Title: Plasma Assisted Surface Modification


1
Plasma Assisted Surface Modification
  • By Maurice Clark
  • For Elec 7730
  • Dr. Tzeng

2
Outline
  • Questions
  • Types Surface Modifications
  • Plasmas role in surface modification
  • Oxidation
  • Nitriding
  • Carburzing
  • Answer to questions

3
Questions
  • What are the four forms of surface modification?
  • Name one way that oxygen plasma is used to modify
    the surface of materials.
  • Why is plasma used to modify the surface of
    material?

4
Type of Surface modifications
5
Surface Modification Categories
  • Contamination Removal
  • Use physical and chemical energy to remove a
    small layer of contamination.
  • In this particular process positive ions hit the
    surface and dislodge the contaminates from the
    surface
  • Surface Activation
  • Process uses gases that dissociates when exposed
    to plasma, creating different functional groups
    on the surface.
  • Functional groups bonds well with the bulk
    material
  • Grafting
  • Plasma excited by inert gases activate the
    surface by creating free radicals on surface,
    then the material is exposed to monomers causing
    polymer layer to grafted
  • Cross Linking
  • Uses inert gases such as argon and helium to
    remove atomic species for the surface and then
    generates reactive surface radials The radicals
    then react within the surface forming chemical
    bonds which result is in cross-linked surface

6
Plasma Surface Modification
  • Cold Plasma
  • Microwave
  • Radio Frequency
  • Inductively Coupled
  • DC Glow Discharge
  • Processes such as deposition, cleaning, cross
    linking, and grafting competing within the
    plasma.
  • Controlling the parameters of the plasma we can
    make one process more preferable then the others.
  • Plasma is characterized by what it does to the
    substrate.

7
Plasma Surface Modification
  • Involves the interaction of plasma generated
    species with a solid surface.
  • Result in a physical or chemical modification of
    the first few layers of the surface, while
    maintaining the properties of the bulk material.
  • Materials employed in the microelectronic and
    optoelectronic industries include ceramics,
    glass, polymers ,and metal. (Au, Cu, Ni, ect.)

8
Plasma Parameters
  • Processing Parameters
  • Operating Pressure
  • Substrate voltage
  • Gas composition
  • Treatment Power
  • Treatment Time
  • System Parameters
  • Electrode Location
  • Reactor Design
  • Vacuum system

9
Plasma Oxidization
10
Plasma Oxidation
  • Plasma oxidation - formation of an oxide on a
    metal or semiconductor surface immersed in oxygen
    plasma at a floating potential.
  • The substrate is floating therefore no current is
    flowing through it and the oxide growth occurs by
    thermal diffusion.

11
Plasma Oxidation
12
Plasma Oxidation
  • Types of Plasmas
  • Inductively coupled
  • Microwave
  • Radio Frequency
  • ECR
  • Gases
  • Oxygen
  • Nitrous Oxide
  • Ozone

13
Applications
  • Effective gate dielectric
  • Polysilicon
  • Thin film transistors

14
Advantages of Oxidation
  • Reduced diffusion of heavy metals into silicon.
  • Possibility of oxidation after metallization.
  • Prevention of wafer warpage as a result of
    thermal stresses.
  • Possibility of oxidation of hydrogenated
    amorphous silicon with reduced hydrogen loss that
    world otherwise change the properties of the
    material.

15
Plasma Nitriding
16
Plasma Nitriding Process
  • Low pressure plasma process
  • Vacuum filled with H2 and N2 at pressure between
    0.1 to 10 torr, with a large DC voltage between
    the work space as the cathode and furnace as the
    anode
  • DC glow discharge ionizes the gas an ion hit the
    work surface and ion nitriding happens.

17
Properties of Plasma Nitrated Surfaces
  • Improvement in surface hardening
  • Greater wear resistance
  • Longer fatigue life
  • Corrosion Resistance
  • Process can be applied to wide variety of metal.
  • Cast Iron
  • Stainless Steel
  • Titanium
  • Plasma treatment is preferred over conventional
    treatment because if reduces the treatment time
    which takes about 50 hrs.

18
Surface Modification using Nitrogen Plasma
  • Improves the surface hardness
  • Gear wheels
  • Crank shafts
  • Dies ECT.
  • Reduced Adhesion
  • Improved High-temperature Strength
  • Increased part surface life

19
Plasma Nitriding Systems
20
Plasma Carburizing
21
Schematic of Plasma Carburizing Unit
  • Work piece is heated up to process temperature by
    an external heater in a vacuum furnace.
  • Methane or propane is introduced into the furnace
    to a pressure 2 to 3 torr.
  • A DC voltage is applied between the work piece or
    cathode and a glow discharge is generated

22
Carburizing
  • Plasma primarily assists in the mass transfer of
    carbon atoms to the surface of the sample.
  • Carburizing of steel has been done using
    hydrocarbons gas at 1-20 torr in a DC discharge.
    This process required extra heat treatment of the
    part at 1050C
  • Plasma treatment is conducted for a short period
    of time. A longer heating time is need in order
    to diffuse carbon into steel.

23
Carburizing Process Units
24
Surface Functionalize
25
Oxygen Plasma
  • Low pressure plasma
  • Reactive gases are feed into a vacuum chamber and
    are ionized by electrical energy.
  • Gases active in a way such that that the surface
    of the material is changed.
  • The byproduct of the this reaction are carry away
    by the pump.

26
Oxygen Plasma
  • Electrons generate
  • Ions
  • UV Photons
  • Negative Ions
  • Radicals
  • React with Surface
  • Carbon dioxide
  • Water
  • Modified Surface
  • Tailored properties

27
Fictionalization
  • Cross linking
  • Inert gas such as Argon or Helium
  • Ionized and the covalent polymer bonds are
    broken at the polymer surface .
  • Three process which can occur in the inert plasma
  • Dissociated molecules can revert to its previous
    state by recombining
  • Reaction between adjoining free radical within
    the polymer chain forming double and triple bonds
  • Molecules can form a bond with nearby free
    radical on an adjacent chain (cross linking)

28
Types of Plasmas used for Crosslinking
  • Helium
  • Argon
  • Krypton
  • Neon
  • Xeon
  • Hydrogen
  • Nitrogen

29
Process Applications for Plasma Surface
Enhancement
30
Fictionalization
  • CASING (Crosslinks via Activated Species of Inert
    Gases.
  • This process is used to enhance the performance
    of the polymers.
  • The bond breaking accords on the polymer surface.
  • Since there are no free radical scavengers
    (oxygen by products) in the plasma the molecules
    form bonds with nearby radicals on different
    chains.
  • Depending on the chemistry of the polymer and
    the gas the surface can be made wettable or
    nonwettable.

31
Answers
  • What are the four forms of surface modification?
    Crosslinking, Activation, Grafting, Contamination
    Removal
  • Name one way that oxygen plasma is used to modify
    the surface of materials. Oxidation
  • Why is plasma used to modify the surface of
    material? Low-temperature process

32
Conclusion
  • Plasma has many applications in industry.
  • Plasma can be used to modify a Varity of
    materials
  • Plasma can functionalize the surface to create
    properties that where not present before.
