Lecture 6 Chap 8: Sequential VHDL

1
Lecture 6Chap 8 Sequential VHDL
Instructors Fu-Chiung Cheng (???) Associate
Professor Computer Science Engineering Tatung
University
2
VHDL domains

• VHDL has two domains
• A. concurrent domain signal assignment (chap
  3,4),
• component instances (chap 11),
• processes.
• B. sequential domain the statements in a
  process.
• Sequential VHDL is difficult to interpretation
• as hardware

3
VHDL processes

• A process is a series of sequential statements
  that
• must be executed in order.
• Basic structure of a process
• process sensitivity-list
• declaration part
• begin
• statement part
• end process

4
librar ieee use ieee.std_logic_1164.all,
ieee.number_std.all entity adder is port(a,
b in unsigned(3 downto 0) sum out unsigned(3
downto 0)) end architecture behavior of adder
is process (a.b) begin sum lt a b
end process end
5
VHDL procsses

• sensitivity list a list of signals to which the
  process
• is sensitive
• Any events on any of the signals in the
  sensitivity list
• causes the process to be executed once.
• A. all the statements in the statement part
  will be
• executed
• B. Then the process will stop and wait for
  further
• activity

6
Wait statement

• The sensitivity list is optional.
• If sensitivity list is absent, then the process
  must
• contain wait statements.
• Sensitivity list and wait are mutual exclusive.
• Basic structure
• process
• declaration part
• begin
• statement part
• wait on sensitivity-list
• end process

7
librar ieee use ieee.std_logic_1164.all,
ieee.number_std.all entity adder is port(a,
b in unsigned(3 downto 0) sum out unsigned(3
downto 0)) end architecture behavior of adder
is process begin sum lt a b wait on
a, b end process end
8
Declaration and Statement parts

• Declaration part of a process allows the
  declaration
• of types, functions, procedures, variables
  which are
• local to the process.
• Statement part of a process contains the
  sequential
• statements to be executed each time the process
  is
• activated.
• Sequential statements
• A. if statement.
• B. case statements,
• C. for loops,
• D. simple signal assignments

9
Combinational Process

• Combinational process must be sensitive to all
  the
• signals that are read in the process.
• If a process is not sensitive to all its inputs
  and is not
• a registered process (chap 9) then it is
  unsynthesisable
• Example adder
• A. inputs of the process signals a and b.
• B. it is a combinational logic.
• C. a sensitivity list wait statement at the
  end.
• VHDL allows any number of wait statements in a
• process with no sensitivity list. However, when
  used
• for synthesis, only one wait statement can be
  present.

10
Wait statement positioning

• why wait at the end sensitivity list
• At the elaboration phase of the simulation, all
  process
• in a model are run once.
• (elaboration VHDL simulator at
  initialization)
• It is not necessary to place the wait statement
  at the
• end of the process.
• The most common place for wait statement is at
  the
• start (any of the statements will not be run at
  the
• elaboration time.)

11
librar ieee use ieee.std_logic_1164.all,
ieee.number_std.all entity adder is port(a,
b in unsigned(3 downto 0) sum out unsigned(3
downto 0)) end architecture behavior of adder
is process begin wait on a, b sum lt a
b end process end
12
Wait statement positioning

• Note that elaboration has no hardware
  equivalent.
• Elaboration makes no difference to synthesized
  circuits.
• Note that the difference between simulation and
• synthesis due to elaboration can be a pitfall.
• Simulation OK but Gate level implementation is
  not
• (initialization problem)

13
Signal Assignment

• Signals are the interface between VHDLs
  concurrent
• domain and the sequential domain within a
  process.
• Signals are a means of communication between
• processes
• VHDL model
• a network of processes intercommunicating via
  signals.
• All the hierarchy is effectively removed to
  leave a
• network of processes and signals.

14
Signal Assignment

• VHDL Simulator
• A. update signal values
• B. run processes activated by the changes on the
  signals
• listed in their sensitivity list.
• While a process is running, all signals in the
  system
• remain unchanged. (constant during process
  execution)
• A signal assignment in a process causes a signal
  change
• (an event) to be queued for that signal.
• The simulator will not process the event until
• process execution stops.
• (signals are updated at the end of the process)

15
Signal Assignment

• Three types of signal assignments
• A. simple assignment (OK in a process)
• B. conditional assignment (not OK)
• C. selected assignment (not OK)
• if and case statements can be used in a process
• to implement B and C

16
Variables

• Variables are used to store intermediate values
  within
• a process
• Variables can only exist within sequential VHDL
• (can not be declared or used directly in an
  architecture.)
• Variable declaration
• variable a, b, c std_logic
• Initial values
• variable a std_logic 1
• If variables do not have explicit initial values
  given in
• the declaration, the left values of the types
  will be
• used as initial values.

17
Variables

• Signals are not updated during process
  execution.
• Thus, signals can not be used to store
  intermediate
• values of calculation during process execution
• Variables are updated immediately by variable
• assignments
• A. accumulate result
• B. store intermediate values in a calculation
  within a
• process.
• C. variable expr
• Example

18
librar ieee use ieee.std_logic_1164.all entity
full_adder is port(a, b in std_logic
cout, sum out std_logic) end architecture
behavior of full_adder is process
(a,b,c) variable sum1, sum2, c1, c2 std_logic
begin sum1 a xor b c1 a and b
-- HA sum2 sum1 xor c c2 sum1 and c --
HA sum lt sum2 cout lt c1 or c2 end
process end
19
If statement

• if statement is the sequential equivalent of the

• conditional signal assignment.
• Syntax
• if boolean then
• true-statements-1
• elsif boolean then
• true-statements-2
• else
• default-statements
• end if

20
process (a,b) begin if a b then result lt
00 -- 0 equal elsif a lt b then result lt
11 -- -1 less than else result lt 01
-- 1 greater than end if end process
21
If statement

• hardware implementation multiplexers

process (a,b) begin if a b then equal lt
1 else equal lt 0 end if end
process
22
If statement
z lt a when sel1 1 else b when sel2
1 else c
process (a,b,c, sel1, sel2) begin if sel1 1
then z lt a elsif sel2 1 z lt b else
z lt c end if end process
23
If statement prioritization
process (a,b,c, sel1, sel2) begin if sel1 1
then z lt a elsif sel1 0 and sel2 1
-- redundant z lt b -- bad else
z lt c end if end process
24
Incomplete If statement

• What happens if there is a missing else part?
• What happens if there is a signal that is not
  assigned
• in some branches of the if statement?
• Ans The signals that do not received values,
• the previous values is preserved.
• Latches are used to keep the previous values
• Such circuits are called sequential circuits.
• (current states depend on previous history)

25
Complete If statement
process (a,b, enable) begin if enable 1
z lt b else z lt a end if end
process
process (a,b, enable) begin z lt a if enable
1 z lt b --- else part is
missing end if end process
26
Incomplete If statement
process (a,b,c) begin if c 1 z lt
a --- z is not assigned --- if c 0
else y lt b --- y is not assigned
--- if c 1 end if end process
process (a,b, enable) begin if enable 1
z lt b // else part is missing end if
end process
27
Incomplete If statement

• Incomplete if statement due to the redundant
  test

process (a,b,c) begin if c 1 z lt
a elsif c /1 then z ltb end if end
process
Why? c 1 gt c and 1 c 0 gt c and 0
28
Case statement

• Case statement is like if statement.
• The case statement does not need to be boolean.
• The condition in case statement can be a signal,
• variable, or expression
• Example

29
Case statement
type light_type is (red, amber, green)
process (light) -- light has type light_type
begin case light is when red
gt next_light lt green when amber
gt next_light lt red when green
gt next_light ltamber end case end
process
30
Case statement

• when part choices and branches
• each branches can contain any number of
  statements
• case statement must cover every possible value
  of the
• type or subtype of the condition.
• Keyword other mopping up choice.
• Example of legal choices
• A. when 0 to integerhigh gt
• B. When redamber gt
• C. When 0 to 1 3 to 4 gt
• hardware implementation multiplexers

31
Latches

• If a signal is assigned only after some
  conditions and
• not others, (incomplete if statement) then the
  previous
• value of the signal is preserved.
• In a registered process, the previous value is
  stored in
• registers (synchronous sequential circuits)
• In a combinational process the previous value is
  stored
• in latches (asynchronous sequential circuits)
• Thus, a process can contain a mixture of
  combinational
• and latched outputs.

32
Latches

• signal input, output std_logic_vector(3
  downto 0)
• signal enable std_logic
• process (enable, input)
• begin
• if enable 1 then
• output lt input
• end if
• end process

33
Latches

• In principle, latch can be applied to a process
  of any
• complexity.
• In practice, analysis becomes extremely
  difficult when
• there are many levels of nesting
• Practical Synthesis tools have built-in limit.
• Safe way use only the outmost level of the
  conditional
• A latched process is a combinational process
  with
• latches on the outputs.
• Example

34
A Latched Process
process (en, sel, a, b) begin if en 1
then if sel 1 then -- error 0 zlt
a else zltb end if end if end
process
35
A Latched Process

• A latched process
• if en 1 then -- latch outputs
• if sel 1 then -- begin combinational
  outputs
• zlt a
• else -- complete if statemenet
• zltb
• end if -- end of combination outputs
• end if

36
A Latched Process

• A single-level, two-branch if statement
• process (en, sel, a, b)
• begin
• if en 1 and sel1 then
• z lta
• elsif en1 and sel 0 then
• zltb
• end if
• end process
• The missing else clause means that the signal Z
  will not
• always get a new value under all conditions.

37
Loops

• A loop is a mechanism for repeating a section of
  VHDL
• code.
• Three types of loops in VHDL
• A. simple loop loop indefinitely
• B. while loop loop until a condition become
  false.
• C. for loop loop a specified number of times.
• Loop gt hardware replication
• Thus, only for loop is possible.
• Example

38
librar ieee -- DA test OK use
ieee.std_logic_1164.all entity match_bits is
port(a, b in std_logic_vector(7 downto 0)
matches out std_logic_vector(7 downto
0)) end architecture behavior of match_bits is
begin process (a,b) begin for I in 7
downto 0 loop matches(i) lt not (a(i) xor
b(i) ) -- bitwise EQ end loop end
process end
39
librar ieee use ieee.std_logic_1164.all entity
match_bits is port(a, b in
std_logic_vector(7 downto 0) match out
std_logic_ vector(7 downto 0)) end architecture
behavior of match_bits is process (a,b)
begin matches(7) lt not (a(7) xor b(7) )
matches(6) lt not (a(6) xor b(6) ) .
matches(0) lt not (a(0) xor b(0) ) end
process end
40
For loop

• Note that the loop range is irrelevant, since
  there is no
• connection between the replicated logic blocks.
• Order is not important in this example.
• Connection of replication blocks gt variable
• A variable is used to store value in one
  iteration of the
• loop and then is read by another iteration.
• Initialization is required.
• Example

41
librar ieee use ieee.std_logic_1164.all,
ieee.numeric_std.all entity count_ones is
port(vec in std_logic_vector(15 downto 0)
count out unsigned(4 downto 0)) end
42
architecture behavior of count_ones is
process (vec) variable result unsigned(4 downto
0) begin result to_unsigned(0,
resultlength)) for i in 15 downto 0
loop if vec(i) 1 then result
result 1 end if end loop -- DA Test
OK count lt result -- but more complicate
end process end
43
process (vec) variable result unsigned(4
downto 0) begin result to_unsigned(0,
resultlength)) if vec(15) 1 then
result result 1 end if if vec(14)
1 then result result 1 end
if . if vec(0) 1 then result
result 1 end if count lt result
end process
44
For loop

• looping the elements of an array from left to
  right
• for i in vecrange loop
• looping the elements of an array from right to
  left
• for i in vecreverse_range loop
• looping the elements of an array from lowest
  index to
• highest index
• for i in veclow to vechigh loop
• looping the elements of an array from highest
  index to
• lowest index
• for i in vechigh to veclow loop

45
For loop

• hardware implementation constant loop count
• The constant loop count is a constraint that
  make some
• circuits difficult to describe.
• Example
• Count the number of of trailing zeros on a
  value
• count the zeros until a 1 is reached then stop.
• This would be easy to describe as a while loop
  but
• would be unsynthesisable.
• Exit and next statement may be used

46
For loop exit statement

• The exit statement allows the execution of a for
  loop to
• be stopped.
• The loop is exited, even thought it has not
  completed
• all its iterations.
• Example
• Count the number of of trailing zeros on a
  value
• count the zeros until a 1 is reached then stop.

47
architecture behavior of count_trailing_zeros is
process (vec) variable result unsigned(4
downto 0) begin result to_unsigned(0,
resultlength)) for i in vecreverse_range
loop exit when vec(i) 1 result result
1 end loop count lt result end
process end
48
For loop next statement

• The next statement is closely to the exit
  statement
• next statement skips any statements remaining
  in the
• current iteration of the loop and moves
  straight on to
• next iteration.
• Example

49
architecture behavior of count_ones is
process (vec) variable result unsigned(4 downto
0) begin result to_unsigned(0,
resultlength)) for i in vecrange
loop next when vec(i) 0 result result
1 end loop count lt result end
process end
