Statistical Model-Checking of Black-Box
Probabilistic SystemsVESTA

• Koushik Sen
• Mahesh Viswanathan
• Gul Agha
• University of Illinois Urbana-Champaign

2
Motivation

• Simulation of probabilistic systems
• used for performance evaluation and
• reliability analysis
• Can we use the traces obtained from simulation
  for formal verification?
• Statistical model-checking

3
Assumptions for black-box probabilistic systems

• Stochastic Discrete Event System
• Paths are of the form s0 --t0-gt s1 --t1-gt
• Labeling function L S ! 2AP
• Probability measure ? on the set of paths with
  common prefix is unknown
• Each state has a unique identifier
• Not required if properties are without nested
  probabilistic operators
• We have no control on the execution of the system
• Samples can be generated through discrete event
  simulation
• Time domain may be continuous or discrete
• Example
• Systems having underlying continuous-time Markov
  chain (CTMC) model
• Systems having underlying discrete-time Markov
  chain (DTMC) model

4
Properties in CSL sub-logic

• ? true a ? Æ ? ? PQ p(?)
• ? ? Ultt ? X ?
• where Q 2 lt,gt,,
• Plt 0.5(lt10 full)
• Probability that queue becomes full in 10 units
  of time is less than 0.5
• Pgt0.98( retransmit Ult200 receive)
• Probability that a message is received
  successfully within 200 time units without any
  need for retransmission is greater than 0.98

5
Statistical Approaches
Younes et al. 02,04
Monte-Carlo Simulator
Property
6
Our Approach
Property
7
Statistical Model Checking

• Given a model M, a set of samples S (generated
  from M) and a property ?
• A(S, s0,?)
• A(S, s0,?) yes with error ?
• ) ? PrA(S, s0,?) yes M,s0 2 ?
• A(S, s0,?) no with error ?
• ) ? PrA(S, s0,?) no M,s0 ² ?
• A(S, s0,?) dont know
• smaller the error (also called p-value) better
  the confidence

yes with error ? no with error ? dont know
8
Model-Checking Overview

• Check satisfaction of a formula
• Check satisfaction of its sub-formula
• Use the result to check satisfaction of the
  formula
• ?1 Æ ?2 is satisfied at s iff
• ?1 is satisfied at s
• ?2 is satisfied at s
• ?1 Ultt?2 is satisfied on a path s1s2 iff
• At si, ?2 is satisfied
• At sj (for all j lti), ?1 is satisfied
• time(si) time(s1) lt t
• Pltp ( ?) is satisfied at s iff
• probability that a path from s satisfies ? is
  less than p

Easy
Easy
How??
9
Checking Plt0.6(p Ult12 q) statistically at s
Sample contains, say, 30 paths from s

• On 21 paths (p Ult12 q) is satisfied
• 21/30 gt 0.6
• can we say that Plt0.6(p Ult12 q) is violated at s
  ??
• Statistically, yes, provided we quantify the
  error in our decision
• error ?
• PrOn 21 (or more) out of 30 paths (p Ult12 q)
  hold probability that (p Ult12 q) holds on
  a path is less than 0.6
• PrX 21 where XBinomial(30,0.6)

.
p Ult12 q
10
Error (p-value)

• Let r ( of paths on which (p Ult12 q) hold /
  of total paths)
• Let p Pr(p Ult12 q) holds on a path
• no answer (formula violates)
• yes answer (formula holds)

error Prr 21/30 p 0.6
error Prr 10/30 p 0.6
11
Nested Checking Plt0.6(?1Ult12?2) at s

• ?1 and ?2 contain nested probabilistic operators
• Checking (?1 Ult12 ?2) over a path
• Answers are not simply yes or no
• Answers can be
• yes with error ?
• no with error ?
• dont know
• Need a modified decision procedure
• Handle dont know to get useful answers
• Incorporate error of decision for sub-formulas

12
Checking Plt0.6(?1Ult12?2) at s (Problem)

• Solution
• Resolve dont know (?) in adversial fashion
• Observation region
• Create uncertainty region to incorporate error
  associated with sub-formulas.

.
?
?
?1
?3
?2
?1 Ult12 ?2
13
To check Plt0.6(?1Ult12?2) at s

• Need to check if of yes paths by of total
  paths lt 0.6
• Let, of yes paths20, of no paths 8,
  of dont know paths 3
• of yes paths lies between
• 20 resolve all dont know paths as no paths
• 23 resolve all dont know paths as yes
  paths
• Create an uncertainty region 0.6 - ?1 , 0.6
  ?2
• ?1 and ?2 depends on error for decision along
  all the sample paths
• Check if 20/30,23/30 falls outside 0.6 - ?1 ,
  0.6 ?2

0.6-?1
0.6?2
0.0
1.0
0.6
23/30
20/30
14
Case 1 yes answer
error estimate
r
p
0.6-?1
0.6?2
0.0
1.0
0.6
15
Case 2 no answer
error estimate
r
p
0.6-?1
0.6?2
0.0
1.0
0.6
16
Case 3 dont know answer
no error
0.6-?1
0.6?2
0.0
1.0
0.6
17
From nested error to uncertainty region

• Random variable X 1 if ? ² ? and 0 otherwise
• Let Random variable Z 1 if A(S,?,?) yes with
  error ? and 0 if A(S,?,?) no with error ?
• X Bernoulli(p) (say)
• Z Bernoulli(p) (say)
• We get samples from this distribution
• Can estimate p
• However, to verify P p(?)
• check if p p or not
• Relate p and p
• p-?p p p(1-p)?
• p - ?1 p p ?2 uncertainty region

18
Conjunction

• A(S,s,?1 Æ ?2)
• Let A(S,s,?1) x1 with error ?1
• and A(S,s,?2) x2 with error ?2
• where xi 2 yes,no,dont know
• If x1yes and x2yes then A(S,s,?1 Æ ?2)
  yes with error max(?1,?2)
• If x1no or x2no then A(S,s,?1 Æ ?2) no
  with error ?1 ?2 - ?1?2
• Else dont know

19
Evaluation

• Implementation VeStA
• http//osl.cs.uiuc.edu/ksen/vesta/
• Tandem Queuing Network
• Cyclic Polling System
• Grid World Example
• Answers matched the numerical model-checker
• error (?) of the order 10-8 in all of our
  experiments
• Very high confidence in our result
• Disadvantage Space requirement is high
• Required to store all samples before
  model-checking

20
Future Work

• Use Machine Learning to get rid of state
  identifiers
• Possible for CTMC models Sen et al. QEST 04
• State identifiers are not required if there is no
  nested probabilistic operator
• In practice most interesting properties are
  without nested probabilistic operators
• Verify probabilistic properties of various
  network protocols
• Earlier intractable due to large state space
