ESE250Digital Audio Basics

• Week 10 November 17, 2009
• File System

2
Review

• Everything reduces to bits
• Songs ? digitized and encoded
• Machine code ? bit encoding for machine
  instructions
• Ebook text, Homework PDF, movies,
• Memories store bits
• Non-volatile memories store them persistently
  (when the power goes off)

3
Persistent Storage Questions

• How do we save data across boots
• When the computer is off
• How do we save data to move between machines?
• How do we organize our data so we can find it
  again?
• Tell others to find it?

4
Strawman 1

• Guess a random address and write data there
• Write down addresses on paper
• To playback song
• Run program located at address 42000
• On data located at address 81736
• How do I know if I can use the block at address
  90,000?
• Why might this be problematic?

5
Course Map
Numbers correspond to course weeks
6
Outline

• What does technology give us?
• Requirements?
• Interlude
• File System Sketch

7
Technology
8
Hard Disk

• Disc with magnetic material on its surface

9
Hard Disk

• Disc with magnetic material on its surface
• Divided into tracks (circles)
• Modern disks
• 300,000 TPI
• TPI Tracks Per Inch

10
Hard Disk

• Disc with magnetic material on its surface
• Divided into bit regions
• Modern disks
• 1.5M BPI
• BPI bits per inch

11
Hard Disk

• Each bit located at a position (R,?)
• R select track
• ? select bit from track
• Disc spins
• Traces through Q

12
Hard Disk

• Each bit located at a position (R,?)
• Add arm to move head

13
Hard Disk

• Each bit located at a position (R,?)
• Head arm moves
• Varies R

14
Disk Bandwidth

• Typical Disk speed?
• 15,000 RPM
• One rotation every
• 60s/15,0004ms
• At R1 inch and 1.5M BPI, How many bits/second?
• 2 p ? 1 in ? 1.5M/in / 4ms
• 9Mbits/4ms 2.25Gb/s
• 280 MB/s

15
Disk Speed

• Move head in R?
• Also a few milliseconds
• Typical Data access 10ms
• E.g. 4ms rotate 6ms seek

16
Throughput and Implications

• Disk throughput faster than access time
• 10ms latency
• 280MB/s throughput (1B/4ns)
• What does this drive us to?
• 10ms seek ? Random byte access 100B/s
• Sequential access 280MB/s
• Want to exploit sequential access!
• Read blocks of data

17
Read Data Blocks

• How many sequential bytes can read in 1ms?
• 280MB/s ? 0.001 s
• 280KB
• Can read 280KB in the same time as 1Byte
• 6ms seek, 4ms rotation, 1ms data read

18
Seagate 2.5 Disk Drive
5400 RPM
http//www.seagate.com/docs/pdf/datasheet/disc/ds_
momentus_5400_psd.pdf
19
FLASH Memory
Week 8

• Exploit tunneling
• Use high-voltage to reduce barrier
• Tunnel charge onto floating node
• Charge trapped on node
• Use field from floating node to modulate
  conduction

http//commons.wikimedia.org/wiki/FileFlash-Progr
20
Flash

• NOR -- Read like other memories
• NAND Sequential read within page
• Denser than NOR
• Can only erase in blocks
• 4KB, 64KB?256KB
• Once erased can write byte (page) at a time
• Write time variable
• Typically need feedback to sense when written

21
Samsung 256Mx8 NAND Flash
http//www.datasheetcatalog.com/datasheets_pdf/K/9
/E/2/K9E2G08U0M.shtml
22
Intel Solid-State Drive (SSD)
35,000/s x 4KB 140MB/s
SSDhttp//download.intel.com/design/flash/nand/ext
reme/extreme-sata-ssd-datasheet.pdf
23
Requirements
24
File

• File sequence of bits that go together
• MP3 encoding
• Executable for mp3player
• Picture in JPEG
• PDF for your lab writeup
• How big is a file?

25
File

• File sequence of bits that go together
• Like an object
• A base address
• Length or extent
• Generally has a typebut only used weakly
• Mp3, WAV, x86 executable,
• On unix/linux
• an array of unsigned char
• with a length
• Magic number ? tries to convey type
• Inband, in the file (first word?)

26
Create a File?

• What do I need to do to create/store a new file?
• Allocate/reserve space for it
• Give it a name?
• Make a record somewhere of mapping between name
  and location

27
Strawman 2
free_address

• Keep track of next free address
• free_address initialized to 0

28
Strawman 2
free_address

• Keep track of next free address
• free_address initialized to 0
• When create file, give it space at free_address
• Increment free_address by length

29
Strawman 2
free_address

• Keep track of next free address
• free_address initialized to 0
• When create file, give it space at free_address
• Increment free_address by length
• Store name address in table
• Maybe put table at high addresses

File1 0
30
Strawman 2

• Keep track of next free address
• free_address initialized to 0
• When create file, give it space at free_address
• Increment free_address by length
• Store name address in table
• Maybe put table at high addresses

free_address
File1 0
File2 250
31
Strawman 2

• Keep track of next free address
• free_address initialized to 0
• When create file, give it space at free_address
• Increment free_address by length
• Store name address in table
• Maybe put table at high addresses
• When free_addresslengttable_base
• Device is full

free_address
File1 0
File2 250
32
Strawman 2

• Keep track of next free address
• free_address initialized to 0
• When create file, give it space at free_address
• Increment free_address by length
• Store name address in table
• Maybe put table at high addresses
• When free_addresslengttable_base
• Device is full

free_address
33
Evaluating Strawman 2

• Bad
• What happens when delete a file?
• How reuse space?
• Add data to files?
• Table gets big
• All filenames have to be unique?
• Demands coordination between
• users?
• Programs?
• Programs from different vendors?

• Good
• Accommodates variable length files
• Allows contiguous access

34
Files Grow and Shrink

• Essay/homework gets longer as write it
• Dont know how long it will be when start
• Database of checks written grows
• TODO before end-of-term list shrinks?
• Where put additional space?
• Allocate new space at end of disk?

35
Delete Files

• Dont need lame .o files once build executable
• Replace false start
• That was a bad picture of me
• Now have better
• Dont want anyone to see my secret plans to take
  over the world
• want the space back because drive filling up

36
Repurposing Space

• How reclaim space?
• With single free_address pointer
• cant keep track of all the places where there is
  space
• What can do?
• Keep a list of free regions
• Try to find a region where will fit

37
Finding Contiguous Space

• What if our disk looks like this
• and we want to allocate a large file?
• Disk has capacity
• But cannot allocate because not contiguous

38
Bad Sectors

• Portions of a disk head may be bad
• At manufacture time
• Go bad during use
• Portions of Flash RAM may be bad
• Manufacturing defects
• Limited number of write cycles
• Also inhibits contiguous allocation

39
Naming Conflicts

• How solve naming conflicts?
• Provide separate contexts
• E.g. separate space of names
• for each user
• for each program
• Typically with a directory structure

40
Directory

• Special file that contains name to location
  mappings
• Once a file, we can easily allow hierarchy
• Directories can contain directories

41
Requirement Roundup

• Find things easily and quickly
• Minimize what we need to look at to find data
• Portable (is the sole state holder)
• Self describing
• Fast read
• Attempt to layout contiguous files
• Fast write
• Not take too long to find space for file
• Support deletion (repurpose capacity)
• Use (most) of capacity
• Allow files to be non-contiguous
• Tolerate errors in media
• Dont depend on contiguous blocks to be good
• Isolate/differentiate who can access what

Challenge both asymptotics and constants
(e.g. 280MB/s vs. 10ms
random access) matter.
42
Interlude
43
Disk Data Security

• How is security enforced?
• OS demands credentials for login
• User doesnt get direct access to hardware
• OS intermediates

44
Physical Disk Access

• What happens if the disk is removed from the
  physical machine?
• Plugged into another machine that
• Someone else has administrator access on?
• Doesnt respect the users/isolation?

45
Common News Item

• Computer hard drive sold on eBay 'had details of
  top secret U.S. missile defence system'
• By Daily Mail ReporterLast updated at 1108 AM
  on 07th May 2009
• Highly sensitive details of a US military
  missile air defence system were found on a
  second-hand hard drive bought on eBay.
• The test launch procedures were found on a hard
  disk for the THAAD (Terminal High Altitude Area
  Defence) ground to air missile defence system,
  used to shoot down Scud missiles in Iraq.
• The disk also contained security policies,
  blueprints of facilities and personal information
  on employees including social security numbers,
  belonging to technology company Lockheed Martin -
  who designed and built the system.
• Read more http//www.dailymail.co.uk/news/articl
  e-1178239/Computer-hard-drive-sold-eBay-details-se
  cret-U-S-missile-defence-system.htmlixzz0Wxa60PT9


46
all too common

• VA Update on Missing Hard Drive in Birmingham,
  Ala.
• February 10, 2007 Printable Version
• Investigation Yielding Additional Information
• WASHINGTON -- The Department of Veterans Affairs
  (VA) today issued an update on the information
  potentially contained on a missing
  government-owned, portable hard drive used by a
  VA employee at a Department facility in
  Birmingham, Ala.
• Our investigation into this incident continues,
  but I believe it is important to provide the
  public additional details as quickly as we can,
  said Jim Nicholson, Secretary of Veterans
  Affairs.  I am concerned and will remain so
  until we have notified those potentially affected
  and get to the bottom of what happened.
• VA will continue working around the clock to
  determine every possible detail we can,
  Nicholson said.
• VA and VAs Office of Inspector General have
  learned that data files the employee was working
  with may have included sensitive VA-related
  information on approximately 535,000
  individuals.  The investigation has also
  determined that information on approximately 1.3
  million non-VA physicians both living and
  deceased could have been stored on the missing
  hard drive.  It is believed though, that most of
  the physician information is readily available to
  the public.  Some of the files, however, may
  contain sensitive information.

47
Still Happening

• Probe Targets Archives Handling of Data on 70
  Million Vets
• By Ryan Singel October 1, 2009
• The inspector general of the National Archives
  and Records Administration is investigating a
  potential data breach affecting tens of millions
  of records about U.S. military veterans,
  Wired.com has learned. The issue involves a
  defective hard drive the agency sent back to its
  vendor for repair and recycling without first
  destroying the data. ....
• The incident was reported to NARAs inspector
  general by Hank Bellomy, a NARA IT manager, who
  charges that the move put 70 million veterans at
  risk of identity theft, and that NARAs practice
  of returning hard drives unsanitized was
  symptomatic of an irresponsible security mindset
  unbecoming to Americas record-keeping agency.
• This is the single largest release of personally
  identifiable information by the government ever,
  Bellomy told Wired.com. When the USDA did the
  same thing, they provided credit monitoring for
  all their employees. We leaked 70 million
  records, and no one has heard a word of it.

http//www.wired.com/threatlevel/2009/10/probe-tar
gets-archives-handling-of-data-on-70-million-vets/
48
Caveats

• On standard unix/windows setups
• Without the OS to providing protection,
  all the data is accessible
• Sometimes good for recovery
• On standard unix/windows setups
• Rm/del doesnt make the data go away
• Also sometimes useful for recovery
• Even format not guarantee data overwritten
• See Remembrance of Data Passed A Study of Disk
  Sanitization Practices
• IEEE Security and Privacy, v1n1p1727 (linked
  from todays reading)

49
File System Sketch
50
Sketch

• Manage the disk at the level of blocks of fixed
  size (bnodes)
• Format disk for bnodes
• File is a collection of bnodes
• Directory is a kind of file
• Root of system bnode in known location

51
bnode

• Fixed-size block of data
• Minimum unit of storage allocation
• bnodes map to physical addresses
• E.g. bnode 76 ? address 76?4096 311296
• Or bnode 76 ? R1.012in, theta32.07 degrees
• Address physical resources through bnodes

52
bnode Size

• How big should a bnode be?
• Needs to be bigger than the block address
• Problems with small blocks?
• Longer addresses
• Can address smaller FS w/ fixed address bits
• Problems with large blocks?
• Minimum allocation increment
• ?Internal fragmentation
• Typical values 4KB, 1KB, 256B
• Trending toward larger these days
• Intel 4KB SSD, 64KB for some flash

53
Files from bnodes

• Use bnodes as file handle
• How we address the file
• bnode contains metadata
• Block type, File type, length
• Small file all data in single bnode

76
obj, 3172
54
Files from bnodes
76
obj, 15,791

• Large file tree of bnodes

55
Files from bnodes
76
obj, 15,791

• Large file tree of bnodes
• Multi-level if necessary

37253
56
Files from bnodes

• Large file tree of bnodes
• Multi-level if necessary
• Overhead for tree structure?
• 4KB pages
• About 1000-way tree
• 1000KB tree needs 1001 pages
• 8KB tree needs 3 pages (50 overhead)
• In practice inodes avoid this worst-case

57
EXT2 inode
indirect blocks
(12 of these)
Source http//www.tldp.org/LDP/tlk/fs/filesystem
.html
58
File Expansion with bnodes

• Expand file
• Add bnodes to file

76
76
obj, 15,791
59
Directory

• File
• With type directory
• contains name/bnode pairs
• Small
• Fits in one bnode
• Large
• Tree of bnodes
• Just like file

Directory, 234
Lab1, 76 Lab2, 98 Lab3, 1034 Lab4, 267 Lab5,
2053 .
60
Free bnodes
0
1
2
3
4
5

• Keep track of free and usable bnodes
• Grouped by contiguous set of free blocks
• Allocation try to find contiguous set of bnodes
  to satisfy file need
• and try not to breakup large contiguous block
  unnecessarily
• Deletion try to reassemble free blocks
• E.g. delete 13 ? make 1014 length 5 block

6
7
8
9
Length 1 1, 14 Length 2 3-4, 7-8, Length 3
10-12, 16-18 Length 4 20--23
10
11
12
13
14
15
16
17
18
19
20
21
22
23
61
Superblock

• For bootstrapping and file system management
• Each file system has a master block in a
  canonical location (first block on device)
• Describes file-system type
• Root bnode
• Keeps track of free lists at least the head
  pointers to (bnodes, blocks)
• Corruption on superblock makes file system
  unreadable
• ?Store backup copies on disk

62
Format disk

• Identify all non-defective bnodes
• Defective blocks skipped
• ? those addresses not assigned to bnodes
• Create free bnode data structure
• Create superblock

63
Review Sketch

• Manage the disk at the level of bnodes
• Format disk for bnodes
• File is a collection of bnodes
• Directory is a kind of file
• Root of system bnode in known location

64
Requirement Review

• Find things easily and quickly
• Minimize what we need to look at to find data
• Directory structure
• Portable (is the sole state holder)
• Self describing ? superblock, metadata
• Fast read
• Attempt to layout contiguous files
• Fast write
• Not take too long to find space for file ?
  efficient free structure
• Support deletion (repurpose capacity)
• Return bnodes to free list
• Use (most) of capacity
• Allow files to be non-contiguous ? bnodes
• Tolerate errors in media
• Dont depend on contiguous blocks to be good ?
  bnodes
• Isolate/differentiate who can access what

65
Learn More

• Online reading/pointers
• Unix File System Tutorial
• Flash, SSD, Hard drive data sheets
• Data found on hard drive articles
• Courses
• CIS121 efficient data structures
• CIS380 operating systems

66
Big Ideas

• Persistence/Volatility
• Self-describing
• Every disk different (at least due to media
  defects)
• Only place to save data across boots
• Naming
• Must have canonical way of referencing data
• Indirection
• Build logically contiguous region from
  non-contiguous physical regions
• Deal with growing, variable size files and errors
  in media
