Chapter 11 The Muscular System

1
Chapter 11The Muscular System
2
Muscle Attachment SitesOrigin and Insertion

• Skeletal muscles shorten pull on the bones they
  are attached to
• Origin is the bone that does not move when muscle
  shortens (normally proximal)
• Insertion is the movable bone (some 2 joint
  muscles)
• Fleshy portion of the muscle in between
  attachment sites belly

3
Coordination Within Muscle Groups

• Most movement is the result of several muscle
  working at the same time
• Most muscles are arranged in opposing pairs at
  joints
• prime mover or agonist contracts to cause the
  desired action
• antagonist stretches and yields to prime mover
• synergists contract to stabilize nearby joints
• fixators stabilize the origin of the prime mover
• scapula held steady so deltoid can raise arm

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
Muscles of Facial Expression

• Arise from skull insert onto skin
• Encircle eyes, nose mouth
• Express emotions
• Facial Nerve (VII)
• Bells palsy facial paralysis due

9
Muscles of Facial Expression

• Orbicularis oculi closes the eye
• Levator palpebrae superioris opens the eye
• Orbicularis oris puckers the mouth
• Buccinator forms the muscular portion of the
  cheek assists in whistling, blowing, sucking
  chewing

10
(No Transcript)
11
Extrinsic Muscles of the Eyeballs

• Extrinsic muscles insert onto white of eye
• Fastest contracting most precisely controlled
• Cranial nerves 3, 4 6 innervate the six muscles
• 4 Rectus muscles 2 obliques
• Intrinsic muscles are found within the eyeball
• Levator palpebrae superioris raises eyelid

12
(No Transcript)
13
Muscles that Move the Mandible

• Masseter, temporalis pterygoids
• Arise from skull insert on mandible
• Cranial nerve V (trigeminal nerve)
• Protracts, elevates or retracts mandible
• Temporalis Masseter elevate the mandible
  (biting)
• temporalis retracts

14
(No Transcript)
15
Jaw Muscles -- Deep Dissection

• Lateral pterygoid protracts mandible
• sphenoid bone to condyle of mandible
• Medial pterygoid elevates protracts mandible
• sphenoid bone to angle of mandible
• Together move jaw side to side to grind food.

16
Muscles that Move the Tongue

• 4 extrinsic muscle ariseelsewhere, but
  insertinto tongue
• Genioglossus
• from inside tip of mandible
• Styloglossus
• from styloid process
• Palatoglossus
• from hard palate
• Hyoglossus
• from hyoid bone
• Together move tongue in various directions
• Intubation is necessary during anesthesia since
  Genioglossus relaxes tongue falls posteriorly
  blocking airway

17
Muscles that Move the Head

• Sternocleidomastoid muscle
• arises from sternum clavicle inserts onto
  mastoid process of skull
• innervated by cranial nerve XI (spinal accessory)
• contraction of both flexes the cervical vertebrae
  extends head
• contraction of one, laterally flexes the neck and
  rotates face in opposite direction

18
Muscles of Abdominal Wall

• Notice 4 layers of muscle in the abdominal wall

19
(No Transcript)
20
Transverse Section of Body Wall

• Rectus sheath formed from connective tissue
  aponeuroses of other abdominal muscles as they
  insert in the midline connective tissue called
  the linea alba

21
Muscles that Move the Vertebrae

• Quite complex due to overlap
• Erector spinae fibers run longitudinally
• 3 groupings
• spinalis
• iliocostalis
• longissimus
• extend vertebral column
• Smaller, deeper muscles
• transversospinalis group
• semispinalis, multifidis rotatores
• run from transverse process to dorsal spine of
  vertebrae above help rotate vertebrae

22
Muscles Used in Breathing
23
(No Transcript)
24
(No Transcript)
25
Female Pelvic Floor Perineum

• Both the pelvic diaphragm ( coccygeus levator
  ani) and the muscles of the perineum fill in the
  gap between the hip bones

26
Muscles of Male Perineum
27
Stabilizing the Pectoral Girdle

• Anterior thoracic muscles
• Subclavius extends from 1st rib to clavicle
• Pectoralis minor extends from ribs to coracoid
  process
• Serratus anterior extends from ribs to inner
  surface of scapula
• Posterior thoracic muscle
• Trapezius extends from skull vertebrae to
  clavicle scapula
• Levator scapulae extends from cervical vertebrae
  to scapula
• Rhomboideus extends from thoracic vertebrae to
  vertebral border of scapula

28
Axial Muscles that Move the Arm

• Pectoralis major Latissimus dorsi extend from
  body wall to humerus.

29
(No Transcript)
30
(No Transcript)
31
Muscles that Move the Arm

• Deltoid arises from acromion spine of scapula
  inserts on arm
• abducts, flexes extends arm
• Rotator cuff muscles extend from scapula
  posterior to shoulder joint to attach to the
  humerus
• supraspinatus infraspinatus above below
  spine of scapula
• subscapularis on inner surface of scapula

32
Flexors of the Forearm (elbow)

• Cross anterior surface of elbow joint form
  flexor muscle compartment
• Biceps brachii
• scapula to radial tuberosity
• flexes shoulder and elbow supinates hand
• Brachialis
• humerus to ulna
• flexion of elbow
• Brachioradialis
• humerus to radius
• flexes elbow

33
Extensors of the Forearm (elbow)

• Cross posterior surface of elbow joint forms
  extensor muscle compartment
• Triceps brachii
• long head arises scapula
• medial lateral heads from humerus
• inserts on ulna
• extends elbow shoulder joints
• Anconeus
• assists triceps brachii in extending the elbow

34
(No Transcript)
35
Muscle that Pronate Flex

• Pronator teres
• medial epicondyle to radius so contraction turns
  palm of hand down towards floor
• Flexor carpi muscles
• radialis
• ulnaris
• Flexor digitorum muscles
• superficialis
• profundus
• Flexor pollicis

36
Muscles that Supinate Extend

• Supinator
• lateral epicondyle of humerus to radius
• supinates hand
• Extensors of wrist and fingers
• extensor carpi
• extensor digitorum
• extensor pollicis
• extensor indicis

37
(No Transcript)
38
(No Transcript)
39
Retinaculum

• Tough connective tissue band that helps hold
  tendons in place
• Extensor Flexor retinaculum cross wrist region
  attaching from bone to bone (carpal tunnel
  syndrome painful compression of median nerve
  due to narrowing passageway under flexor
  retinaculum

40
(No Transcript)
41
Muscles Crossing the Hip Joint

• Iliopsoas flexes hip joint
• arises lumbar vertebrae ilium
• inserts on lesser trochanter
• Quadriceps femoris has 4 heads
• Rectus femoris crosses hip
• 3 heads arise from femur
• all act to extend the knee
• Adductor muscles
• bring legs together
• cross hip joint medially
• see next picture
• Pulled groin muscle
• result of quick sprint activity
• stretching or tearing of iliopsoas or adductor
  muscle

42
Adductor Muscles of the Thigh

• Adductor group of muscle extends from pelvis to
  linea aspera on posterior surface of femur
• pectineus
• adductor longus
• adductor brevis
• gracilis
• adductor magnus (hip extensor)

43
Muscles of the Butt Thigh

• Gluteus muscles
• maximus, medius minimus
• maximus extends hip
• medius minimus abduct
• Deeper muscles laterally rotate femur
• Hamstring muscles
• semimembranosus (medial)
• semitendinosus (medial)
• biceps femoris (lateral)
• extend hip flex knee
• Pulled hamstring
• tear of origin of muscles from ischial tuberosity

44
(No Transcript)
45
(No Transcript)
46
Cross-Section through Thigh

• 3 compartments of muscle with unique innervation
• anterior compartment is quadriceps femoris
  innervated by femoral nerve
• medial compartment is adductors innervated by
  obturator nerve
• posterior compartment is hamstrings innervated by
  sciatic nerve

47
Muscles of the Calf (posterior leg)

• 3 muscles insert onto calcaneus
• gastrocnemius arises femur
• flexes knee and ankle
• plantaris soleus arise from leg
• flexes ankle
• Deeper mm arise from tibia or fibula
• cross ankle joint to insert into foot
• tibialis posterior
• flexor digitorum longus
• flexor hallucis longus
• flexing ankle joint toes

48
Muscles of the Leg and Foot

• Anterior compartment of leg
• extensors of ankle toes
• tibialis anterior
• extensor digitorum longus
• extensor hallucis longus
• tendons pass under retinaculum
• Shinsplits syndrome
• pain or soreness on anterior tibia
• running on hard surfaces
• Lateral compartment of leg
• peroneus mm plantarflex the foot
• tendons pass posteriorly to axis of ankle joint
  and into plantar foot

49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
