Hardware Fault Tolerance Through Simultaneous Multithreading part 3

1
Hardware Fault Tolerance Through Simultaneous
Multithreading (part 3)

• Jonathan Winter

2
3 SMT Fault Tolerance Papers

• Eric Rotenberg, "AR-SMT - A Microarchitectural
  Approach to Fault Tolerance in Microprocessors",
  Symposium on Fault-Tolerant Computing, 1999.
• Steven K. Reinhardt and Shubhendu S. Mukherjee,
  "Transient Fault Detection via Simultaneous
  Multithreading", ISCA 2000.
• Shubhendu S. Mukherjee, Michael Kontz and Steven
  K. Reinhardt, "Detailed Design and Evaluation of
  Redundant Multithreading Alternatives", ISCA 2002.

3
Outline

• Background
• SMT
• Hardware fault tolerance
• AR-SMT
• Basic mechanisms
• Implementation issues
• Simulation and Results
• Transient Fault Detection via SMT
• Sphere of replication
• Basic mechanisms
• Comparison to AR-SMT
• Simulation and Results
• Redundant Multithreading Alternatives
• Realistic processor implementation
• CRT
• Simulation and Results
• Fault Recovery
• Future Lectures ?

4
Sphere of Replication

• Size of sphere of replication
• Two alternatives with and without register file
• Instruction and data caches kept outside

5
Redundant Multithreading Alternatives

• Discusses real world fault tolerant processors
• Evaluates SRT on a more realistic and detailed
  processor than the previous paper
• Proposes Chip-level Redundant Threading (CRT)
• Detailed simulation results with new metric
• Relative SMT-Efficiency

6
Real World SMT, CMP, and FT

• Simulated processor based on Compaq Alpha Araña
  (a.k.a. 21464 or EV8)
• IBM Power4 and HP Mako are 2-way CMPs
• Compaq Himalaya uses multi-chip lockstepping
• IBM S/390 G5 uses on-chip lockstepping

7
Detailed Processor Description

• 8 way SMT with 4 hardware contexts
• IBOX fetches chunks of 8 instructions and
  forwards them to the PBOX
• Complex branch prediction mechanism
• Line predictor
• Branch predictor, jump target predictor, and
  return address stack

8
Detailed Processor Description (part 2)

• PBOX performs initial processing
• Register renaming and partial decoding
• Maintains tables for recovery from
  miss-predictions
• QBOX issues instructions out-of-order to the
  EBOX, FBOX, or MBOX
• Retires instructions and commits architectural
  state in program order
• Consists of instruction queue, in-flight table,
  and completion unit
• MBOX conducts loads and stores
• Load and store queues divided between threads
• Available queue space is very small per thread

9
SRT on Detailed Processor

• Input replication uses LVQ variant that allows
  out-of-order load issue from trailing thread
• Output comparison is the same as SRT
• Improvement is suggested that has per-thread SQ
• PBOX storage structures made per-thread to avoid
  deadlock situations
• Branch outcome queue converted to line prediction
  queue
• Preferential space redundancy (PSR) implemented
  to better cover permanent faults

10
Chip-level Redundant Threading

• Each core executes a lead and trailing thread
  from different programs
• LVQ and line prediction queue must forward data
  to other processors trailing thread
• Store buffer must receive retired stores from
  other processor for comparison

11
CRT Advantages

• CRT checks much less information to detect faults
  then lockstepped processors
• Lockstep fault detection circuitry is on critical
  path for cache misses
• CRT executes threads more efficiently because of
  SMT dynamic scheduling on each processor

12
Simulation Environment

• Asim performance model framework used
• Simulates processor like Alpha 21464
• All 18 SPEC CPU95 benchmarks used
• Combinations of SPEC used for multi-program
  simulations
• Lockstepped processor simulated with zero fault
  detection delay (Lock0) and with 8-cycle delay
  (Lock8)
• SRT architecture simulated with delays for
  forwarding line predictions and load values
• Extra delays for CRT architecture

13
SMT-Efficiency

• SMT-Efficiency (SMT-E) used instead of IPC
• SMT-E of individual thread is IPC of thread in
  SMT mode divided by the IPC in single-thread mode
  in an SMT
• Overall SMT-E is arithmetic mean of individual
  SMT-Efficiencies
• A. Snavely and D. M. Tullsen, Symbiotic Job
  Scheduling for a Simultaneous Multithreading
  Processor, ASPLOS 2000

14
SMT-Speedup ( SMT-Efficiency)

• Y. Sazeides and T. Juan, How to Compare the
  Performance of Two SMT Microarchitectures,
  ISPASS 2001

15
Preferential Space Redundancy

• Without PSR, 65 of instructions execute on same
  functional unit
• With PSR, only 0.06 of instructions run on the
  same unit
• No performance degradation is experienced

16
SRT One Logical Thread

• SRT 32 slower than single thread on SMT
• SRT 11 faster than running two redundant copies
• Degradation 30 with per-thread store queue
• Best-case 26 degradation with oracle store queue

17
SRT Two Logical Threads

• Degradation of SRT is 40
• Per-thread store queue give 32 degradation
• Store lifetime drops from 44 cycles to vs. 39 for
  single thread
• Oracle store queue gives 5 better efficiency

18
Chip-level Redundant Threading

• With one logical thread, CRT performs similarly
  to lockstepping
• With two logical threads CRT beats Lock0 and
  Lock8 by 10 and 2 respectively
• Adding the per-thread store queue causes CRT to
  beat Lock8 by 13 average (22 maximum)
• Using an oracle store queue improves performance
  by 6 more

19
CRT with Four Logical Threads

• Initial CRT configuration is no better than Lock8
• Adding per-thread store queue gives CRT 13
  better performance than Lock8
• Using an oracle store queue improve performance
  only by another 2

20
Conclusions

• The benefits of SRT are not as great as in the
  original paper when using a detailed model
• 30 and 32 degradation seen on single thread and
  multithread workloads
• SRT methods can be used to detect permanent
  faults
• Chip-level redundant threading gives improved
  performance over lockstepped processors
• Overall CRT provided a 13 improvement

21
Transient Fault Recovery

• AR-SMT suggests that the R-stream could be used
  as a checkpoint for recovery
• SRT suggests checkpoint/restart or failover
• Argues that since faults are infrequent, the will
  have a minor impact on performance

22
Future Lectures ?

• Hardware Transient Fault Recovery
• T.N. Vijaykumar, Irith Pomeranz, and Karl Cheng,
  Transient-Fault Recovery Using Simultaneous
  Multithreading, ISCA 2002
• Mohamed Gomaa, Chad Scarbrough, T.N. Vijaykumar,
  and Irith Pomeranz, Transient-Fault Recovery for
  Chip Multiprocessors, ISCA 2003
• Slipstream Processors (an AR-SMT extension)
• Karthik Sundaramoorth, Zach Purser, and Eric
  Rotenberg, Slipstream Processors Improving both
  Performance and Fault Tolerance, ASPLOS 2000
• Khaled Z. Ibrahim, Gregory T. Byrd, and Eric
  Rotenberg, Slipstream Execution Mode for
  CMP-Based Multiprocessors, HPCA 2003
