Rocks

1
Rocks
ROCKS

• Chapter 10

2
Rocks

• Naturally occurring solid material made of one or
  more minerals
• Grouped into 3 main types, based on the way it
  was formed

3
IGNEOUS ROCKS
1
4
IGNEOUS ROCKS

• Formed from magma that cools and hardens
• Fire Formed

5
IGNEOUS ROCKS 2 types

• Intrusive rocks
• formed deep within Earth
• Cools slowly, large crystals
• Coarse grained

• Extrusive rocks
• formed from lava at Earths surface
• Cools quickly, small crystals
• fine grained

6
IGNEOUS ROCKS texture

• Size of crystal grains and chemical composition
  are used to classify igneous rocks
• Texture depends on time it takes a rock to harden
  (cooling rate)

7
IGNEOUS ROCKS porphyry(POR-fuh-ree)

• Igneous rock with a mixture of large and small
  crystals

8
Two types of magma

• Felsic
• Light-colored
• Thick and slow flowing
• Rich in silica

• Mafic
• Dark-colored
• Very fluid
• Rich in iron

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Scoria
16
Igneous Rock Structures

• Intrusions underground rock masses

• Extrusions surface rock masses

17
INTRUSIONS

• Batholiths
• largest igneous intrusions
• Form when huge bodies of magma cool underground
• Cover 1000 km

18
Batholith
19
(No Transcript)
20
INTRUSIONS

• Laccoliths
• Domelike masses formed from magma bulging upward

21
(No Transcript)
22
This laccolith in Red and White Mountain,
Colorado, is of Tertiary age. Overlying layers
of rock have been eroded.
23
INTRUSIONS

• Dike
• Sheets of igneous rocks that cut across the rock
  layer

24
(No Transcript)
25
Dike
26
Dike
27
INTRUSIONS

• Sill
• Sheet of hardened magma that forms between and
  parallel to layers of rock

28
(No Transcript)
29
Sill
30
EXTRUSIONS

• Volcanic neck
• The plug of hardened magma left in the vent from
  which lava flowed

31
(No Transcript)
32
Volcanic neck
33
INTRUSIONS

• Stock
• Similar to batholiths but less than 100 km

34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
SEDIMENTARY ROCKS
2
38
Sedimentary Rocks

• 75 of Earths surface is sedimentary rock!

39
How Sedimentary Rocks are made

• Mud, sand, gravel and shells are sediments that
  make up rocks
• Sediments are moved by wind and water
• Compaction Pressure placed in sediment layers
  cause them to change to rocks
• Cementation sediments are joined together
  (cemented) by minerals dissolved in water
• This process results in the formation of layers
  called strata.

40
(No Transcript)
41
The major characteristics of all sedimentary
rocks is that they form layers!
42

• "For your information, there's a lot more to
  ogres than people think...

Ogres are like sedimentary rocks!
Sedimentary rocks have layers...
Ogres have layers!
...We both have layers."
43
Sedimentary rocks usually form in water

• Ripple marks and mud cracks

44
Fossils often preserved in sedimentary rocks
45
Sedimentary Rocks Classified by

• Composition
• Texture
• Grain size

46
Types

• Clastic
• Organic
• Chemical

47
1. Clastic Rocks

• Formed by broken pieces or fragments of rock
• Classified according to size and shape of
  fragments

48
Clastic Rocks

• Conglomerates
• Made of rounded pebbles and other rocks of
  different sizes and cemented together by clay,
  mud ,or sand
• Formed when rivers deposit large pieces of rock
• Pieces of rock rounded by water before deposited

49
Conglomerate
50
Clastic Rocks

• Breccia
• Similar to conglomerates, but fragments are sharp
  and angular
• Not carried far enough by water to round the edges

51
Breccia
52
Clastic Rocks

• Sandstone
• Made of small, sand-sized grains
• Very common
• Resistant to wear and decay
• Used to make buildings

53
Sandstone
54
Clastic Rocks

• Mudrock
• Formed from small particles of clay
• Example shale

55
shale
56
shale
57
2. Organic Rock

• Formed directly or indirectly from material that
  used to be living

58
Organic Rock

• Fossilized Limestone
• Shells from dead animals (containing calcium
  carbonate) that sink to bottom of ocean floor

59
Limestone
60
Organic Rock

• Chalk
• Composed of animals and calcium carbonate that
  have been pressed together

61
Chalk
62
Organic Rock

• Coal
• Rock formed from plants that lived millions of
  years ago

63
3. Chemical Rock

• Formed by chemical means that do not involve any
  living organisms
• Can occur through evaporation or chemical action

64
Chemical Rock

• Limestone
• Formed directly from ocean water instead of
  organisms

65
Chemical Limestone
66
Chemical Rock

• Rock salt
• Natural form of common table salt
• Ex Halite

67
(No Transcript)
68
Chemical Rock

• Rock gypsum

69
METAMORPHIC ROCKS
3
70
Metamorphic Rocks

• Metamorphism
• Changing of one type of rock in to another due to
  -
• Tremendous heat
• Great pressure
• Chemical reactions ( a change in composition of
  minerals)

71
Metamorphic Rocks

• Types of Metamorphism
• Contact Metamorphism
• Occurs when rocks are heated by contact with
  magma or lava
• Covers a small area
• Regional Metamorphism
• Occurs when rocks are buried deep beneath Earths
  surface and changed by increase in temperature
  and pressure
• Covers a large area

72
Types of Metamorphic Rock

• Foliated Texture
• Mineral crystals arranged in parallel layers or
  bands (flatten under pressure)

Slate
Schist
?
?
Gneiss
(from clay or shale)
(from granite, basalt, or slate)
(from granite)
73
You will need Quick-time to See the granite to
gneiss animation
http//geowww.ou.edu/jahern/dynamic/notes/met_rx/
AN07_001.MOV
74
Foliated Texture
slate
75
Foliated Texture
phyllite
76
Foliated Texture
gneiss
77
Types of Metamorphic Rock

• 2. Unfoliated Texture
• No bands of crystals
• Dont break in layers

78
Unfoliated Texture
marble
79
Unfoliated Texture
quartzite
80
(No Transcript)
