dispensing

31
Packing
32
Shipping
33
Other returns
34
Pareto chart (, cases, picks, )
35
Conveyors in DCs

• Conveyors become more and more popular
• In the states, a DC can have miles of conveyors

36
What does conveyor do?
Pick module
Sort to shipping docks
Receiving docks
37
Cont.

• Conveyors
• Transport
• Buffer
• Extends the good locations throughout the
  facility
• Can yield very high throughput
• Important for high throughput systems
• Design issues

38
Order picking summary

• Pick list generation
• Order picking strategies
• Batching
• Zoning
• Forward/reserve
• Common pick area
• Order picking technologies
• Pick to light/put to light
• Pick to voice
• Automated order assembly systems
• Pick modules

39
Warehousing Summary

• Warehousing and DC
• Operations inventory, flow line dynamics,
  scheduling, planning
• Time Spatial problem
• Distances,
• Contours,
• COI based assignments
• Storage methods
• Order picking strategies

40
Order picking

• Forward/reserve
• Which sku?
• Space sharing for given sku and V
• General problem
• Common pick area
• Batch picking
• Batch size, lot sizing, worker and route
  schedule,
• Zone picking
• (Dynamic) line balancing problem
• Readings and home works
