Multimedia Project

1
Fun with Geometry and Measurement
Tiffany Padgett Saunders Middle School
Multimedia Project
2
Virginia Standards of Learning

• 8.8 The student will investigate and solve
  problems involving volume and surface area of
  cones and pyramids, using concrete materials and
  practical situations.
• 8.10 The student will describe, classify, and
  construct plane figures and solid figures,
  including prisms, pyramids, cylinders, and cones.
• 7.9 The student will investigate and solve
  problems involving the volume and surface area of
  a rectangular prisms and cylinders, using
  concrete materials and practical situations to
  develop formulas.

3
Purpose
The purpose of the presentation is to provide
middle school students with an interactive way to
learn how to solve problems involving area,
surface area, and volume.
4
SQUARE
A parallelogram with all sides congruent and all
angles congruent.
Area length width
WIDTH
LENGTH
5
Rectangle
A parallelogram with all angles congruent.
Area length width
WIDTH
LENGTH
6
Parallelogram
A quadrilateral with two pairs of parallel sides.
Area Base Height
HEIGHT
BASE
7
Triangle
A polygon having three sides.
Area 1/2 base height
HEIGHT
BASE
Polygon a simple closed figure in a plane
formed by three or more line segments.
8
Trapezoid
A quadrilateral with exactly one pair of parallel
lines.
Area 1/2 height (a b)
B
HEIGHT
A
9
Circle
The set of all points in a plane that are the
same distance from a given point called the
center.
Area pr2
RADIUS
10
Rectangular Prism
A prism with rectangles as bases.
Surface Area 2lw 2wh 2lh
Volume length width height
height
width
length
11
Triangular Prism
A prism with triangle bases.
Surface Area 2(1/2 base height)
(bottom)side (front)side (back)side
Volume 1/2 base height length
Multiply by two because you have two triangles
12
Cylinder
A shape in space that has two parallel and
congruent circular bases.
Surface Area pr2 2prh
Volume pr2h
Radius
height
13
Cones
A shape in space that has a circular base and one
vertex
Surface Area pr2 prs
Volume 1/3 pr2h
Side
radius
14
Pyramid
A figure in space with three or more triangular
faces and a base in the shape of a polygon.
Surface Area Length Width 4(1/2 bh)
Volume1/3 L W H
multiply by 4 because you have 4 triangular
faces.
height
Width
Base/Length
15
Now Let's Try
Some Practice Problems !!!
16
Directions
To hear the directions, click the sound button.

• On a separate piece of paper, work out problems
  1-5.
• If you forget the formulas, click on the button
  with an I in the middle and it will give you
  the list of formulas.
• Once finished, click on the button with the A
  in the center for the correct answer.
• Click on any part of the screen to go to the next
  problem.

17
Push to return to practice problems
1.
2.
3.
4.
5.
18
Find the Area...
Push for the formulas
1.
8 cm
Push here for the answer
A
12 cm
19
Find the Area...
Push for the formulas
Answer Alw 128 96 cm
1.
8 cm
12 cm
20
Find the Area...
Push for the formulas
15 cm
2.
Push here for answer
A
HEIGHT
8 cm
12 cm
10 cm
21
Find the Area...
Push for the formulas
15 cm
2.
Answer a1/2(ab)h 1/2(1215)10 1/2(27)
10 1/2(270) 135 cm2
HEIGHT
8 cm
12 cm
10 cm
22
Find the Surface Area...
Push for the formulas
A
Click here for the answer
3.
5 ft
14ft
10 ft
6 ft
23
Find the Surface Area...
Push for the formulas
3.
5 ft
Answer SA2(1/2 bh)sidesideside 2(1/26
14)106105105 2( 42)605050
84605050 244 ft2
14ft
10 ft
6 ft
24
Find the Volume...
Push for formulas
4.
A
Push for Answers
4 in
3.5 in
5in
25
Find the Volume...
4.
Answer Vlwh 53.54 70 in3
4 in
3.5 in
5in
26
Find the Volume...
Push for formulas
Push here for the answer
A
5.
3 yds
5 yds
27
Find the Volume...
5.
3 yds
Answer Vpr2h 3.14325 3.1495
141.3
5 yds
28
Ready for some more practice????
29
Check out this website for interactive
fun!! Courtesy of George Mason University
MetaMedia Mathematics Program
PUSH ME!!
Introduction
PUSH ME!!
Beginners

Advanced
PUSH ME!!
30
Still Want More???
Check out these sites!!
Click Here
Geometry Jokes
Fun Site
Click Here
31
Additional Activities

• Merrills Pre-Algebra Book Chapter 13 Measuring
  Area and Volume
• Practice Problems in the Book
• Practice Worksheets
• Other Activities
• Students can draw and color pictures using 15
  different geometric shapes.
• Students can create paper nets of different
  figures for a more concrete representation of
  shapes.
• Students can make a slit book of all formulas and
  pictures of the geometric shapes.
