Rocks and Minerals

1
Rocks and Minerals

• Mixtures and Compounds

2
Rocks and Minerals

• Rocks are mixtures of grains of minerals cemented
  together
• Minerals have well-defined chemical formulas and
  crystal structures

Amethyst, a mineral
3
Some Common Minerals

• Olivine (Fe, Mg)2SiO4
• Quartz SiO2
• Feldspar NaAlSi3O8
• Mica KAl2 (AlSi3O10)(OH) 2
• Pyroxene (Mg,Fe)2Si2O6
• Amphibole Ca2(Mg,Fe)5Si8O22(OH) 2
• Calcite CaCO3
• Dolomite CaMg(CO3)2

4
Lattice Structure of Quartz
Red is oxygen, blue is silicon
5
Finding Composition

• Multiply the atomic mass by the subscript for
  each element in the formula
• Add them all up to get the total molar mass

6
The Rock Cycle
7
Igneous Rocks

• Intrusive
• Formed underground as magma cools
• Cools slowly so big crystals
• granite
• Extrusive
• Formed on surface as lava cools
• Cools quickly so small or no crystals
• obsidian

8
Sedimentary Rocks

• Formed when rock particles (sediment) are fused
  together (cementation) by pressure
• Layered structure
• Named according to size or type of particles
• Sandstone, mudstone, limestone

9
Metamorphic Rock

• Rocks that have undergone chemical change by high
  temperature or pressure
• NO MELTING!
• Examples
• limestone becomes marble
• shale becomes slate

10
Rock Characteristics

• Porosity
• Granularity
• Hardness
• Density
• Color

• Characteristics reflect
• Mineral composition
• Method of formation

11
Principle of Superposition

• Assumes no change in position of layer
• Oldest rocks will be on the bottom
• Youngest rocks on top
• Gives relative ages of the rocks

12
Principle of Superposition
13
Radioactive Dating

• Measure ratio of radioactive isotope to decay
  product
• Use known half life to determine age
• Gives absolute age of the rock

14
WeatheringBreaking Down Rocks

• Physical
• Ice
• Plants
• Chemical
• Carbonic acid
• Acid rain
• Oxidation

15
Weathering

• Some rocks are more resistant to weathering than
  others

16
Physical Weathering
17
Acid Rain The Same Statue
1908 1969
18
Erosion and DepositionShaping the Land

• Water
• Fast moving carries lots of sediment, carves
  canyons
• Slow moving deposits sediment forming deltas
• Wind
• Arches
• Dunes
• Glaciers
• Deep U-shaped valleys
• Terminal moraines

19
Grand Canyon
20
Nile Delta
21
Braided Rivers

• Braided rivers in Alaska carry sediment from snow
  melts to flat planes

22
Rainbow Arch, Arizona
23
Sand Dunes, Algeria
24
Glacier Valley, Switzerland
25
Terminal Moraine
