Status of current work on Faculae and Sunspots

1
Status of current work onFaculae and Sunspots

• Åke Nordlund, University of Copenhagen
• Tobias Heinemann, University of Copenhagen
• Mats Carlsson, University of Oslo
• Boris Gudiksen, University of Oslo
• Bob Stein, Michigan State University
• Sacha Kosovichev , Stanford
• Dali Georgobiani, Stanford
• Nagi Mansour, NASA-Ames

2
Grand Plan
3
Today Progress Report

• Faculae
• Center-to-limb behavior
• Light bridges
• Relation to pores, umbrae and penumbrae
• Sunspots
• Importance of resolution

4
Photospheric physics

• Equation of state
• Qualitative HHeMe
• Accurate Lookup table
• Opacity
• Qualitative H-minus
• Accurate Lookup table Opacity Distribution
  Function
• Radiative energy transfer
• Qualitative Vertical horizontal rays
• Accurate Comprehensive set of rays

5
Coronal physics

• Equation of state
• Qualitative HHeMe
• Accurate Lookup table
• Heat conduction
• Spitzer conductivity
• Conduction parallel to B
• Radiative cooling
• Optically thin
• Cooling functions from the litterature

6
Chromospheric physics

• Equation of state
• Qualitative or accurate
• Energy fluxes
• Spitzer heat conduction
• Convective transport (driven)
• Radiation continuum and ke
• Radiative cooling
• Optically thick
• Approximation of key spectral lines

7
Code Staggered Mesh Code

• Cell centered mass and thermal energy densities
• Face-centered momenta and magnetic fields
• Edge-centered electric fields and electric
  currents

• Advantages
• simplicity OpenMP (MPI btw boxes)
• consistency (e.g., divB0)
• accuracy conservative, 5th order

8
Radiative Transfer Equation

• Solve in a form that directly gives the cooling

9
Opacity is binned, according to its magnitude,
into 4 bins.
10
5 Rays Through Each Surface Grid Point
Interpolate source function to rays at each height
11
Benchmarks Timing Results
12
Altix Itanium-2 Scaling
13
Plage Sunspot simulations

• Dimensions 12x12x3 Mm
• Intermediate resolution 250x250x125
• dx 48 km, dz 24 km
• Duration 60 min, production run
• Higher resolution 500x500x125
• dx 24 km, dz 24 km
• Duration 15 min, testing high res. effects
• Target resolution 1000x1000x250
• dx 12 km, dz 12 km
• Duration hours

14
Vertical magnetic field
250x250x125, duration 35 min Average flux
density slowly growing from 400 G to 600 G
12 Mm
-2
kG
2
15
Vertical slice, entropy
Resolution 250x250x125 Duration 35 min
3 Mm
12 Mm
16
High resolution (500x500x125)
Vertical magnetic field
Surface temperature
Size 12 Mm Resolution 24 km
17
Lites et al. AR 3-D structure
18
Sunspot lightbridges

• Model, scale 1.5 x 1.5 x 3 Mm
• resolution 12x12x12 km
• with radiation and ionization

19
Sunspot lightbridges

• Model, scale 1.5 x 1.5 x 3 Mm
• resolution 12x12x12 km
• with radiation and ionization

20
Faculae, continuum, G-band

• Hot walls
• Seen in projection
• Evacuated foreground
• G-band molecule bands
• Temperature sensitivity

21
Center-to-LimbVariation
22

Lites et al (Solar Physics)
23
G-band, inclined view
24
G-band, center to limb
25
Magnetic concentrations cool, low r,low
opacity.Towards limb,radiation emerges from
hot granulewalls behind.On optical depth
scale,magneticconcentrations are hot, contrast
increases with opacity
26
Temperature structure
Granule (G) Intergranular lane (IG) G-band
bright point (BP) Dark flux concentration (FC)
TTgband TTgcont
27
Striated Bright Walls
Observed
Model
28
Dark striations weaker B larger r see higher
cooler layer
29
Solar velocity spectrum
Velocity spectrum v(k) (k P(k))1/2
30
Velocity driving for corona sims
Voronoi tessellation ensemble
Velocity spectrum from three superposed ensembles
31
Scale Free Spectrum?Doppler Image of the
SunMichelson Doppler Interferometer (SOHO/MDI)
32
Solar horizontal velocity (observed)Scales
differ by factor 2 which is which?
33
Solar horizontal velocity (model)Scales differ
by factor 2 which is which?
24 Mm
12 Mm
6 Mm
3 Mm
34
Supergranulation scale convection first relax
24x24x9 Mm, then 50x50x20 Mm

• Origin of supergranulation
• Role of HeII ionization
• Role of magnetic field
• Emergence of magnetic flux
• Maintenance of magnetic network
• Driving coronal heating simulations

Vertical velocity
35
Solar velocity spectrum24 Mm simulation will
fill gap
36
Summary

• High resolution, large resources needed
• Faculae
• Sunspots
• Lightbridges illusion!
• Large scale convection
• Approx. scale free horizontal motions!
