Partage dinformation à grande échelle

• Marc Shapiro

Cambridge Distributed Systems Group
2
1. Résumé des épisodes précédents
3
Grandes étapes

• 1978 Ingénieur ENSEEIHT
• 1978--1980 doctorant LAAS
• 1980--1982 Post-doc MIT Lab. for Computer
  Science
• 1982--1985 Chargé de Recherches CMIRH
• 1984--1985 INRIA
• 1986--1999 Directeur de recherche, responsable
  scientifique INRIA projet SOR
• 1993--1994 Cornell
• 1997 Jini, Sun Research Labs
• 1999 Senior Researcher, MSR Cambridge

4
Thèses encadrées

• Yek Loong Chong. U. de Cambridge, 2003.
• Nicolas Richer. Paris 6, 2002.
• Fabrice le Fessant (co-encadrement).
  Polytechnique, 2001.
• Xavier Blondel. CNAM, 2000.
• Aline Baggio. Paris 6, 1999.
• Georges Brun-Cottan. Paris 6, 1998.
• Julien Maisonneuve, Paris 6, 1996.
• Paulo Ferreira. Paris 6, 1996.
• Hervé Soulard. Paris 6, 1995.
• David Plainfossé. Paris 6, 1994.
• Daniel Edelson. UC Santa Cruz, 1993.
• Michel Ruffin. Paris 6, 1992.
• Yvon Gourhant. Paris 6, 1991.
• Sabine Habert. Paris 6, 1989.
• Mesaac Mounchili Makpangou. Paris 6, 1989.

5
Publications

• Computing Surveys, en cours
• PODC 2001
• Livre Springer 2000
• PLDI 1998
• ECOOP 1998
• ICDCS 1996
• IWMM 1995
• WDAG 1995

• Livre IEEE 1994
• OSDI 1994
• ICDCS 1994
• PODC 1992
• RDS 1991
• Computing Systems 1989
• SOSP 1989
• ICDCS 1986

6
Le partage de linformation à grande échelle

• Complexité des systèmes répartis parallélisme,
  pannes, événement, latence
• Objets sémantique non prédéfinie
• Système
• outils communs
• aspects dynamiques
• compromis
• Traiter les problèmes de fond, impact sur le long
  terme

7
Objets Fragmentés1981-1990

• Structuration
• Contrôle de la transparence
• Mandataire
• programmable
• spécifique au client
• état du protocole
• Système SOS
• Voir
• proxy Web
• Jini
• pages Web dynamiques

8
Chaînes de Paires Souche-Scion 19901999

• Automatiser la gestion dobjets en réparti
• Références
• RM locaux coordination asynchrone
• Simplicité efficacité
• Tolérant les pannes détectables
• Dérivation formelle

x
z
y
t
9
RM asynchrone en mémoire répliquée 19932000

• Scalability ? asynch.
• Consistency
• Local GC
• Distributed GC
• Sufficient safety rules
• Union rule
• Clean propagation
• Comprehensive scanning
• Create before delete
• Causal delivery
• PerDiS

10
Réplication optimiste 2001

• Partage en écriture décentralisé
• IceCube
• moteur général de réconciliation
• journalisation dopérations
• paramétré par la sémantique
• Cohérence à terme
• modèle opérations contraintes
• sûreté vivacité
• invariant global
• décrire et comprendre les solutions
• Très préliminaire

11
2. Réplication optimiste et IceCube
12
Optimistic replication

• Replicas of shared objects on sites
• Without synchronisation
• peer-to-peer read
• and update!
• Applications
• high latency networks
• disconnected operation
• cooperative work
• Improves availability performance
• Consistency a posteriori, offline
• Merge independent updates

13
Example cooperative engineering with CVS

• CVS developing shared code
• Local, disconnected replica no interference
• Conflicts
• Write same file syntactic
• Overlap in file violates edit semantics
• Doesnt compile, test violates application
  semantics
• Both sides of a conflict are excluded
• Manual repair

14
Example Bayou

• General-purpose database
• Any replica can update, log actions
• action dependency check, operation,
  merge-procedure
• Optimistic replication
• epidemic exchange logs
• roll-back, replay commit
• dep-check semantic check for conflict
• merge-proc semantic repair

15
Operation-based model
0
scheduling commitment
0
16
Execution model

• operation code pre/post-conditions
• Schedule must satisfy
• Violation ? conflict
• But pre/post-conditions often unknown
• Conservative approximations

17
Happens-before

• True constraints unknown
• e1 precedes e2 in process
• e1 sends, e2 receives
• ? e1 ? e2
• ?(e1 ? e2) ? ?(e2 ? e1)
• ? e1 e2
• e1 e2 e1 does not cause e2
• e1 ? e2 e1 might cause e2
• Partial order, consistent with causal dependence
• Schedule consistent with ?

18
Syntactic vs. semantic mechanisms

• Scalar timestamps
• no concurrency detection
• very conservative approx. of causality
• Vector timestamps
• detect concurrency
• conservative approx. of causality
• Alternative explicit constraints

19
Constraints between operations

• Not all schedules are acceptable
• Constraints, e.g.
• x gt 50
• respect causal ordering
• all-or-nothing transactions
• alternative execution paths
• conflicting operations exclude each other

20
IceCube Primitive constraints

• Constraint predicate (action, schedule)
• Declarative (static binary)
• MustHave a ? b
• if a?s and a?b then b?s
• (not necessarily contiguous nor in order)
• Order a ? b
• if a, b?s and a?b then a before b in s
• (not necessarily both nor contiguous)
• Imperative (dynamic) a.preCondition (State)

21
IceCube log constraints
alternatives
predecessor- successor
parcel

• Express user intents
• Predecessor/successor a ? b ? b ? a
• b uses effect of a a causes b
• Parcel a ? b ? b ? a
• ?transaction
• Alternatives a ? b ? b ? a

22
IceCube Object constraints

• Shared data type advertises static semantics
• mutually exclusive
• a ? b ? b ? a
• best order (e.g. bank credits before debits)
• a ? b
• Only between concurrent actions
• Also dynamic constraints

mutually exclusive
best order
commute
23
Optimistic concurrency control scheduling

• Two actions are either
• Dependent
• ? schedule in dependence order
• Commutative
• ? schedule in any order
• Concurrent with favourable order
• schedule in non-conflicting order
• Concurrent and conflicting
• or exclude one, the other, or both

24
IceCube scheduling

• Insight
• conflict choice of which action to exclude
• maximise value

25
IceCube scheduling model
dynamic constraints
0
1
object constraints
0
2
26
Search vs. syntactic order
27
Performance of IceCube heuristics
28
3. Cohérence à terme (Eventual consistency)
29
Eventual consistency

• Consistent with user intents
• Consistent with data invariants
• Replicas consistent with each other
• Eventual consistency
• Each site receives all actions
• Schedule that satisfies constraints
• Common stable prefix
• Equivalent results

30
Stability

• Peer-to-peer, indefinite tentative update
  advisory reconciliation OK
• But stability needed
• Users, external world depend on it
• Garbage collect multilog
• Only stable actions relevant for consistency
• Stable eventually decisions not changed
• Committed definitely included in all schedules
• Aborted definitely excluded

31
Eventual consistency intuitive

• Liveness sites receive all operations
• Epidemic multicast
• Quickly
• Safety sites compute the same value
• Equivalent schedules
• Stability actions eventually not undone
• Commit / abort

32
Sound schedules

• s sound s satisfies constraints for all its
  actions
• Closed for MustHave
• a?s ? a?b ? b?s
• Consistent with Order (? acyclic)
• (a,b? s ? a?b) ? a before b in s
• Actions succeed
• a ? s ? a.preCondition (state)

33
Maintaining local soundness

• ? site i, schedule si
• Legal
• committedi ? si ? abortedi ? si ?
• Safe
• si sound
• When aborting a, also abort actions that MustHave
  a
• When committing a, also abort uncommitted actions
  that are Ordered before a

34
Schedule equivalence

• Equivalence s ? t
• s, t sound
• a?s ? a?t
• ordering is irrelevant!
• Eventual consistency reduces to
• Same committed operations everywhere
• All committed operations in every schedule
• Schedules are sound

35
Eventual consistency

• ? action a, site i,k, schedule si
• Legal
• committedi ? si ? abortedi ? si ?
• Safe
• si sound
• Live
• ?a ? committedi ? abortedi
• a ? committedi ? ??a ? committedk
• a ? abortedi ? ??a ? abortedk

36
Global safety invariant

• sound ?t ? time, i ? sitescommittedi(t)
• Closed for MustHave ?
• Non-conflicting Acyclic in Order ?
• Actions successful
• ?s, ?a a.preCondition (state)
• Very strong!
• i commits a at t only if j wont commit
  conflicting b at t
• a will succeed everywhere, anytime

37
Maintaining global invariant

• Alternatives
• Common knowledge deterministic abort rule idem
  commit?
• TWR
• Unilateral abort idem commit?
• CVS, Holliday 2000
• Single primary site decides
• Bayou, CVS
• Consensus before deciding
• Deno, Holliday 2000-2002

38
Stability with TWR

• Independent objects
• Independent writes (no MustHave nor Order)
• All sites take same decision
• Given two writes to same object, abort the
  earlier
• Whether concurrent or not
• Write stable when seen by all sites
• Disjointness committedi ?
• Soundness no MustHave (no transactions)

39
Stability in Bayou

• Databases
• Disjoint
• Independent no multi-DB transaction
• 1 primary / database
• Log constraints transactions, time order
• Disjointness Only 1 site decides about a the
  primary for the database that a updates
• Soundness whole transaction commits or aborts

40
Hollidays pre-commit protocol

• Log constraints
• multi-object transactions
• happens-before order
• Read transactions commit locally
• Read-Write transactions consensus to commit
• convert locks to intentions
• pre-commit, vote
• commit if quorum yes
• abort if anti-quorum no or conflict with
  committed

41
Trade-offs

• No perfect solution
• Common knowledge
• syntactic fast, inflexible
• aborts, doesnt commit
• Partition primary
• single point of failure
• no MustHave across partition boundaries
• Consensus
• slow
• scalability
• impossibility of consensus in asynchronous
  systems with failure

42
4. Conclusion
43
Passage à léchelle ?

• Réplication en écriture
• CC pessimiste attendre
• CC optimiste spéculer
• Progrès malgré pannes
• Non transparent
• Limité par le commit
• Compromis possibles
• partitionner
• diminuer la granularité
• limiter nombre décrivains

44
Perspectives

• Importance grandissante du partage
• Lecture et écriture
• Commerce électronique
• Pertinence des techniques
• Mandataires spécifiques encapsulant létat du
  protocole
• Java, .Net ramasse-miettes réparti
• Réplication centres Web, BD
• Travail déconnecté

45
The end
