Title: OSGi Enablement for Tuscany


1
OSGi Enablement for Tuscany
  • Raymond Feng

2
Overview
3
Motivations
  • Provide modularity for Tuscany to
    formalize/enforce the SPI contracts and minimize
    the package dependencies across modules
  • Enable Tuscany to work with OSGi environment such
    as JEE application servers, Eclipse RCP or Spring
    DM
  • Provide versioning and isolation so that Tuscany
    extensions can depend on different versions of
    the same library
  • Provide lifecycle management for extensions
    install/uninstall/start/stop a module

4
Objectives
  • Tuscany runtime will be able to run in both
    non-OSGi and OSGi environment
  • No OSGi APIs should be used for non-OSGi specific
    modules
  • Build a consistent OSGi story to facilitate
    developing, building, launching, running and
    testing Tuscany
  • Makes developers life a bit easier to work with
    OSGi

5
What problems do we try to solve?
  • Turning Tuscany modules into OSGi bundles
  • Turning 3rd party dependencies into OSGi bundles
  • Developing, building, launching, running and
    testing with OSGi
  • Producing distributions that are compatible with
    the OSGi bundle structure in an efficient way (in
    one-two minutes)

6
Turning Tuscany modules into OSGi bundles
7
Creating bundles for Tuscany modules
  • Modularize Tuscany after the maven modules
  • One OSGi bundle per maven module
  • Be consistent for build, packaging and runtime
  • Much easier to aggregating than decomposing
  • Developers are responsible for authoring and
    maintaining MANIFEST.MF (instead of MF generation
    tools)
  • Tooling friendly
  • Developers pay more attentions to the dependencies

8
Things to consider to create an OSGi bundle for a
module
  • Add META-INF/MANIFEST.MF (dont stop here )
  • Clean up module dependencies and package
    visibilities
  • Prepare for code changes
  • Service Discovery
  • ClassLoading

9
Rules of thumb
  • Identify the absolutely necessary SPI packages
    that need to be exported
  • Don't try to export everything
  • For model modules, try to only export the package
    that contains the interfaces
  • Try not to export any package from the
    xxx-runtime moudles
  • Any classes that can be accessed via the
    ExtensionPointRegistry using interfaces should
    not be exported
  • Only import other packages when it's needed
  • For example, we used to have a lot of modules
    pull in assembly for just a constant for the SCA
    namespace
  • Avoid DynamicImport-Package
  • Avoid Require-Bundle
  • Do not export "private" packages as a workaround
    or hack which can fail the "clean SPI". Refactor
    things into SPIs if necessary

10
Granularity Discussion
  • 180 bundles cumbersome
  • Multiple bundles required to enable one
    capability
  • Much debate about right level of granularity
    (flexibility vs. usability)
  • Some opinions
  • Fine-grained bundles suitable for developer view
  • Features/Profiles used to group bundles to
    provide a user view
  • Inspired by Eclipse Features

11
Dealing with 3rd party jars
12
Handling 3rd party jars
  • We have to live with the reality
  • Many 3rd party jars are not OSGi bundles. No repo
    is available to get all converted bundles
  • We need to convert them (build time, run time)
  • Some of the 3rd party bundles are broken (w/
    bogus MF)
  • We need to fix them (replacing the MF)
  • More and more 3rd party jars are upgraded to be
    OSGi bundles
  • We should be able to incrementally consume 3rd
    party jars as OSGi bundles

13
Converting 3rd party jars to OSGi bundles
  • A folder bundle is created to represent a 3rd
    party jar
  • The folder structure looks like
  • jaxb-impl-2.1.12
  • META-INF
  • MANIFEST.MF
  • jaxb-impl-2.1.12.jar
  • It is non-invasive and flexible
  • The original jar is not changed (avoid legal,
    signature issues)
  • Multiple jars can be easily aggregated (control
    the bundle granularity)
  • The MANIFEST.MF can be easily customized

OSGi Framework
MANIFESTBundle-Classpath third-party.jar Dynamic
-Import-Package Export-Package ... ...
third-party-osgi.jar
MANIFESTBundle-Classpath third-party.jar Import-
Package ... Export-Package ... ...
Install
third-party.jar
third-party.jar
third-party.jar
14
Sample META-INF/MANIFEST.MF
  • Manifest-Version 1.0
  • Bundle-ManifestVersion 2
  • Bundle-SymbolicName com.sun.xml.bind.jaxb-impl
  • Bundle-Name com.sun.xml.bind.jaxb-impl
  • Bundle-Version 2.1.12
  • DynamicImport-Package javax.transactionversion"
    1.1",javax.transacti
  • on.xaversion"1.1",
  • Bundle-ClassPath jaxb-impl-2.1.12.jar
  • Export-Package com.sun.xml.bind.v2.schemagenvers
    ion2.1.12,com.sun.x
  • ml.bind.v2.utilversion2.1.12,com.sun.xml.txw2.a
    nnotationversion2.
  • 1.12,com.sun.xml.bind.v2.model.runtimeversion2.
    1.12,com.sun.xml.bin
  • d.v2.runtimeversion2.1.12,com.sun.xml.txw2.outp
    utversion2.1.12,co
  • m.sun.xml.bind.v2version2.1.12,com.sun.istackv
    ersion2.1.12,com.su
  • n.xml.bind.v2.runtime.propertyversion2.1.12,com
    .sun.xml.bind.v2.run
  • time.unmarshallerversion2.1.12,com.sun.xml.bind
    .v2.model.navversio
  • n2.1.12,com.sun.xml.bind.marshallerversion2.1.
    12,com.sun.xml.bind.
  • v2.runtime.reflect.optversion2.1.12,com.sun.xml
    .bind.v2.runtime.out
  • putversion2.1.12,com.sun.xml.txw2version2.1.1
    2,com.sun.xml.bind.v
  • 2.schemagen.xmlschemaversion2.1.12,com.sun.xml.
    bind.v2.runtime.refl

15
Developing Tuscany with OSGi
16
Checking out source code and building with maven
  • Check out the Tuscany source code from SVN
  • svn co https//svn.apache.org/repos/asf/tuscany/ja
    va/sca/
  • Run maven build
  • mvn clean install -fn
  • Generate Eclipse projects
  • mvn -Peclipse

17
Setting up Eclipse PDE
  • Download Eclipse (w/ plugin development)
  • http//www.eclipse.org/downloads/download.php?file
    /technology/epp/downloads/release/galileo/SR1/ecl
    ipse-jee-galileo-SR1-win32.zip
  • Configure PDE target platform
  • File ? Open File
  • lttuscanygt\sca\distribution\all\target\features\tus
    cany-pde35.target
  • Click on Set as target platform
  • Load Tuscany modules into Eclipse
  • File ? Import ? General ? Import Existing
    Projects

18
Whats happening during the Tuscany build?
  • Validating OSGi constraints to report bundle
    resolution issues during compilation
  • Generating PDE project so that Tuscany modules
    can be loaded in Eclipse to leverage the nice
    OSGi tooling
  • Generating OSGi bundles for 3rd party jars
  • Generating PDE target platform definitions so
    that 3rd party bundles can be used in Eclipse as
    plugin dependencies
  • Generating Equinox configuration so that Tuscany
    distribution can be directly loaded as an OSGi
    framework

19
Maven/OSGi Tools provided by Tuscany
  • Maven-bundle-plugin
  • Generates bundles for 3rd party jars
  • Generates OSGi enabled PDE projects
  • Version 1.0.4 released at 10/09/2009
  • Maven-eclipse-compiler
  • Expose OSGi aware Eclipse JDT compiler
  • Expose Eclipse OSGi bundle validation
  • Version 1.0.1 released on 04/07/2009
  • Maven-osgi-junit-plugin
  • JUnit tests in a OSGi enabled environment
  • Version 1.0 released on 10/28/2009
  • https//svn.apache.org/repos/asf/tuscany/maven-plu
    gins/trunk/

20
Development Time
  • Eclipse PDE provides nice OSGi tooling
  • Graphical editor for MANIFEST.MF (w/ additional
    tools to analyze/calculate dependencies)
  • Plugin Dependencies Classpath Container
  • Compilation errors/warning for OSGi constraint
    violations (w/ Quick Fix suggestions)
  • OSGi test environment to validate and launch OSGi
    framework (w/ console)

21
Runtime
  • Provide a SCA node launcher to start an OSGi
    runtime and run SCA application with the
    OSGi-enabled Tuscany runtime
  • We need to use Tuscany's service discovery
    mechanism to discover and instantiate the
    factories
  • Change how JDK factories such as XMLInputFactory,
    XPathFactory, and DocumentBuilderFactory, are
    discovered and instantiated
  • XMLInputFactory.newInstance() used the JSE
    service provider pattern which doesn't work with
    OSGi
  • Adjust the code that assumes there is a flat
    thread context classloader that can access all
    the classes in the Tuscany runtime
  • With OSGi, there is a network of classloaders
    (one classloader per module) and the class
    visibility is constrained by the OSGi headers
    such as Import-Package and Export-Package
  • The classloader for the current class is a good
    starting point for Class.forName() with OSGi

22
Launching OSGi framework within Eclipse PDE
23
Launching OSGi from Tuscany distribution
  • Equinox
  • java -jar osgi-3.5.0-v20090520.jar -clean
    -console -configuration ..\features\configuration
  • http//cwiki.apache.org/confluence/display/TUSCANY
    xDOCx2x/RunningTuscanySCA2.xwithEquinoxandF
    elix

24
Testing Tuscany with OSGi
25
A few options
  • Tuscany maven-osgi-junit plugin
  • Generate two bundles for the main and test
    classes respectively. The test bundle is a
    fragment of the main bundle.
  • For example, the plugin generates the following
    bundles for sample-calculator-osgi.jar
    sample-calculator-osgi-osgi.jar
    sample-calculator-osgi-osgi-tests.jar
  • Find the EquinoxHost class from
    tuscany-node-launcher-equinox and create an
    instance
  • Start the equinox runtime
  • Set up the classloader for surefire so that it
    uses OSGi classloading for the test cases with
    the test bundle.
  • Delegate to surefire to run the unit tests
  • Apache Felix junit4osgi
  • http//felix.apache.org/site/apache-felix-ipojo-ju
    nit4osgi.html

26
Trouble-shooting OSGi related issues
27
Common traps
  • System packages need to be explicitly imported,
    such as javax.xml.namespace
  • Be careful of TCCL (ThreadContext Classloader)
  • No well-defined TCCL in OSGi
  • Equinox uses ContextFinder to find the closest
    class on the calling stack that is loaded by an
    OSGi bundle
  • JDK and some 3rd party libraries uses service
    discover pattern relying on TCCL being able to
    load/see everything

28
Some tips
  • Most common exceptions
  • ClassNotFoundException
  • NoClassDefFoundError
  • Bundle is not resolved
  • Missing Import-Package (including system packages
    from the JDK)
  • Split package from Export-Package
  • Different versions of the same package are
    exported
  • Chain of bundle resolution (Exported packages
    from unresolved bundle cannot be seen.)

29
Useful Links
  • http//cwiki.apache.org/autoexport-2.2.9/TUSCANYxD
    OCx2x/osgi-enablement-for-tuscany-runtime.html
  • Infoq.com articles
  • http//www.infoq.com/articles/modular-java-what-is
    -it
  • http//www.infoq.com/articles/modular-java-static-
    modularity
  • http//www.infoq.com/articles/modular-java-dynamic
    -modularity
  • http//www.dynamicjava.org/
