Title: University of Notre Dame


1
Thermionic Refrigeration
  • Jeffrey A. Bean
  • EE666 Advanced Semiconductor Devices

2
Outline
  • Types of refrigeration
  • Application of each type in electronics
  • Why the fuss about cooling?
  • Thermionic refrigeration (TIR) in detail
  • Current Devices
  • Improvements
  • Possible uses

3
Types of Refrigeration
  • Compressive
  • Utilizes a refrigerant fluid and a compressor
  • Efficiency 30-50 of Carnot value
  • Thermoelectric
  • Utilizes materials which produce a temperature
    gradient with potential across device
  • Efficiency 5-10 of Carnot value
  • Thermionic
  • Utilizes parallel materials separated by a small
    distance (either vacuum or other material)
  • Efficiency 10-30 of Carnot value

Shakouri, A. and Bowers, J. E., Heterostructure
Integrated Thermionic Refrigeration, 16th Int.
Conf. on Thermoelectrics, pp. 636, 1997
4
Compressive Refrigeration
  • 1) Refrigerant fluid is compressed (high pressure
    temperature increases)
  • 2) Fluid flows through an expansion valve into
    low pressure chamber (phase of refrigerant also
    changes)
  • 3) Coils absorb heat in the device

5
Thermoelectric Refrigeration (TER)
  • A temperature difference between the junctions of
    two dissimilar metal wires produces a voltage
    potential (known as the Seebeck
    Effect)
  • Peltier cooling forces heat
    flow from one side to the
    other by applying an
    external electric potential
  • Thermoelectric generation
    is utilized on deep space
    missions using a plutonium
    core as the heat source

http//www.dts-generator.com/main-e.htm
6
Thermionic Refrigeration (TIR)
  • Investigation into thermionic energy conversion
    began in the 1950s
  • Utilizes fact that electrons with high thermal
    energy (greater than the work function) can
    escape from the metal
  • General idea
  • A high work function
    metal cathode in contact
    with a heat source will
    emit electrons to a lower
    work function anode

Vacuum Barrier
7
Impact of Each Type on Electronics
  • Compressive
  • Pros efficient, high cooling power from ambient
  • Cons bulky, expensive, noisy, power consumption,
    scaling
  • Thermoelectric
  • Pros lightweight, small footprint
  • Cons lousy efficiency, low cooling power from
    ambient, cant be integrated on IC chips, power
    consumption
  • Thermionic
  • Pros integration on ICs using current
    technology, low power
  • Cons only support localized cooling, low cooling
    power from ambient temperature

8
Why the fuss about cooling?
  • Power dissipation in electronics is becoming a
    huge issue

Processor Chip Power Density
Intel
9
Refrigeration Terms
  • Efficiency
  • Carnot Efficiency
  • Figure of Merit
  • Voltage aDT
  • a - electrical conductivity
  • k - thermal conductivity

http//pubs.acs.org/hotartcl/cenear/000403/7814sci
t1.html
10
How Thermionic Refrigerators Work
  • Under an applied bias, hot electrons flow to
    the hot side of the junction
  • Removing the high energy electrons from the cold
    side of the junction cools it
  • Charge neutrality is maintained by adding
    electrons adiabatically through an ohmic contact
  • Amount of heat absorbed in cathode is total
    current times the average energy of electrons
    emitted over the barrier

Structure under thermal equilibrium
Structure under bias
11
TER vs. TIR
  • Thermoelectric Refrigeration
  • Electrons absorb energy from the lattice
  • Based on bulk properties of the semiconductor
  • Electron transport is diffusive
  • Thermionic Refrigeration
  • Electron transport is ballistic
  • Selective emission of hot carriers from cathode
    to anode yields higher efficiency than TER
  • Tunneling of lower energy carriers reduces
    efficiency

12
Thermionic Refrigeration
  • Thermionic devices are based on Richardsons
    equations
  • describes current per unit area emitted by a
    metal with work function f and temperature T
  • Cathode barrier height as a function of current

Mahan, G. D., Thermionic Refrigeration, J.
Appl. Phys, Vol. 76 (7) , pp. 4362, 1994.
13
Thermionic Refrigerator Operation
  • Practical thermionic refrigerators should emit at
    least 1 A/cm2 from the cathode
  • For room temperature operation, a work function
    of 0.4eV is needed
  • Most metal work functions are in the range of
    4-5eV
  • fm (eV) vs. Temperature (K)

Mahan, G. D., Thermionic Refrigeration, J.
Appl. Phys, Vol. 76 (7) , pp. 4363, 1994.
14
Thermionic Refrigeration Example
  • TLTh700K and TRTc500K
  • Work functions f0.7eV
  • 80 of Carnot efficiency
  • Current 1.3W/cm2
  • Bias Voltage 0.35V
  • The total voltage over the barrier is such that
    the drop across the mean free path is a few kT
  • Known as the Bethe criterion for thermionic
    emission

fmC
fmH
V
Mahan, G. D., Thermionic Refrigeration, J.
Appl. Phys, Vol. 76 (7) , pp. 4364, 1994.
15
Thermionic Refrigerator Issues
  • Lowering the barrier height to provide for room
    temperature cooling
  • Metal-Vacuum-Metal thermionic refrigerators only
    operate at high temperatures (gt700K)
  • Anode/Cathode spacing
  • Uniformity of electrodes
  • Proximity issues
  • Space charges in the vacuum region
  • Impedes the flow of electrons from the anode to
    the cathode by introducing an extra potential
    barrier
  • Thermal conductivity (in semiconductor devices)

16
Barrier height problem solved!...kind of
  • Need materials with low barrier heights
  • Heterostructures are perfect for this!
  • Bandgap engineering
  • Layer thickness and composition using epitaxial
    growth techniques (MBE and MOCVD)
  • Field assisted transport across barrier
  • Close and uniform spacing of anode and cathode is
    no longer a problem
  • Space charge can be controlled by modulation
    doping in the barrier region
  • Alloys can be used to create desired Schottky
    barrier heights at contacts
  • Drawback High thermal conductivity of
    semiconductors (compared to vacuum)

17
Heterostructure Cooling Power
  • Effective mass affects the cooling performance by
    changing the density of supply electrons and
    electrons in the barrier
  • This cooling power reduces at lower temperatures
    because the Fermi-Dirac distribution of electrons
    narrows as T decreases

Shakouri, A. and Bowers, J. E., Heterostructure
Integrated Thermionic Refrigeration, Appl. Phys.
Lett. 71 (9), pp. 1234, 1997
18
Heterostructure Refrigeration
  • Electron mean free path l at
  • 300K is assumed to be 0.2mm
  • Barrier thickness L must be lt l

fmC
fmH
L
Shakouri, A. and Bowers, J. E., Heterostructure
Integrated Thermionic Refrigeration, 16th Int.
Conf. on Thermoelectrics, pp. 636, 1997
19
Multilayer (Superlattice) Heterostructures
  • Overall thermal conductivity reduced to 10 of
    the individual materials that compose it
  • Efficiency increases 5-10 times over single
    barrier structures

Efficiency of a single barrier TIR where TH300K
and TC260K as a function of f
Efficiency of a multiple barrier TIR where
TH300K and TC260K as a function of f
Mahan, G. D., J. O. Sofo, and M. Bartkowiak,
Multilayer thermionic refrigerator and
generator, J. Appl. Phys., Vol. 83 No. 9, pp.
4683, 1998
20
SiGe/Si Microcoolers
  • 200 repeated layers of 3nmSi/12nmSi0.75Ge0.25
    superlattice (3mm thick)
  • Grown on Si0.8Ge0.2 buffer layer on Si substrate
  • Mesa etch to define devices

Shakouri, A. and Zhang, Y., On-Chip Solid-State
Cooling for ICs Using Thin-Film
Microrefrigerators, IEEE Trans. On Comp. and
Pack. Tech., Vol. 28 No. 1, pp. 66, 2005
21
SiGe/Si Microcoolers
  • Optimum device size 50x50 60x60mm2
  • Author reports maximum cooling of 20-30ºC and
    several thousands of W/cm2 cooling power density
    with optimized SiGe superlattic structures

Shakouri, A. and Zhang, Y., On-Chip Solid-State
Cooling for ICs Using Thin-Film
Microrefrigerators, IEEE Trans. On Comp. and
Pack. Tech., Vol. 28 No. 1, pp. 67, 2005
22
Advantages of Heterostructure TIR
  • Compared to bulk thermoelectric refrigerators
  • 1) very small size and standard thin-film
    fabrication - suitable for monolithic
    integration on IC chips
  • Possible to put refrigerator near active devices
    and cool hot spots directly
  • 2) higher cooling power density
  • 3) transient response of SiGe/Si superlattice
    refrigerators is several orders of magnitude
    faster (105 for these SiGe/Si microrefrigerators)

23
Further Improvement
  • Reduce thermal conductivity (materials)
  • The current limitation in superlattice coolers is
    the contact resistance between the metal and cap
    layer
  • Ohmic contacts to a thermionic emission device
    (ballistic transport) will have a non-zero
    resistance due to joule heating from the large
    current densities

Ulrich, M. D., P. A. Barnes, and C. B. Vining,
Effect of contact resistance in solid-state
thermionic emission, J. Appl. Phys., Vol. 92 No.
1, pp. 245, 2002
24
More Improvements
  • Packaging is also an important aspect of the
    device optimization
  • Addition of a package between chip and heat sink
    adds another thermal barrier
  • Use of Si or Cu packages aided in reducing this
    thermal resistance
  • Optimizing length of wire bonds
  • These improvements have resulted in a maximum
    cooling increase of gt100

25
Light Emission
  • Heat flowing in the reverse direction to the
    thermionic emission due to lattice heat
    conduction reduces the temperature difference and
    destroys efficiency
  • Opto-thermionic refrigeration gets the thermionic
    carriers e- from n-doped and h from p-doped
    semiconductor from each side could recombine
    radiatively

Intersubband Light Emitting Cooler
Interband LEC
Shakouri, A. and Bowers, J. E., Heterostructure
Integrated Thermionic Refrigeration, 16th Int.
Conf. on Thermoelectrics, pp. 636, 1997
26
Conclusions
  • Small area, localized cooling, can be implemented
    with current IC fabrication techniques
  • With optimization, current devices could provide
  • Cooling of 20-30ºC for 50x50 mm2 areas
  • Several thousands of W/cm2 cooling power density
  • Further exotic structures could increase
    efficiency further
  • Questions???
