Title: Using GIS to Aid in TMDL Modeling


1
Using GIS to Aid in TMDL Modeling
  • Term Project Presentation
  • CE394K GIS in Water Resources
  • November 30, 2000
  • Tony Sarman

2
Objective
  • To understand the Total Maximum Daily Load (TMDL)
    process
  • To see what abilities GIS has to aid in the
    development of TMDLs

3
Background
  • Clean Water Act section 303(d)
  • Identification and rank waters with insufficient
    controls
  • Set TMDL
  • Implementation of the control measures
  • Effluent Limits
  • Best Management Practices (BMP)

4
Background
  • TMDL - maximum amount of a pollutant that a
    water body can receive and still meet water
    quality standards.
  • LC WLA LA MOS

5
Basins 3.0
  • Better Assessment Science Integrating Point and
    Nonpoint Sources (BASINS)
  • Directly integrated within an ArcView GIS
    environment
  • Modeling Tools
  • QUAL2E
  • Soil and Water Assessment Tool (SWAT)
  • Generation and analysis of model simulation
    (GenScn)

6
QUAL2E
  • One-dimensional, steady-state water quality model
  • Able to give concentrations along the length of a
    river
  • Predominantly point source

7
SWAT
  • Simulates hydrology, pesticide and nutrient
    cycling, bacteria transport, erosion, and
    sediment transport
  • Predict effects of land use management
  • Daily time step

8
GenScn
  • Replaced NPSM
  • Create, analyze, and compare simulation scenarios
  • Simulate the hydrologic and associated water
    quality processes on pervious and impervious land
    surfaces and in streams and well-mixed
    impoundments

9
Summary
  • Still working with the program
  • Fixed problems since v. 2.0
  • Raster Data Require Spatial Analyst
  • May be possible to model lakes, bays, estuaries
  • Snow melt algorithm (degree-day)
