Changes to ISO 10303239

1
Changes to ISO 10303-239

• Rob Bodington, Phil Spiby

2
Objectives of telecon

• Inform about project
• Agree scope of changes to ISO 10303-239
• Agree publication strategy
• Timescales

3
Objectives
TOG to agreement2009-01-19

• Deliver update edition of ISO 10303-239
• Updated ISO 10303-239 ready for taking forward
  ballot 31st March
• Incorporate required changes identified from PLCS
  deployments
• Ensure compatibility with AP233
• Include additional AP203/233 modules as
  appropriate
• Ensure backward compatibility with AP239
• There may be an impact on PLCS templates
• E.g. description
• Attempt to ensure that seen as minor
  corrections/extensions not another reason not
  to use PLCS

4
Approach to publication
TOG to agreement2009-01-19

• Agree publication strategy timetable
• New edition?
• Publish as International Standard 2010
• The process is to raise a new work item for the
  development of the AP239e2 Committee Draft (CD)
• NWI will list modules to be changed and new
  modules
• Submit NWI to SC4 Change management for a 2 week
  review
• Send for initial ballot under ISO process as
  combined CD and NWI
• AP239e2 CD ballot will include TS ballot of all
  new and changed modules as well as the AP
• Action develop NWI by 30 Jan 2009
• Identify resources
• Eurostep funded by UK MoD to March 31st
• Invite other resources to participate to take the
  AP forward
• Role of the TOG
• Build consensus
• PLCS OASIS Core team
• Action email Core team
• PLCS OASIS TOG
• Completed
• PLCS OASIS TC

5
Types of change

• PLCS/SC4 (SEDS) modifications to PLCS modules
• Deployment of the standard has identified issues
  to be addressed
• Raised as SEDS against the standard Only SEDS
  will be considered
• Action ensure ALL PLCS issues are raised as SEDS
• Action ensure that everyone is aware of the
  issue raising process
• Either SEDS or DEXlib issue
• New AP239modules
• Some new PLCS modules will be required to address
  the issues
• Aim to avoid scope creep!
• Action Identify the required new modules
• SC4 modifications to AP239 modules
• Development of AP203e2/AP233/AP236/AP210 has led
  to some changes to PLCS modules
• New editions of PLCS modules have been
  published
• Action Summarize all the changes evaluate the
  impact
• Use of Ap203e2/233 modules by PLCS
• Ap203e2/233 have developed a number of new
  modules
• Action Summarize modules and agree what if any
  should be incorporated
• ISO documentation changes
• Ref data can now be documented in modules

6
PLCS/SC4 (SEDS) modifications to AP239 modules

• Collecting all SEDS
• Select extensions
• New PLCS modules
• Extended_observation
• Extended_message
• Information collection
• Configuration management?
• Resource item?

7
SC4 modifications to PLCS modules

• 35 out of 138 modules changed
• Focussing on ARM changes
• MIM changes can we ignore?
• Types of Changes
• Changes to USE FROMS, selects, rules
• Changes to entities
• New entities
• Reordering of attributes
• A number of ARM modules have had their attributes
  reordered
• PLCS p21 files no longer compatible
• Do we care? how do we get this changed back?
• Mandatory attributes now optional
• Documentation pulls in extraneous ap203 modules

TOG to agreement2009-01-19 Focus on the
ARM However, we will have to list the MIM changes
TOG to agreement2009-01-19 Ignore changes
Raise issues
8
SC4 modifications to PLCS modules

• Geometry
• contextual_shape_positioning
• Complete rewrite
• elemental_geometric_shape
• Removed Value_with_unitAddedIdentification_assig
  nment (WHY?)
• shape_property_assignment
• Documentation pulls in extraneous ap203 modules

TOG to agreement2009-01-19 geometry is not the
focus of PLCS so live with change
Raise SEDS to get this addressed
9
SC4 modifications to PLCS modules

• Assembly structure
• An Assembly_component_relationship is now a type
  of Product_occurrence_definition_relationshipProd
  uct_occurrence_definition_relationship is an
  abstract supertype with no supertypesNo idea why
  they changed this
• It was a type of View_definition_usage.
• This may have a major impact
• Documentation pulls in extraneous ap203 modules

10
(No Transcript)
11
SC4 modifications to PLCS modules

• Properties / representation
• extended_measure_representation
• Changedvalue_limitRemoved value_limit_with_glob
  al_unitqualified_property_value_representation
• property_assignment
• Made Property_representation a subtype of
  Property_definition_representation
• independent_property_representation
• Independent_property_representation now a subtype
  of Property_definition_representation

12
SC4 modifications to PLCS modules

• State
• Changed by AP233
• Same content split modules
• Will require minor modifications to ap239_
  modules

13
SC4 modifications to PLCS modules

• Task
• Changed by A233
• extended_task_element
• Will require minor modifications to ap239_
  modules

14
Use of AP203/233 modules by PLCS

• Should we incorporate all of 233 modules?
• Description
• Fixes 239 hack
• Analysis
• Behaviour
• Validation Verification
• Risk?
• However, it is not yet at TS level

15
ISO publication/documentation changes

• Ref data can now be documented in modules
• Action Decide if we include ref data.
• E.g identification assignment
• Propose to keep this in the dexs
• Need to check existing modules for reference data
• Abstract Test Suite?
• We did not have any before .
• Conformance classes?
• We did not have any before . I think that we
  should keep them as DEXs
• XSLT changes to AP
• Action investigate

NDLO resourcing work on test rallies Can
contribute to the abstract test suite
16
Plan

• PLCS/SC4 (SEDS) modifications to Ap239 modules
• Analyze issues
• Identify / Agree new modules
• Information collection . (others)
• Address SEDS
• Develop new Ap239 modules
• Create module
• Create template
• SC4 modifications to PLCS modules
• Analyze changes impact analysis
• Analyze change to State
• Analyze change Task
• Analyze Assembly
• Update ap239 modules
• Use of Ap203/233 modules by PLCS
• Analyze new modules
• Identify those that are useful to PLCS
• Add module
• Extend selects

17
Milestones

• SC4 modifications to AP239 modules understood
  (30th Jan)
• Agreed / changed
• Scope of AP239e2 agreed (30th Jan)
• new AP239 modules identified
• 203/233 modules to include agreed
• AP239 modules SEDS modules addressed (28th Feb)
• SC4 SEDS workshop 10-12th March
• New AP239 modules developed (20th March)
• AP239e2 modules ready for SC4 process (31st
  March)
• New HTML for AP239e2 delivered
