Strictly Lexical Dependency Parsing

1
Strictly Lexical Dependency Parsing

• Qin Iris Wang and Dale Schuurmans
• University of Alberta
• wqin,dale_at_cs.ualberta.ca

Dekang Lin Google, Inc. lindek_at_google.com
2
Lexical Statistics In Parsing

• Widely used in previous statistical parsers, such
  as
• Collins (1996, 1997, 1999)
• Chaniak (2000)
• But, have been proved not very useful
• Gildea (2001)
• Bikel (2004)
• Unlexicalized parsing
• Klein and Manning (2003)

3
Strictly Lexicalized Parsing

• A dependency parsing model
• All the parameters are based on word statistics
• No POS tags or grammatical categories needed
• Advantages
• Making the construction of Treebank easier
• Especially beneficial for languages where POS
  tags are not as clearly defined as English (such
  as Chinese)

4
POS tags in Parsing

• All previous parsers use a POS lexicon
• Natural language data is sparse
• Bikel (2004) found that of all the needed bi-gram
  statistics, only 1.49 were observed in the
  treebank
• Part-of-speech tags
• Words belonging to the same part-of-speech are
  expected to have the same syntactic behavior

5
An Alternative Approach

• Distributional word similarities
• Words tend to have similar meanings if they tend
  to appear in the same contexts
• Soft clusters of words
• Computed automatically
• Not having been used in parsing before

6
Outline

• A probabilistic dependency parsing model
• Similarity-based smoothing
• Experimental results
• Related work and conclusions

7
An Example Dependency Tree

• A dependency tree structure for the sentence
• The kid skipped school regularly.

? 0
school 4
The 1
kid 2
skipped 3
regularly 5
8
Probabilistic Dependency Parsing

• S an input sentence T a candidate
  dependency tree
• F(S) the set of possible dependency trees
  spanning on S. The goal of parsing
• The tree T is constructed in steps G1, G2 , GN.
  (N words in the sentence)

9
Different Sequences of Steps May Lead to the Same
Dependency Tree
3
5
1
2
4
? 0
school 4
The 1
kid 2
skipped 3
regularly 5
4
5
1
2
3
? 0
school 4
The 1
kid 2
skipped 3
regularly 5
10
Canonical Order of the Links

• Left to right
• Bottom-up
• Head outward
• Right attaching first

11
Whats Involved in Each Step?

• Each step involves four events, conditioned on
  the context

Step (events)
Context
G1
? 0
regularly 5
The 1
school 4
kid 2
skipped 3
12
Whats Involved in Each Step?
Step (events)
Context

)
regularly 5
skipped 3
P (
skipped, regularly, C3R 1
)
regularly 5
skipped 3
P(
The number of modifiers already created
13
Whats Involved in Each Step?
Step (events)
Context
G4
14

• Suppose Gi corresponds to a dependency link (u,
  v, L).

• Maximum Likelihood estimates ?

Sparse Data!
15
Outline

• A probabilistic dependency parsing model
• Similarity-based smoothing
• Experimental results
• Related work and conclusion

16
Similarity-based Smoothing
skipped, regularly, C3R 1
)
regularly 5
skipped 3
P(
17
Similarity-based Smoothing
skipped, regularly,
)
regularly 5
skipped 3
P(
S(regularly)
S(skipped)
skipping 0.229951skip 0.197991skips
0.169982sprinted 0.140535bounced
0.139547missed 0.134966cruised 0.133933scooted
0.13387jogged 0.133638wandered 0.132721
frequently 0.365862routinely 0.286178periodicall
y 0.273665often 0.24077constantly
0.234693occasionally 0.226324who
0.200348continuously 0.194026continually
0.177632repeatedly 0.177434
18
Similarity-based Smoothing
skipped, regularly,
)
regularly 5
skipped 3
P(
S(regularly)
S(skipped)
skipping 0.229951skip 0.197991skips
0.169982sprinted 0.140535bounced
0.139547missed 0.134966cruised 0.133933scooted
0.13387jogged 0.133638wandered 0.132721
frequently 0.365862routinely 0.286178periodicall
y 0.273665often 0.24077constantly
0.234693occasionally 0.226324who
0.200348continuously 0.194026continually
0.177632repeatedly 0.177434
19
Similarity-based Smoothing
skipped, regularly,
)
regularly 5
skipped 3
P(
skip frequently skip routinely skip
repeatedly bounced often bounced who bounced
repeatedly
Similar contexts
20
Similarity-based Smoothing
C similar contexts of C
C
)
regularly 5
skipped 3
PSIM (
(
C
)
regularly 5
skipped 3
An event is more likely to occur after context C
if it tends to occur after similar contexts of C
21
Similarity-based Smoothing

• Finally,
• P(E C) a PMLE(E C) (1 a)
  PSIM(E C)

C is the frequency count of the corresponding
context C in the training data
22
(No Transcript)
23
Outline

• A probabilistic dependency parsing model
• Similarity-based smoothing
• Experimental results
• Related work and conclusion

24
Experimental Setup

• Word similarities
• Chinese Gigaword corpus
• Chinese Treebank (CTB 3.0), same data split as
  Bikel (2004)
• Training Sections 1-270 and 400-931
• Development Sections 301-325
• Testing Sections 271-300
• Dependency trees
• Converted from the constituency trees (Bikel,
  2004)

25
Experimental Results - 1
Evaluation Results on Chinese Treebank (CTB) 3.0

• Performance highly correlated with the length of
  the sentences

26
Comparison With an Unlexicalized Model

• For the unlexicalized model, input to the parser
  is the sequence of the POS tags

27
Comparison With an Strictly Lexicalized Joint
Model

• where hi and mi are the head and the modifier of
  the i'th dependency link.

• In (Dagan et al., 1999)

28
Comparison With a Strictly Less Lexicalized
Conditional Model

• Only one word in a similar context of C may be
  different from a word in C

29
Experimental Results - 2
Performance of Alternative Models (sentence
length lt 40)
30
Outline

• A probabilistic dependency parsing model
• Similarity-based smoothing
• Experimental results
• Related work and conclusion

31
Related Work

• Maximize the joint probability
• Collins (1997)
• Charniak (2000)
• Maximize the conditional probability
• Clark et al. (2002) CCG grammar
• Ratnaparkhi (1999) maximize the prob. during
  each step
• Dependency parsing models
• Yamada and Matsumoto (2002)
• Eisner (1996)
• MacDonald et al.(2005)
• Klein and Manning (2004) the DMV model
• Parsing Chinese with the Penn Chinese Treebank
• Bikel and Chiang (2000)
• Levy and Manning (2003)

32
Conclusions

• First work for parsing without using
  part-of-speech tags
• Strictly lexicalized parser outperformed its
  unlexicalized counterpart
• Takes the advantage of the similarity-based
  smoothing, which has not been successfully
  applied to parsing before.

33
Questions?
Thanks!
34
Notation

• / no more modifiers on the left/right
  of a word w
• / the current number of modifiers w
  has taken on its left / right
• (u, v, d) a dependency link with the direction
  d. u and v are integers, denoting the indices of
  the words (u lt v)
• LinkR(u, v) a link from u to v
• LinkL(u, v) a link from v to u

35
Assumptions

• depends only on w and
• LinkR(u, v) depends only on u, v, and
• LinkL(u, v) depends only on u, v, and

• Suppose the dependency link created in the step i
  is
• (u, v, d)
• If d L, Gi is the conjunction of , ,
  and LinkL (u, v).
• If d R, Gi is the conjunction of , ,
  and LinkR (u, v).

36
Feature Representation

• Represent a word w by a feature vector
• The features of w are the set of words occurred
  within a small context window of w in a large
  corpus
• The value of a feature w is

where P(w, w) is the probability of w and w
co-occur in a context window
37
Similarity-based Smoothing

• In (Dagan et al., 1999)

• The parameters in our model consist of
  conditional probabilities P(EC) where E is the
  binary variable linkd(u, v) or and the
  context C is either or


38
Similarity-based Smoothing

• In our model, the similar contexts are defined
  as

• We compute the similarity between two contexts
  as
